Page 3 - Linear Motorized Stages

Miniature Long Travel Linear Stage MMS-200
Dover Motion
Add to watch list
Miniature Long Travel Linear Stage MMS-200
Compare
The Dover Motion MMS series miniature long travel linear stage is a high performance positioner designed into a small package ideal for keeping instrument size and cost down. It’s overall height of 37mm keeps Abbe error effects to a minimum. The non-contact ironless servo motor provides high force and stable velocity with no cogging. ...

Specifications
Axes Of Motion: Two
Travel Range: 200 mm
Load Capacity (Horizontal): 12 kg
Load Capacity (Vertical): 12 kg
Max Speed: 2000 mm/s
Data Sheet
Miniature Linear Stage MMX-25
Dover Motion
Add to watch list
Miniature Linear Stage MMX-25
Compare
The Dover Motion MMX series miniature linear stage combines the ultimate in performance, reliability, and value. The high power MMX, has a higher force density to deliver 5 times the force of similar competitive products. The stage design use high precision anti-creep crossed roller guideways for extremely smooth motion, high ...

Specifications
Axes Of Motion: Two
Travel Range: 25 mm
Load Capacity (Horizontal): 10 kg
Load Capacity (Vertical): 10 kg
Max Speed: 1100 mm/s
Data Sheet
Precision Linear Motion Platform LM2-100-BS-A-H-S-F-00
Griffin Motion
Add to watch list
Precision Linear Motion Platform LM2-100-BS-A-H-S-F-00
Compare
The LM2 Series stages are designed for a variety of applications. This compact low profile linear stage is built for high duty cycles and long life and attains high velocities for factory automation and semiconductor processing equipment. This stage has exceptional levels of accuracy, repeatability, flatness and straightness. The ...

Specifications
Axes Of Motion: Three
Travel Range: 100 mm
Load Capacity (Horizontal): 1.1 kg
Load Capacity (Vertical): 4.62 kg
Max Speed: 150 mm/s
Data Sheet
Precision Linear-Rotary Stage PLR-100
Griffin Motion
Add to watch list
Precision Linear-Rotary Stage PLR-100
Compare
The linear-rotary stages are designed for high loading capacities and precise positioning to suit a variety of applications. The pneumatic dead-length collet chuck allows to collet to remain stationary axially during opening and closing. The crossed roller bearings and the linear motor offer extremely smooth operation and velocity ...

Specifications
Axes Of Motion: Three
Travel Range: 100 mm
Load Capacity (Horizontal): 7.7 kg
Load Capacity (Vertical): 14.2 kg
Max Speed: 300 mm/s
Data Sheet
MX-PLS Series Precision Linear Stages
Motion X Corp
Add to watch list
MX-PLS Series Precision Linear Stages
Compare
Motion X Corporation’s MX-PLS Series Precision Linear Stages range from standard to ultra high precision and offer the highest accuracy, pitch, yaw, roll, stiffness, straightness, repeatability, load capacity, move and settling times available. Our MX-PLS Series Precision Linear Stages are offered in either cross roller bearing ...

Specifications
Axes Of Motion: Three
Travel Range: -- mm
Load Capacity (Horizontal): -- kg
Load Capacity (Vertical): -- kg
Max Speed: -- mm/s
Data Sheet
MX-POFS Series Precision Open Frame Stages
Motion X Corp
Add to watch list
MX-POFS Series Precision Open Frame Stages
Compare
Motion X Corporation’s MX-POFS Series Precision Open Frame Stages range from standard to ultra high precision and offer the highest accuracy, pitch, yaw, roll, stiffness, straightness, repeatability, load capacity, move and settling times available. Our MX-POFS Series Precision Open Frame Stages are offered in either cross ...

Specifications
Axes Of Motion: One
Travel Range: -- mm
Load Capacity (Horizontal): -- kg
Load Capacity (Vertical): -- kg
Max Speed: -- mm/s
Data Sheet
Translation Stage VT-21L
MICRONIX USA LLC
Add to watch list
Translation Stage VT-21L
Compare
The low cost VT-21L linear stage excels in applications with very limited space due to its compact design. The stage utilizes a 2-phase stepper motor and is equipped with two mechanical limit switches. A pre-loaded ball slide creates high stiffness and superior performance. The VT-21L is available with an optional linear encoder with ...

