Page 3 - Power Sensors

The UPF10P-2S-H5-L-D0 is a high-performance thermal detector designed for accurate laser power measurement up to 2 W. It combines the low power thermopile technology with the large bandwidth and high-power capacity of a thermal device. With its compact design and smart interface containing calibration data, it offers convenience and ...

Specifications

Max Average Power: 2 W
Effective Aperture: 10 mm
Spectral Range: 0.28-21um
Cooling Method: No cooling
Rise Time: 1.4 sec
The UP12E-20H-H5-D0 is a high-quality thermal detector designed for precise laser power measurement applications. With a maximum continuous power handling capacity of 20 W, this detector provides accurate and reliable results across a broad spectral range. Its exceptional sensitivity and fast response time make it an ideal choice for ...

Specifications

Max Average Power: 40 W
Effective Aperture: 12 mm
Spectral Range: 0.19-20um
Cooling Method: Water, Heatsink
Maximum Average Power (continuous): 20 W
The Gentec-EO UP series of laser power detectors include seven families (XLP12, UP12, UP10, UP17, UP19, UP25, UP55) of opto-thermal sensors with different cooling options (stand alone, heat sink, fan and water), with or without amplification.  The high power surface absorber sensors are designed for use at high average power ...

Specifications

Max Average Power: 70 W
Effective Aperture: 12 mm
Spectral Range: 0.19-20um
Cooling Method: Water, Heatsink
The Gentec-EO UP series stands at the forefront of laser power detection technology, offering a versatile lineup of opto-thermal sensors tailored to meet the precise demands of various applications. This series encompasses seven distinct families, including XLP12, UP12, UP10, UP17, UP19, UP25, and UP55, each engineered for ...

Specifications

Max Average Power: 2 W
Effective Aperture: 10 mm
Spectral Range: 0.19-20um
Cooling Method: No cooling
The Gentec-EO UP series of laser power detectors include seven families (XLP12, UP12, UP10, UP17, UP19, UP25, UP55) of opto-thermal sensors with different cooling options (stand alone, heat sink, fan and water), with or without amplification.  The high power surface absorber sensors are designed for use at high average power ...

Specifications

Max Average Power: 200 W
Effective Aperture: 19 mm
Spectral Range: 0.19-20um
Cooling Method: Water, Heatsink, Fan-cooled
The Gentec-EO UP series of laser power detectors include seven families (XLP12, UP12, UP10, UP17, UP19, UP25, UP55) of opto-thermal sensors with different cooling options (stand alone, heat sink, fan and water), with or without amplification.  The high power surface absorber sensors are designed for use at high average power ...

Specifications

Max Average Power: 150 W
Effective Aperture: 19 mm
Spectral Range: 0.19-20um
Cooling Method: Water, Heatsink, Fan-cooled
The UP19K-110F-H9-D0 is a high-performance thermal detector designed for laser power measurement up to 110 W. It offers a compact design, fast rise time, and a high damage threshold. With its modular concept, it provides flexibility in increasing the power capability of the detector. The detector is equipped with a smart interface ...

Specifications

Max Average Power: 110 W
Effective Aperture: 19 mm
Spectral Range: 0.19-20um
Cooling Method: Water, Heatsink, Fan-cooled
Dimensions: 50H x 50W x 63D mm
The UP19K-50L-H5-D0 is a highly efficient thermal detector designed for laser power measurement, capable of handling powers up to 50 W. With a modular concept and five different cooling modules, it offers versatility and power capability. This detector boasts high performance with a fast rise time of 0.6 seconds and a high damage ...

Specifications

Max Average Power: 50 W
Effective Aperture: 19 mm
Spectral Range: 0.19-20um
Cooling Method: Water, Heatsink, Fan-cooled
Noise Equivalent Power: 1.0 mW
The UP19K-30H-H5-D0 is a high-performance thermal detector designed for accurate laser power measurement. With a maximum capacity of 30 W, it provides precise and reliable measurements in a compact form factor. This detector is ideal for a wide range of laser applications and offers exceptional sensitivity.

Specifications

Max Average Power: 60 W
Effective Aperture: 19 mm
Spectral Range: 0.19-20um
Cooling Method: Water, Heatsink, Fan-cooled
Maximum Average Power (continuous): 30 W
About Gentec-EO: Gentec Electro-Optics is specialized in laser beam and terahertz source measurement and analysis. Gentec-EO is an expert in the design and manufacture of light detection and measurement technologies and solutions with a 50-year history in the market. Gentec\'s offerings include laser beam profilers, ...

Specifications

Max Average Power: 250 W
Effective Aperture: 19 mm
Spectral Range: 0.19-20um
Cooling Method: Convection, Thermoelectric, Heatsink, Fan-cooled
The Gentec-EO PH20-GE-D0 is a high-performance photodiode detector engineered for laser power measurement, capable of accurately measuring laser power up to 30 mW. This photodiode detector offers exceptional precision, sensitivity, and reliability, making it the perfect choice for a wide range of laser power measurement applications.

