Energy and Power Sensors

The ROF-PD-10G 10GHz high-speed light detection module uses high-performance 10GHz PIN detector, single-mode / multi-mode fiber coupling input, SMA connector output, having high gain, high sensitivity, DC / AC coupling output, gain flat and other Features, mainly being used in high-speed optical fiber transmission system, ROF and ...

Specifications

Detector Type: Photodetector
Min Power Measurement: 10 nW
Max Power Measurement: 40 W
Spectral Range: 850-1660nm
Display: Touch screen
...
Data Sheet
The T-RAD-ANALOG is an analog (BNC) power module designed to interface with THZ-B heads, making it compatible with oscilloscopes and lock-in amplifiers. This module is a crucial component for measuring and analyzing optical power accurately.

Specifications

Detector Compatibility: Photodiode, Pyroelectric, Thermopile
Min Measurable Energy: Not Applicable
Max Measurable Energy: Not Applicable
Min Measurable Power: <10 pW
Max Measurable Power: <100 kW
...
Data Sheet
The MACH 6 is a high-speed joulemeter designed to measure every pulse at up to 200 kHz with exceptional precision. It offers 12-bit digital accuracy and can capture up to 4 million pulses in real-time. This instrument sets the standard for speed and accuracy in joulemeter technology and is compatible with a range of fast energy ...

Specifications

Detector Compatibility: Photodiode, Pyroelectric, Other
Min Measurable Energy: <10 pJ
Max Measurable Energy: <10 mJ
Min Measurable Power: Not Applicable
Max Measurable Power: Not Applicable
...
Data Sheet
The PE5B-GE-D0 is a precision photodiode detector designed for laser energy measurement applications, capable of measuring laser energies of up to 2.4 nJ. This compact and high-performance detector operates in the spectral range of 800 to 1650 nm and offers exceptional sensitivity and accuracy. With fast response times and high ...

Specifications

Max Measurable Energy: 0.0000024 mJ
Max Repetition Rate: 1000 Hz
Effective Aperture: 5 mm
Spectral Range: 0.8-1.65um
Typical Energy Sensitivity: 1 GV/J
...
Data Sheet
The PRONTO-250 is a versatile and portable laser power meter designed for laser power measurements of up to 250 W. This compact device provides accurate and reliable power measurements in a wide spectral range, making it an essential tool for laser operators, researchers, and engineers. With intuitive user interface, protective ...

Specifications

Max Average Power: 250 W
Effective Aperture: 19 mm
Spectral Range: 0.19-20um
Cooling Method: No cooling
Noise Level: 10 mW
...
Data Sheet
The UP12E-20H-H5-D0 is a high-quality thermal detector designed for precise laser power measurement applications. With a maximum continuous power handling capacity of 20 W, this detector provides accurate and reliable results across a broad spectral range. Its exceptional sensitivity and fast response time make it an ideal choice for ...

Specifications

Max Average Power: 40 W
Effective Aperture: 12 mm
Spectral Range: 0.19-20um
Cooling Method: Water, Heatsink
Maximum Average Power (continuous): 20 W
...
Data Sheet
The UP19K-30H-H5-D0 is a high-performance thermal detector designed for accurate laser power measurement. With a maximum capacity of 30 W, it provides precise and reliable measurements in a compact form factor. This detector is ideal for a wide range of laser applications and offers exceptional sensitivity.

Specifications

Max Average Power: 60 W
Effective Aperture: 19 mm
Spectral Range: 0.19-20um
Cooling Method: Water, Heatsink, Fan-cooled
Maximum Average Power (continuous): 30 W
...
Data Sheet
The U-LINK (USB) is a versatile PC interface designed for precise power and energy measurements. With a single-channel USB output, it offers exceptional performance and flexibility for a wide range of applications. This universal meter is compatible with various detectors, and its advanced features make it a valuable tool for ...

Specifications

Detector Compatibility: Photodiode, Pyroelectric, Thermopile
Min Measurable Energy: Not Applicable
Max Measurable Energy: Not Applicable
Min Measurable Power: <10 pW
Max Measurable Power: <100 kW
...
Data Sheet
The UP19K-50L-H5-D0 is a highly efficient thermal detector designed for laser power measurement, capable of handling powers up to 50 W. With a modular concept and five different cooling modules, it offers versatility and power capability. This detector boasts high performance with a fast rise time of 0.6 seconds and a high damage ...

Specifications

Max Average Power: 50 W
Effective Aperture: 19 mm
Spectral Range: 0.19-20um
Cooling Method: Water, Heatsink, Fan-cooled
Noise Equivalent Power: 1.0 mW
...
Data Sheet
The U-LINK (RS-232) is a single-channel PC interface designed for precise power and energy measurement. This versatile interface, with RS-232 output, offers comprehensive control and data acquisition capabilities through the user-friendly PC-Gentec-EO software. It is a valuable tool for professionals in need of accurate measurement ...