Specifications
Axes Of Motion: One
Travel Range: 26 mm
Load Capacity (Horizontal): 1 kg
Load Capacity (Vertical): 1 kg
Max Speed: 5 mm/s
Data Sheet
Translation Stage VT-21S
MICRONIX USA LLC
Add to watch list
Translation Stage VT-21S
Compare
The low cost VT-21S linear stage excels in applications with very limited space due to its compact design. The stage utilizes a 2-phase stepper motor and is equipped with two mechanical limit switches. A pre-loaded ball slide creates high stiffness and superior performance. The VT-21S is available with an optional linear encoder with ...

Specifications
Axes Of Motion: One
Travel Range: 10 mm
Load Capacity (Horizontal): 1 kg
Load Capacity (Vertical): 1 kg
Max Speed: 5 mm/s
Data Sheet
MS30 - 8mm Miniature Translation Stage with Piezo-Electric Inertial Drive.
MechOnics AG
Add to watch list
MS30 - 8mm Miniature Translation Stage with Piezo-Electric Inertial Drive.
Compare
Miniature translation stage with piezo electric inertial drive.

Specifications
Axes Of Motion: One
Travel Range: 8 mm
Load Capacity (Horizontal): -- kg
Load Capacity (Vertical): 0.032 kg
Max Speed: 1.2 mm/s
Data Sheet
MS15 - 10mm Travel Positioner
MechOnics AG
Add to watch list
MS15 - 10mm Travel Positioner
Compare
Ultra small miniature translation stages with piezo electic inertial drive.

Specifications
Axes Of Motion: One
Travel Range: 10 mm
Load Capacity (Horizontal): 0.45 kg
Load Capacity (Vertical): 0.32 kg
Max Speed: 1.5 mm/s
Data Sheet
MS15 - 3.5mm Ultra-Small Miniature Translation Stages with Piezo Electric Inertial Drive
MechOnics AG
Add to watch list
MS15 - 3.5mm Ultra-Small Miniature Translation Stages with Piezo Electric Inertial Drive
Compare
Ultra small miniature translation stages with piezo electic inertial drive.

Specifications
Axes Of Motion: One
Travel Range: 3 mm
Load Capacity (Horizontal): 0.3 kg
Load Capacity (Vertical): 2 kg
Max Speed: 1.5 mm/s
Data Sheet
Lineax-6 Linear Motor Stage LX-6 SP
NUTEC Components Inc
Add to watch list
Lineax-6 Linear Motor Stage LX-6 SP
Compare
A linear motor driven stage suitable for applications where reliable 24/7 operation, precision positioning and ease of use are desirable characteristics. The versatile 150 mm x 46mm envelope is well suited for many instrument type machines and robotic devices. Lineax® direct drive linear motors for stage positioning exhibit ...

Specifications
Axes Of Motion: Two
Travel Range: 50-600 mm
Load Capacity (Horizontal): 15 kg
Load Capacity (Vertical): 15 kg
Max Speed: 2000 mm/s
Data Sheet
Lineax-8 Linear Motor Stage LX-8 SP
NUTEC Components Inc
Add to watch list
Lineax-8 Linear Motor Stage LX-8 SP
Compare
A brushless linear servo-motor driven stage that combines very high speed and precision sub-micron positioning. This is the perfect combination for high throughput and demanding linear motion applications. Lineax® direct drive linear motors for stage positioning exhibit advantages over conventional screw driven stages. LDirect ...

Specifications
Axes Of Motion: Two
Travel Range: 125-750 mm
Load Capacity (Horizontal): 50 kg
Load Capacity (Vertical): 50 kg
Max Speed: 3000 mm/s
Data Sheet
Lineax-10 Linear Motor Stage LX-10-SP
NUTEC Components Inc
Add to watch list
Lineax-10 Linear Motor Stage LX-10-SP
Compare
A powerful precision stage integrating modern positioning technology with robust payload capability, expanding the high precision performance envelope to include high payload and long travel applications. Lineax® direct drive linear motors for stage positioning exhibit advantages over conventional screw driven stages. Direct ...

