Thumbnail of NNS-XY100RZ2-01 High Precision XYZ-axis Nano Positioning Stage photo 1

Description

NNS-Z50-01 is a Z-axis motion stage, the closed loop travel range is 50μm ,the closed loop resolution is 0.5nm. It has the characteristics of high load, high resonant frequency and high bandwidth. The surface is black anodized for optical applications. This stage can be side-mounted.

NNS-XY100RZ2-01 High Precision XYZ-axis Nano Positioning Stage

Sanying MotionControl Instruments Ltd.

Specifications

Axes Of Motion: Three
Travel Range: 0.1 mm
Load Capacity (Horizontal): Not Specified
Load Capacity (Vertical): Not Specified
Max Speed: Not Specified
Weight: 1.1 kg
Guiding Mechanism: Other
Voltage Requirement: Other

Got questions about specs? Use the inquiry form to ask.

Document icon Download Data Sheet Download icon

Features

  • Range 100μm/100μm/±1mrad
  • Close-loop resolution up to 0.5nm/0.5nm/0.1μrad

Applications

  • Optical Microscopy
  • Optical Metrology
  • Laser Processing
  • High-precision Autofocus
  • Objective turret adjustment and scanning
