LiSaSWIR 2048M-STE

Name: LiSaSWIR 2048M-STE
Brand: New Imaging Technologies (NIT)
Availability: InStock

Description

SWIR line-scan array camera
2048x1 Pixels Resolution 8μm pixel Pitch
Short-Wave-Infrared Imaging up to 1700nm

Specifications

Camera Type:	Industrial
Array Type:	InGaAs
Spectral Band:	0.9 – 1.7 um
# Pixels (Height):	2048
# Pixels (Width):	1
Pixel Pitch:	8 um
Array Cooling:	Uncooled
Frame Rate:	110kHz
Interface:	CameraLink
Read-out Noise:	<90e- (HG)
GenICam Compliant:	Yes

Download Data Sheet

Features

Line-scan array
High QE InGaAs from 900nm to 1700nm
2K Resolution: 2048*1pixels
Bad Pixels Replacement and embedded
Non-Uniformity Correction
High Sensitivity, low noise <90e-
CameraLink interface
GenIcam compliant

Applications

Solar panel inspection
Wafer & semiconductor inspection
Hot Glass inspection
Process Sorting (food, waste, etc.)

Add to Watchlist (My Watchlist)

Ships from:

France

Sold by:

New Imaging Technologies (NIT)

On FindLight:

since 2020

Got Questions? Ask Above ▲

Message the supplier directly
No signup or account needed
No FindLight fees or markups
Expect a fast reply

Frequently Asked Questions

What is the LiSaSWIR 2048-STE?

The LiSaSWIR 2048 is a SWIR line-scan array camera with a resolution of 2048x1 pixels.

What is the pitch of the camera?

The camera has a pitch of 8μm.

What is the wavelength range that the camera can capture?

The camera can capture short-wave-infrared imaging up to 1700nm.

What are the features of the LiSaSWIR 2048?

The camera features a line-scan array, high QE InGaAs from 900nm to 1700nm, framerate >110kHz, 2K resolution, bad pixels replacement and embedded non-uniformity correction, and a CameraLink interface, genIcam compliant

What are some applications of the LiSaSWIR 2048?

The camera can be used for solar panel inspection, wafer & semiconductor inspection, hot glass inspection, and process sorting in industries such as food and waste management.