Specifications
Axes Of Motion: One
Travel Range: 300-1250 mm
Load Capacity (Horizontal): 50 kg
Load Capacity (Vertical): 50 kg
Max Speed: 3000 mm/s
Data Sheet
Sensapex Micromanipulator
Npi electronic GmbH
Add to watch list
Sensapex Micromanipulator
Compare
Smallest fully featured Micromanipulator provides  20 mm of precise piezo movement in all three/four axes!

Specifications
Axes Of Motion: Three
Travel Range: 20 mm
Load Capacity (Horizontal): 0.150 kg
Load Capacity (Vertical): 0.150 kg
Max Speed: 5 mm/s
Data Sheet
M3-LS-3.4-15 LINEAR SMART STAGE
New Scale Technologies Inc
Add to watch list
M3-LS-3.4-15 LINEAR SMART STAGE
Compare
The M3-LS-3.4-15 is a direct-drive precision piezoelectric micro stage with embedded controller, designed for integration into compact instruments. With long travel and 100 gram vertical load capacity, it has 0.5 m resolution for precise, repeatable positioning of optics, probes, sensors and more. Absolute encoding means there is no ...

Specifications
Axes Of Motion: Two
Travel Range: 15 mm
Load Capacity (Horizontal): 0.2 kg
Load Capacity (Vertical): 0.1 kg
Max Speed: 4 mm/s
Data Sheet
Ultra-thin Motorized Linear Stage - PG413 (Integrated Linear Ball Guide)
SURUGA SEIKI
Add to watch list
Ultra-thin Motorized Linear Stage - PG413 (Integrated Linear Ball Guide)
Compare
Suruga Seiki\'s PG Series linear motorized translation stages are a great fit for applications which require a good accuracy combined with a relatively large travel range. These motorized translation stages are particularly popular in laser optics, spectroscopy, microscopy, and metrology applications. Whether you are working in an ...

Specifications
Axes Of Motion: One
Travel Range: 13 mm
Load Capacity (Horizontal): 10 kg
Load Capacity (Vertical): 3 kg
Max Speed: 10 mm/s
...
Data Sheet
Ultra-thin XY-Axis Motorized Linear Stage - PMG413 (Integrated Linear Ball Guide)
SURUGA SEIKI
Add to watch list
Ultra-thin XY-Axis Motorized Linear Stage - PMG413 (Integrated Linear Ball Guide)
Compare
Suruga Seiki\'s PG Series linear motorized translation stages are a great fit for applications which require a good accuracy combined with a relatively large travel range. These motorized translation stages are particularly popular in laser optics, spectroscopy, microscopy, and metrology applications. Whether you are working in an ...

Specifications
Axes Of Motion: Two
Travel Range: 13 mm
Load Capacity (Horizontal): 9.5 kg
Load Capacity (Vertical): 2.85 kg
Max Speed: 10 mm/s
...
Data Sheet
Ultra-thin Z-Axis Motorized Linear Stage - PZG413 (Integrated Linear Ball Guide)
SURUGA SEIKI
Add to watch list
Ultra-thin Z-Axis Motorized Linear Stage - PZG413 (Integrated Linear Ball Guide)
Compare
Suruga Seiki\'s PG Series linear motorized translation stages are a great fit for applications which require a good accuracy combined with a relatively large travel range. These motorized translation stages are particularly popular in laser optics, spectroscopy, microscopy, and metrology applications. Whether you are working in an ...

Specifications
Axes Of Motion: One
Travel Range: 13 mm
Load Capacity (Horizontal): - kg
Load Capacity (Vertical): 5 kg
Max Speed: 10 mm/s
...
Data Sheet
Ultra-thin XYZ-Axis Motorized Linear Stage - PMZG413 (Integrated Linear Ball Guide)
SURUGA SEIKI
Add to watch list
Ultra-thin XYZ-Axis Motorized Linear Stage - PMZG413 (Integrated Linear Ball Guide)
Compare
Suruga Seiki\'s PG Series linear motorized translation stages are a great fit for applications which require a good accuracy combined with a relatively large travel range. These motorized translation stages are particularly popular in laser optics, spectroscopy, microscopy, and metrology applications. Whether you are working in an ...