Specifications

Max Average Power: 0.03 W
Effective Aperture: 5 mm
Spectral Range: 0.6-1.65um
Cooling Method: No cooling
Maximum Average Power: 30 mW
The Gentec-EO PH100-SIUV-D0 is a high-performance photodiode detector designed for laser power measurement, capable of accurately measuring laser power up to 4 mW. This precision instrument offers exceptional sensitivity and reliability, making it an ideal choice for various laser power measurement applications.

Specifications

Max Average Power: 0.038 W
Effective Aperture: 10 mm
Spectral Range: 0.21-1.08um
Cooling Method: No cooling
Maximum Average Power: 4 mW
The Gentec-EO HP280A-30KW-HD-IMP-D0 is a high-power detector designed for laser power measurement up to 30,000 W. With traceable calibration and award-winning technology, this wireless detector ensures accurate and reliable readings.  Its compact design, coupled with BLU wireless output, allows measurements in enclosures or ...

Specifications

Max Average Power: 30000 W
Effective Aperture: 280 mm
Spectral Range: 0.19-20um
Cooling Method: Water
Minimum Average Power: 1000 W
The Gentec-EO Super HP Laser Power Detector is a high-power solution for accurate laser power measurement. With customizable models handling up to 100,000 W of continuous power, it offers stability in readings, especially in water cooling variations. Its compact and lightweight design, unique to the market, comes with infinite ...

Specifications

Max Average Power: 25000 W
Effective Aperture: 210 mm
Spectral Range: 0.19-20um
Cooling Method: Water
Noise Equivalent Power: ±20 W
The UP17P-6S-W5-D0 is a thermal detector designed for laser power measurement up to 6 W. With its ultra-thin casing and high power-to-size ratio, this detector offers a compact and efficient solution for accurate power measurements. It features a choice between two absorbers, H5 with a damage threshold of 36 kW/cm2 and W5 with an ...

Specifications

Max Average Power: 6 W
Effective Aperture: 17 mm
Spectral Range: 0.19-10um
Cooling Method: Convection
Absorber Options: H5 (36 kW/cm2), W5 (100 kW/cm2)
The UP17P-6S-H5-D0 is a thermal detector designed for laser power measurement up to 6 W. With its ultra-thin casing and high "power to size" ratio, this detector offers compact and accurate power measurement capabilities. It features a choice between two absorbers: H5 with a power density of 36 kW/cm2 and W5 with an unmatched power ...

Specifications

Max Average Power: 6 W
Effective Aperture: 17 mm
Spectral Range: 0.19-20um
Cooling Method: Convection
Absorber Choices: H5 (36 kW/cm2), W5 (100 kW/cm2)
The Gentec HP125A-15KW-HD-IMP-D0 is a cutting-edge high-power detector meticulously crafted for precise laser power measurements, accommodating powers up to an impressive 15,000 W. Engineered with advanced features such as traceable calibration, water cooling, and a high-damage threshold, this detector ensures accurate and reliable ...

Specifications

Max Average Power: 15000 W
Effective Aperture: 125 mm
Spectral Range: 0.19-20um
Cooling Method: Water
Minimum Average Power: 500 W
The Gentec HP100A-12KW-HD-TUBE-IMP-D0 is an advanced high-power detector designed for precise laser power measurements, capable of handling powers up to an impressive 12,000 W. Featuring an extension tube to reduce back reflections, this detector is ideal for applications requiring high-power lasers. With exceptional accuracy, ...

Specifications

Max Average Power: 12000 W
Effective Aperture: 125 mm
Spectral Range: 0.19-20um
Cooling Method: Water
Minimum Average Powe: 300 W
The Gentec-EO HP Series power detector family includes HP100A-4KW-HE, HP60A-10KW-GD and HP100A-12KW-HD, HP125A-15KW-HD. The HP detectors can measure between - 100 W and 4 KW of average power for HP100A-4KW-HE & HP100A-4KW-HE-TUBE - 300 W and 10 KW of average power for HP60A-10KW-GD - 300 Wand 12 KW of average power for ...

Specifications

Max Average Power: 4000 W
Effective Aperture: 125 mm
Spectral Range: 0.19-20um
Cooling Method: Water
Achieve precision in laser power measurement with the Gentec IS50A-1KW-RSI-INT-D0 Water-Cooled Integrating Sphere Detector. Designed for applications requiring laser power measurements up to 1000 W, this detector combines water cooling and integrating sphere technology to deliver accurate and reliable results. The award-winning ...

Specifications

Max Average Power: 1000 W
Effective Aperture: 50 mm
Spectral Range: 0.34-1.1um
Cooling Method: Water
Noise Equivalent Power: 10 μW
