Introducing the NS-XY100-02 XY-axis Nano Positioning Stage with Vacuum Chuck
The NS-XY100-02 is a state-of-the-art, high-precision two-dimensional nano-positioning stage that is meticulously designed for ultra-precision motion control applications. This advanced piece of equipment is crafted by Sanying Motion Control Instruments Ltd., a professional manufacturer renowned for their expertise in ultra-precision motion control products. The NS-XY100-02 is engineered to deliver exceptional performance with a closed-loop travel range that extends up to 100x100 μm, ensuring precise and reliable positioning for demanding tasks.
At the heart of the NS-XY100-02 is its integrated vacuum chuck, which provides a stable and secure platform for various applications. The stage is capable of supporting loads up to 1 kg, making it versatile for a wide range of industrial and scientific applications. The closed-loop resolution of up to 0.5 nm guarantees unparalleled precision, making it an ideal choice for environments where accuracy is paramount.
Designed to meet the rigorous demands of modern industries, the NS-XY100-02 excels in environments that require meticulous surface inspection, optical microscopy, and laser technology. It is also perfectly suited for semiconductor processing and testing, as well as high-density optical and magnetic storage applications. The combination of precision, reliability, and versatility makes the NS-XY100-02 an indispensable tool for professionals seeking to enhance their operational capabilities.
Manufactured by Sanying Motion Control Instruments Ltd., the NS-XY100-02 embodies the company's commitment to quality and innovation. For more information, you can reach out to their team at marketing@symc-tec.com. Located at Building 8, 38 Fuyuan Road, Wuqing Development Area, Tianjin, China, Sanying Motion Control Instruments Ltd. continues to lead the industry with cutting-edge solutions tailored to meet the evolving needs of their clients.
NS-XY100-02 XY-axis Nano Positioning Stage with Vacuum Chuck
Specifications |
|
|---|---|
| Axes Of Motion: | Two |
| Travel Range: | 0.1 mm |
| Load Capacity (Horizontal): | 1 kg |
| Weight: | 1.21 kg |
| Guiding Mechanism: | Other |
| Voltage Requirement: | Other |
| Range: | 100 μm |
| Load: | 1 kg |
| Close-loop Resolution: | 0.5 nm |
| Closed Loop Travel Range: | 100 x 100 μm |
| Closed Loop Resolution: | 0.5/0.5 nm |
Features
- Model: NS-XY100-02
- Type: XY-axis Nano Positioning Stage with Vacuum Chuck
- Range: 100 μm
- Load Capacity: 1 kg
- Close-loop Resolution: Up to 0.5 nm
Applications
- Surface Inspection
- Optical Microscopy
- Laser Technology
- Semi-conductor Processing and Testing
- High Density Optical and Magnetic Storage
Frequently Asked Questions
The NS-XY100-02 is a high-precision two-dimensional nano-positioning stage with an integrated vacuum chuck, designed for ultra-precision motion control applications.
The NS-XY100-02 has a closed-loop travel range of 100 x 100 μm.
The NS-XY100-02 can support a load of up to 1 kg.
The NS-XY100-02 has a closed-loop resolution of up to 0.5 nm.
The NS-XY100-02 is used in surface inspection, optical microscopy, laser technology, semiconductor processing and testing, and high-density optical and magnetic storage.
The NS-XY100-02 is manufactured by Sanying Motion Control Instruments Ltd., a professional manufacturer of ultra-precision motion control products.