Specifications

Detector Compatibility: Photodiode, Pyroelectric, Thermopile
Min Measurable Energy: Not Applicable
Max Measurable Energy: Not Applicable
Min Measurable Power: <10 pW
Max Measurable Power: <100 kW
...
Data Sheet
The PRONTO-500-IPL is a highly capable portable energy meter designed for IPL (Intense Pulsed Light) sources. It replaces the discontinued FLASH-500-55-W-IPL and FLASH-500-55-W-IPL-C models, offering the same measurement capabilities but with enhanced features. This energy meter provides accurate readings of up to 350 J per pulse ...

Specifications

Max Measurable Energy: 350000 mJ
Max Repetition Rate: 0.067 Hz
Effective Aperture: 55 mm
Spectral Range: 0.19-2.5um
Noise Equivalent Energy: 500 mJ
...
Data Sheet
The PRONTO-500-IPL is a highly capable portable energy meter designed for IPL (Intense Pulsed Light) sources. It replaces the discontinued FLASH-500-55-W-IPL and FLASH-500-55-W-IPL-C models, offering the same measurement capabilities but with enhanced features. This energy meter provides accurate readings of up to 350 J per pulse ...

Specifications

Max Measurable Energy: 0.000000001 mJ
Max Repetition Rate: 1000 Hz
Effective Aperture: 3 mm
Spectral Range: 0.21-1.08um
Typical Rise Time: 30 µs
...
Data Sheet
The PRONTO-10K is a highly versatile and portable laser power meter designed for measuring laser power with exceptional precision. With the capability to measure power levels of up to 10,000 W, this device is an essential tool for laser professionals. It features advanced electronics, data logging capabilities, and a USB connection ...

Specifications

Max Average Power: 10000 W
Effective Aperture: 55 mm
Spectral Range: 0.19-20um
Cooling Method: Convection
Minimum Average Power: 30 W
...
Data Sheet
The PRONTO-3K is a portable laser power meter designed to measure laser power with precision, catering to applications with power levels of up to 3,000 W. This compact and versatile device provides quick and accurate measurements with a minimal exposure time of 10 seconds. It operates within a broad spectral range from 0.193 to 20 ...

Specifications

Max Average Power: 3000 W
Effective Aperture: 55 mm
Spectral Range: 0.19-20um
Cooling Method: Convection
Minimum Average Power: 5.0 W
...
Data Sheet
The UD19-150-H5 is a high-performance uncalibrated thermal disk sensor designed for precise laser power measurement applications. It boasts a maximum average power handling capacity of 150 W, making it suitable for various laser power monitoring needs. With a wide spectral range of 0.19 - 20 μm and a noise equivalent power as low ...

Specifications

Max Measurable Energy: 15000 mJ
Max Repetition Rate: 10 Hz
Effective Aperture: 19 mm
Spectral Range: 0.19-20um
Maximum Average Power: 150 W
...
Data Sheet
The BLU is an innovative embedded wireless interface designed to streamline power measurement tasks. It is exclusively available as a detector output option, offering convenient and efficient connectivity for your power and energy measurement needs. With its user-friendly mobile application and versatile measurement parameters, the ...

Specifications

Detector Compatibility: Photodiode, Pyroelectric, Thermopile, Fiber, Integrating Sphere, Microbolometer
Min Measurable Energy: Not Applicable
Max Measurable Energy: Not Applicable
Min Measurable Power: Not Applicable
Max Measurable Power: Not Applicable
...
Data Sheet
The QE50LP-H-MB-QED-D0 is a high-performance pyroelectric detector designed for laser energy measurement up to 85 J. This versatile detector offers a range of features and options to suit various laser applications, making it an essential tool for precise energy measurements.

Specifications

Max Measurable Energy: 85000 mJ
Max Repetition Rate: 200 Hz
Effective Aperture: 47 mm
Spectral Range: 0.3-2.1um
Typical Rise Time: 900 us
...
Data Sheet
Gentec-EO's Calorimeters are the pinnacle of reliability for measuring laser beams, particularly for the most substantial and highest energy laser beams. These calorimeters, crafted with precision and expertise, offer unrivaled performance for high-energy inertial confinement fusion calorimetric measurements. With over 40 years of ...

Specifications

Aperture Shape: Round
Aperture Size (larger Dimension): 310 mm
Spectral Range: 351 nm
Maximum Energy: 500 J
Data Sheet
The Gentec-EO High Energy Calorimeter is a state-of-the-art solution designed for accurately measuring extremely high-energy laser beams. With over 40 years of experience in thermal-based energy measurement, Gentec-EO is the trusted choice for applications that demand precision and reliability. Our calorimeters are used in inertial ...

