Imaging & Spectroscopy

FASTCAM SA-Z High Performance High-speed Camera System
Photron Europe Ltd
The Photron FASTCAM SA-Z offers scientists, researchers and engineers the ability to capture high resolution digital images at ultra-high speeds to see and understand previously invisible processes and events. Using Photron’s proprietary CMOS image sensor technology, the FASTCAM SA-Z combines high recording rates with outstanding ...

Specifications

Sensor Type: CMOS
# Pixels (Width): 1024
# Pixels (Height): 1024
Pixel Size (Square): 20 um
Peak Quantum Efficiency: 46 %
...
Data Sheet
MV-CH310-10GM-F-NF 31 MP CMOS Area Scan Camera
MaxxVision GmbH
MV-CH310-10GM-F-NF is a high-end area scan camera of the CH series. It adopts Sony IMX 342 CMOS sensor and provides high quality image with high resolution and low noise. The Gigabit Ethernet interface provides high speed real-time transmission of uncompressed data.

Specifications

Sensor Type: CMOS
# Pixels (Width): 6480
# Pixels (Height): 4860
Pixel Size (Square): 3.45 um
Peak Quantum Efficiency: 100 %
...
Data Sheet
Prime 95B is the Scientific CMOS with extreme sensitivity using high Quantum Efficiency (QE) Backside Illumination (BSI), a first for Scientific CMOS cameras. The 95B’s sensor converts up to 95% of incident photons into a measurable signal.  Unlike microlens approaches to increasing QE, which lose effectiveness as objective ...

Specifications

Sensor Type: sCMOS
# Pixels (Width): 1200
# Pixels (Height): 1200
Pixel Size (Square): 11 um
Peak Quantum Efficiency: 95 %
...
Data Sheet
BUILT FOR RESOLUTION Made for applications requiring a large field of view along with p⁣h⁣o⁣t⁣o⁣n⁣ ⁣c⁣o⁣u⁣n⁣t⁣i⁣n⁣g⁣ capabilities in the fields of Space & Defense, Life Science, Physics, Industry and more. The HNü 1024 camera provides exactly what is to be expected from a high-end E⁣M⁣C⁣C⁣D⁣ camera: virtually no noise. This ...

Specifications

Sensor Type: EMCCD
# Pixels (Width): 1024
# Pixels (Height): 1024
Pixel Size (Square): 13 um
Peak Quantum Efficiency: 95 %
...
Data Sheet
Built for Adaptive Optics' highest performance With frame rates over 3000 fps in full-frame the HNü 240 camera provides exactly what is to be expected from a high-end E⁣M⁣C⁣C⁣D⁣ Adaptive Optics (AO) optimized camera: virtually no noise with the high frame rates necessary to outpace atmospheric distortion. The HNü 240 also has ...

Specifications

Sensor Type: EMCCD
# Pixels (Width): 240
# Pixels (Height): 240
Pixel Size (Square): 24 um
Peak Quantum Efficiency: 95 %
...
Data Sheet
Built for high frame rates Frame rates exceeding 1460 fps in full frame!Made for high-speed applications such as Adaptive Optics (AO) and neural and cardiac imaging, the HNü 128 camera provides exactly what is to be expected from a high-end E⁣M⁣C⁣C⁣D⁣ camera: virtually no noise. This ultimate sensitivity enables highly ...

Specifications

Sensor Type: EMCCD
# Pixels (Width): 128
# Pixels (Height): 128
Pixel Size (Square): 24 um
Peak Quantum Efficiency: 95 %
...
Data Sheet
Built for maximum sensitivity With industry-leading low-light S⁣N⁣R.⁣Made for applications requiring the ultimate sensitivity in Space & Defense, Life Sciences, Physics, Industry and many other fields, the HNü 512 camera provides exactly what is to be expected from a high-end E⁣M⁣C⁣C⁣D⁣ camera: virtually no noise. This ...

Specifications

Sensor Type: EMCCD
# Pixels (Width): 512
# Pixels (Height): 512
Pixel Size (Square): 16 um
Peak Quantum Efficiency: 95 %
...
Data Sheet
The camera uses state of the art BAE Fairchild sCMOS 4123 sensors with 0.5 electron readout noise, very low dark current and low defective pixel count. Available as monochrome or color. Thanks to the proprietary back illumination process and thermo-electric cooling, the new Hawkeye 4123 camera allows ...