Specifications
Axes Of Motion: Three
Travel Range: 13 mm
Load Capacity (Horizontal): - kg
Load Capacity (Vertical): 5 kg
Max Speed: 10 mm/s
...
Data Sheet
[Cave-X Positioner] Motorized Linear Stage - KXG06020 (Linear Ball Guide)
SURUGA SEIKI
Add to watch list
[Cave-X Positioner] Motorized Linear Stage - KXG06020 (Linear Ball Guide)
Compare
Suruga Seiki\'s Cave-X linear motorized translation stages are a great fit for applications which require a good accuracy combined with a relatively large travel range. These motorized translation stages are particularly popular in laser optics, spectroscopy, microscopy, and metrology applications. Whether you are working in an ...

Specifications
Axes Of Motion: One
Travel Range: 20 mm
Load Capacity (Horizontal): 5 kg
Load Capacity (Vertical): 1.5 kg
Max Speed: 20 - 30 mm/s
...
Data Sheet
[Cave-X Positioner] XY-Axis Motorized Linear Stage - KYG06020 (Linear Ball Guide)
SURUGA SEIKI
Add to watch list
[Cave-X Positioner] XY-Axis Motorized Linear Stage - KYG06020 (Linear Ball Guide)
Compare
Suruga Seiki\'s Cave-X 2-axes linear motorized translation stages are a great fit for applications which require a good accuracy combined with a relatively large travel range. These motorized translation stages are particularly popular in laser optics, spectroscopy, microscopy, and metrology applications. Whether you are working in ...

Specifications
Axes Of Motion: Two
Travel Range: 20 mm
Load Capacity (Horizontal): 4 kg
Load Capacity (Vertical): 1.2 kg
Max Speed: 20 - 30 mm/s
...
Data Sheet
[Cave-X Positioner] Z-Axis Motorized Linear Stage - KZG06020 (Linear Ball Guide)
SURUGA SEIKI
Add to watch list
[Cave-X Positioner] Z-Axis Motorized Linear Stage - KZG06020 (Linear Ball Guide)
Compare
Suruga Seiki\'s Cave-X linear motorized translation stages are a great fit for applications which require a good accuracy combined with a relatively large travel range. These motorized translation stages are particularly popular in laser optics, spectroscopy, microscopy, and metrology applications. Whether you are working in an ...

Specifications
Axes Of Motion: One
Travel Range: 20 mm
Load Capacity (Horizontal): - kg
Load Capacity (Vertical): 3 kg
Max Speed: 20 - 30 mm/s
...
Data Sheet
[Cave-X Positioner] XYZ-Axis Motorized Linear Stage - KWG06020 (Linear Ball Guide)
SURUGA SEIKI
Add to watch list
[Cave-X Positioner] XYZ-Axis Motorized Linear Stage - KWG06020 (Linear Ball Guide)
Compare
Suruga Seiki\'s Cave-X 3-axes linear motorized translation stages are a great fit for applications which require a good accuracy combined with a relatively large travel range. These motorized translation stages are particularly popular in laser optics, spectroscopy, microscopy, and metrology applications. Whether you are working in ...

Specifications
Axes Of Motion: Three
Travel Range: 20 mm
Load Capacity (Horizontal): - kg
Load Capacity (Vertical): 3 kg
Max Speed: 20 - 30 mm/s
...
Data Sheet
[Cave-X Positioner] Motorized Linear Stage - KXL06100 (Linear Ball Guide)
SURUGA SEIKI
Add to watch list
[Cave-X Positioner] Motorized Linear Stage - KXL06100 (Linear Ball Guide)
Compare
Suruga Seiki\'s Cave-X linear motorized translation stages are a great fit for applications which require a good accuracy combined with a relatively large travel range. These motorized translation stages are particularly popular in laser optics, spectroscopy, microscopy, and metrology applications. Whether you are working in an ...

Specifications
Axes Of Motion: One
Travel Range: 100 mm
Load Capacity (Horizontal): 12 kg
Load Capacity (Vertical): 4 kg
Max Speed: 45 mm/s
...
Data Sheet
