Description
The technologically advanced IRC912 science grade camera utilizes a high operating temperature nBn focal plane array (FPA) and provides unmatched sensitivity and ultra-low noise with no blooming or crosstalk. The IRC912 operates at up to 119 frames per second full frame, and supports sub windowing for even higher frame rates. The IRC912 features high definition 1280 x 1024 pixel resolution at full window size, and includes Camera Link, Gigabit Ethernet and HDMI outputs. The IRC912 is the perfect choice for the most demanding MWIR imaging applications including materials evaluation, quality assurance and spectroscopy.
IRC912 nBn MID WAVE INFRARED CAMERA
Specifications
| Camera Type: | Industrial, Scientific |
|---|---|
| Array Type: | InSb |
| Spectral Band: | 1 – 5.3 um |
| # Pixels (Height): | 1280 |
| # Pixels (Width): | 1024 |
| Pixel Pitch: | 12 um |
| Array Cooling: | Cooled |
Download Data Sheet
Features
- 1280 x 1024 H.O.T. nBn sensor
- <1 μm to >5 μm spectral response
- NEdT 35 mK
- 119 Hz full window frame rate with windowing
- Motorized four position warm filter wheel option
- Simultaneous Camera Link, GigE & HDMI outputs
Applications
- Surveillance
- Metrology
- Scientific and industrial
- Medical
Frequently Asked Questions
What is the spectral response range of the IRC912 camera?
The spectral response range of the IRC912 camera is from less than 1 μm to greater than 5 μm.
What is the frame rate of the IRC912 camera?
The IRC912 camera operates at up to 119 frames per second full frame, and supports sub windowing for even higher frame rates.
Does the IRC912 camera come with any software?
Yes, the IRC912 camera is delivered with WinIRC software, and a Software Developers' Kit is available for integration into end user applications.
What are the outputs available on the IRC912 camera?
The IRC912 camera includes Camera Link, Gigabit Ethernet, and HDMI outputs.
What are some applications for the IRC912 camera?
The IRC912 camera is suitable for the most demanding MWIR imaging applications including materials evaluation, quality assurance, and spectroscopy.