Specifications

Sensor Type: sCMOS
# Pixels (Width): 4096
# Pixels (Height): 2300
Pixel Size (Square): 4.6 um
Peak Quantum Efficiency: 85 %
...
Data Sheet
e-CAM30_CUNANO is a 3.4 MP 2 lane MIPI CSI-2 custom lens camera board for NVIDIA® Jetson Nano™ developer Kit. This camera is based on 1/3\" AR0330 CMOS Image sensor from onsemi® with 2.2 µm pixel. This camera can be directly connected to camera connector (J13) on the NVIDIA® Jetson Nano™ developer Kit. ...

Specifications

Sensor Type: CMOS
# Pixels (Width): 2304
# Pixels (Height): 1536
Pixel Size (Square): 2.2 um
Peak Quantum Efficiency: 70 %
...
Data Sheet
HORIBA Scientific’s Synapse InGaAs arrays are the ideal choice for demanding, low-light-level measurements in the near infrared (NIR) spectral region from 800–1700 nm. Available in 512 × 1 (25 × 500 µm), 512 × 1 (50 × 500 µm), and 1024 × 1 (25 × 500 µm) pixel formats, these InGaAs detectors provide high resolution while maintaining ...

Specifications

Sensor Type: InGaAs Array
# Pixels (Width): 25
# Pixels (Height): 500
Pixel Size (Square): 512 um
Peak Quantum Efficiency: 85 %
...
Data Sheet
HORIBA Scientific’s Synapse Extended InGaAs arrays are the ideal choice for demanding, low-light-level measurements in the near infrared (NIR) spectral region from 1000–2200 nm. Available in 512 × 1 (25 × 250 µm), 512 × 1 (50 × 250 µm), and 1024 × 1 (25 × 250 µm) pixel formats, these InGaAs detectors provide high resolution while ...

Specifications

Sensor Type: InGaAs Array
# Pixels (Width): 25
# Pixels (Height): 250
Pixel Size (Square): 512 um
Peak Quantum Efficiency: 89 %
...
Data Sheet
Open Electrode technology allows an increased response in the UV over standard front-illuminated CCDs. in the near IR, this detector is a lower-cost alternative to the deep-depletion CCDs with no etaloning beacause of its front-illuminated design and similar signal-to-noise performance.

Specifications

Sensor Type: CCD
# Pixels (Width): 1024
# Pixels (Height): 256
Pixel Size (Square): 26 um
Peak Quantum Efficiency: 58 %
...
Data Sheet
1600 × 200 or 1600 × 400 EMCCD sensor  16 × 16 μm pixel size for high spectral resolution  25.6 × 3.2 mm or 25.6 × 6.4 mm image area  Ideal for high-speed or multi-track spectroscopy  Back- and front-illuminated  BIQX Technology with enhanced QE below 450 ...

Specifications

Sensor Type: EMCCD
# Pixels (Width): 1600
# Pixels (Height): 400
Pixel Size (Square): 16 um
Peak Quantum Efficiency: 98 %
...
Data Sheet
1600 × 200 or 1600 × 400 EMCCD sensor  16 × 16 μm pixel size for high spectral resolution  25.6 × 3.2 mm or 25.6 × 6.4 mm image area  Ideal for high-speed or multi-track spectroscopy  Back- and front-illuminated  BIQX Technology with enhanced QE below 450 ...

Specifications

Sensor Type: EMCCD
# Pixels (Width): 1600
# Pixels (Height): 200
Pixel Size (Square): 16 um
Peak Quantum Efficiency: 98 %
...
Data Sheet
2048 . 70 back-illuminated sensor  UV-Vis quantum efficiency enhancement  Deep thermoelectric cooling  Improved etaloning   16-bit digitization  Lifetime vacuum warranty

Specifications

Sensor Type: CCD
# Pixels (Width): 2048
# Pixels (Height): 70
Pixel Size (Square): 14 um
Peak Quantum Efficiency: 78 %
...
Data Sheet
The Synapse-i scientific CCD camera is the most sensitive quantitative low light imaging camera on the market. The Synapse-i imaging camera provides real image quantification for direct correlation between the image intensity and the detected number of photons. Thanks to its unique quick-change mounting flange, ...

Specifications

Sensor Type: CCD
# Pixels (Width): 1024
# Pixels (Height): 1024
Pixel Size (Square): 13 um
Peak Quantum Efficiency: - %
...
Data Sheet
The Synapse-i scientific CCD camera is the most sensitive quantitative low light imaging camera on the market. The Synapse-i imaging camera provides real image quantification for direct correlation between the image intensity and the detected number of photons. Thanks to its unique quick-change mounting flange, ...