Specifications

Aperture Shape: Round
Aperture Size (larger Dimension): 17 mm
Spectral Range: 190 - 10000 nm
Maximum Energy: 23 J
Minimum Energy: 1 mJ
Data Sheet
Gentec-EO's Calorimeters are the pinnacle of reliability for measuring laser beams, particularly for the most substantial and highest energy laser beams. These calorimeters, crafted with precision and expertise, offer unrivaled performance for high-energy inertial confinement fusion calorimetric measurements. With over 40 years of ...

Specifications

Aperture Shape: Rectangular
Aperture Size (larger Dimension): 400 mm
Spectral Range: 1053 nm, 532 nm, 351 nm
Maximum Energy: 5000 J
Data Sheet
The Gentec-EO High Energy Calorimeter is a state-of-the-art solution designed for accurately measuring extremely high-energy laser beams. With over 40 years of experience in thermal-based energy measurement, Gentec-EO is the trusted choice for applications that demand precision and reliability. Our calorimeters are used in inertial ...

Specifications

Aperture Shape: Round
Aperture Size (larger Dimension): 19 mm
Spectral Range: 190 - 25000 nm
Maximum Energy: 2.3 J
Minimum Energy: 1 mJ
Data Sheet
The Gentec-EO M6-12.5-PY is a highly efficient integrating sphere detector designed for laser energy measurement, capable of handling energies up to 20 mJ. This precision instrument offers reliable and accurate measurements across a wide spectral range, making it an essential tool for laser energy monitoring and analysis in various ...

Specifications

Max Measurable Energy: 200 mJ
Max Repetition Rate: 200000 Hz
Effective Aperture: 12.5 mm
Spectral Range: 0.35-2.5um
Maximum Measurable Energy: 20 mJ
...
Data Sheet
The Gentec-EO UD19-200-H9 is a precision uncalibrated thermal disk sensor designed for laser power measurement, accommodating power levels up to 200 W. This sensor offers reliable and accurate measurements across a broad spectral range, making it an essential tool for laser power monitoring and analysis in various applications.

Specifications

Max Measurable Energy: 25000 mJ
Max Repetition Rate: 8 Hz
Effective Aperture: 19 mm
Spectral Range: 0.19-20um
Maximum Average Power (fan-cooled): 110 W
...
Data Sheet
Gentec-EO UD19-50-W5 thermal sensor disk. The Ultra Disks were designed for integration into laser systems. They are the solution if you are engineering the cooling and signal processing into your system already. The chart below and on the next page show the various Possibilities that Gentec-EO offers to OEM users. The choice ...

Specifications

Max Measurable Energy: 500000 mJ
Max Repetition Rate: 0.25 Hz
Effective Aperture: 17 mm
Spectral Range: 0.19-10um
Maximum Average Power: 50 W
...
Data Sheet
The Gentec-EO PH100-SIUV-D0 is a high-performance photodiode detector designed for laser power measurement, capable of accurately measuring laser power up to 4 mW. This precision instrument offers exceptional sensitivity and reliability, making it an ideal choice for various laser power measurement applications.

Specifications

Max Average Power: 0.038 W
Effective Aperture: 10 mm
Spectral Range: 0.21-1.08um
Cooling Method: No cooling
Maximum Average Power: 4 mW
...
Data Sheet

Frequently Asked Questions

A power sensor is a device used to measure the power of a laser beam. The sensor works by absorbing the energy of the laser beam and converting it into an electrical signal, which can then be read by a meter.

Thermal sensors use a thermopile to measure the temperature rise caused by the absorption of laser energy. Photodiode sensors use a photodiode to measure the current generated by the absorption of laser energy. Thermal sensors are typically more accurate and have a broader spectral range, while photodiode sensors are faster and more compact.

An energy sensor is a device used to measure the total energy output of a laser pulse, rather than the power of the laser beam. Energy sensors typically use a pyroelectric crystal to measure the temperature rise caused by the absorption of laser energy. While power sensors measure the continuous power output of a laser, energy sensors are used to measure pulsed laser output.

Choosing the right sensor depends on various factors such as the power range of the laser, the wavelength of the laser, and the type of measurement required. It's important to consider the accuracy, resolution, and response time of the sensor, as well as its compatibility with other equipment in your setup.

Accessories such as attenuators, filters, and beam splitters may be necessary to optimize the performance of your sensor. It's important to choose accessories that are compatible with your sensor and the laser source you are using. FindLight offers a range of accessories to help you get the most out of your power and energy sensor.

FindLight offers a wide range of power and energy sensors for scientific and industrial applications. These sensors are used to measure the optical power or energy output of lasers across a broad spectral range. Customers can browse and compare different types of sensors, including thermal, photodiode, and pyroelectric sensors, to find the right sensor for their specific needs. With expert support and fast response by suppliers, FindLight is the go-to source for high-quality power and energy sensors.
