Mx Series Motorized Multi-Axis Positioning Systems

Name: Mx Series Motorized Multi-Axis Positioning Systems
Brand: Zolix Instruments CO.,LTD

Description

The Mx series motorized positioning systems by Zolix are designed to provide flexible adjustments and precise positioning in limited spaces.

These systems are based on four-axis or more-axis motorized combinations, offering high integration and customization options. They are ideal for applications such as fine optical path alignment and person posture simulation.

Specifications

Axes Of Motion:	Three
Travel Range:	400 mm
Load Capacity (Horizontal):	10 kg
Load Capacity (Vertical):	Not Specified
Max Speed:	10 mm/s
Weight:	Not Specified
Guiding Mechanism:	Other
Voltage Requirement:	Other

Got questions about specs? Use the inquiry form to ask.

Download Data Sheet

Features

High degree of integration
More than 6-axis systems available
Modular design for easy maintenance
Customization options for specific requirements

Applications

Fine optical path alignment
Person posture simulation
Robotics and automation
Biomedical research
Microscopy and imaging
Semiconductor testing

Request Quote

To: Zolix Instruments CO.,LTD
Re: Mx Series Motorized Multi-Axis Positioning Systems

Name

Work Email

Organization

Country

Your message to supplier

Thank you, your message was sent successfully.

Ships from:: China
Sold by:: Zolix Instruments CO.,LTD ✓ Verified Supplier
On FindLight:: since 2020

Why contact via FindLight?

Message the supplier directly
No signup or account needed
No FindLight fees or markups
Expect a fast reply
Autofill forms with a Buyer Account

Frequently Asked Questions

What is the Mx series motorized multi-axis positioning system?

The Mx series motorized multi-axis positioning system is a product designed and manufactured by Zolix. It offers flexible adjustments and positioning in limited space, with the ability to control more than 6 axes.

What are the design features of the multi-axis positioning system?

The multi-axis positioning system is designed to create a direct coupling between the carrying motors and the load. It minimizes backlash, enables rapid acceleration, and allows for high-speed operation.

What are the attributes of the multi-axis motorized stage?

The multi-axis motorized stage has a special compact construction that consolidates several degrees of freedom, including both linear and rotational motions. It is capable of high-speed accurate positioning along 6 or more axes and features high repeatability.

What models are available for the multi-axis positioning systems?

Zolix offers two distinct models of multi-axis positioning systems: the M8-400R and the M7-600R15. Both models have different travel ranges and axis configurations.

What are the typical applications of the multi-axis positioning systems?

The multi-axis positioning systems are ideal for situations where a load needs to be moved in more than 3 directions, such as fine optical path alignment and simulation of person postures. They can also be used for precise alignment of optomechanics, photonics equipment, lasers, semiconductors, and precision mechanics.