Specifications

Sensor Type: CCD
# Pixels (Width): 512
# Pixels (Height): 512
Pixel Size (Square): 24 um
Peak Quantum Efficiency: - %
...
Data Sheet
· 1024 x 256 Front Illuminated Open Electrode sensor · Deep Thermoelectric cooling · UV transmission with Fused Silica window · 16 bit Digitization · > 58% Quantum Efficiency · > Lifetime Vacuum Warranty

Specifications

Sensor Type: CCD
# Pixels (Width): 1024
# Pixels (Height): 256
Pixel Size (Square): 26 um
Peak Quantum Efficiency: 58 %
...
Data Sheet
High Definition Color Block Camera FCB-H11
AIA
The world of HD expanded into the industrial imaging arena with the debut of Sony’s fifi rst HD block camera, the FCB-H10. Now, continuing its commitment to HD picture quality for applications that require dynamic, high resolution images that are also flfl exible, Sony is introducing the FCB-H11. This stunning new model extends ...

Specifications

Sensor Type: CMOS
# Pixels (Width): --
# Pixels (Height): --
Pixel Size (Square): -- um
Peak Quantum Efficiency: -- %
...
Data Sheet
BU2409MG 24.5MP USB3.0 CMOS Mono Camera
AIA
This BU series is an integrated-(one-body)-type camera that adopts all pixel data readout inter line CCD or CMOS. For video output and camera control, the USB3.1 Gen1 (USB3.0) interface standard is adopted for high transfer rate, and it is easy to integrate into industrial equipment.

Specifications

Sensor Type: CMOS, CCD
# Pixels (Width): 5320
# Pixels (Height): 4600
Pixel Size (Square): 2.74 um
Peak Quantum Efficiency: -- %
...
Data Sheet
Matrox Iris GTX 2000 Smart Camera
AIA
Matrox® Iris GTX is the next evolution of smart cameras from Matrox Imaging. Offering higher resolution sensors and substantially more processing power than its immediate predecessor, Matrox Iris GTX provides exceptional performance for a compact all-in-one vision system. Paired with flowchart-based Matrox Design Assistant® ...

Specifications

Sensor Type: CMOS
# Pixels (Width): 1920
# Pixels (Height): 1200
Pixel Size (Square): -- um
Peak Quantum Efficiency: -- %
...
Data Sheet
The Phantom Ultrahigh-Speed cameras deliver the fastest fps & resolution combinations for 1 Mpx high-speed sensors.

Specifications

Sensor Type: CMOS
# Pixels (Width): 1280
# Pixels (Height): 800
Pixel Size (Square): 28 um
Peak Quantum Efficiency: -- %
...
Data Sheet
The Phantom 4 Mpx Ultrahigh-Speed Series of cameras and has unparalleled image quality with a full 4 Mpx sensor for exceptional detail.

Specifications

Sensor Type: CMOS
# Pixels (Width): 2048
# Pixels (Height): 1920
Pixel Size (Square): 13.5 um
Peak Quantum Efficiency: -- %
...
Data Sheet
Prime BSI Express Scientific CMOS Camera
Crisel Instruments
The Prime BSI Express Scientific CMOS (sCMOS) is designed on a compact platform optimized for integration and delivers the perfect balance between high resolution imaging and sensitivity with an optimized pixel design, USB 3.2 Gen 2 connectivity and near perfect 95% Quantum Efficiency to maximize signal detection.

Specifications

Sensor Type: CMOS, sCMOS
# Pixels (Width): 2048
# Pixels (Height): 2048
Pixel Size (Square): 6.5 um
Peak Quantum Efficiency: 95 %
...
Data Sheet
Kinetix Scientific CMOS Camera
Crisel Instruments
Taking advantage of an 8-bit readout mode, the Kinetix sCMOS delivers a tremendous 500 frames per second (fps), full frame with a 29.4 mm diagonal field of view. The optimized line time allows the speed to significantly outperform typical sCMOS devices, delivering over 5000 megapixels/second – over a 10-fold improvement. ...

Specifications

Sensor Type: CMOS, sCMOS
# Pixels (Width): 3200
# Pixels (Height): 3200
Pixel Size (Square): 6.5 um
Peak Quantum Efficiency: 95 %
...
Data Sheet

Did You know?

Cameras are well-known optical instruments that have endless applications in recording and capturing images, such as in imaging and spectroscopy. These cameras are high-grade devices used in demanding industrial and scientific applications. Imaging cameras offer an extremely sensitive, high-resolution technology to a range of scientific fields. Imaging and Spectroscopy cameras find use in the biomedical field through hyperspectral imaging and Raman spectroscopy, in astronomy for satellite and asteroid tracking, and even find employment in vision-guided robotics.
