Water Power Sensors

The HP400A-100KW-HD-TUBE-D0 is a robust high-power detector designed for precise laser power measurement, capable of handling power levels up to 100,000 W. With its impressive measurement capabilities and reliability, it is an essential tool for high-power laser applications.

Specifications

Max Average Power: 100000 W
Effective Aperture: 400 mm
Spectral Range: 0.19-20um
Cooling Method: Water
Minimum Average Power: 4000 W
...
Gentec-EO offers a power detector for measuring laser powers in the range from 600W - 2500W. UP-HD series power meters can be used in a wide range of applications for detecting light from deep ultraviolet (DUV) to far infrared (FIR).

Specifications

Max Average Power: 2500 W
Effective Aperture: 55 mm
Spectral Range: 0.19-20um
Cooling Method: Water
Noise Equivalent Power: 200 mW
...
Gentec-EO offers a power detector for measuring high or super high laser powers in the range from 100W - 12,000W. HP series detectors can be used in a wide range of applications for detecting light from deep ultraviolet (DUV) to far infrared (FIR).

Specifications

Max Average Power: 4000 W
Effective Aperture: 100 mm
Spectral Range: 0.19-20um
Cooling Method: Water
Max Average Power (2 Minutea): 4500 W
Gentec-EO offers a power detector for measuring high or super high laser powers in the range from 100W - 12,000W. HP series power meters can be used in a wide range of applications for detecting light from deep ultraviolet (DUV) to far infrared (FIR).

Specifications

Max Average Power: 12000 W
Effective Aperture: 100 mm
Spectral Range: 0.19-20um
Cooling Method: Water
Gentec-EO offers a power detector for measuring high or super high laser powers in the range from 100W - 12,000W. HP series power meters can be used in a wide range of applications for detecting light from visible (VIS) to mid infrared (MIR).

Specifications

Max Average Power: 10000 W
Effective Aperture: 100 mm
Spectral Range: 0.8-12um
Cooling Method: Water
Gentec-EO offers a power detector for measuring laser powers in the range from 600W - 2500W. UP-HD series power meters can be used in a wide range of applications for detecting light from deep ultraviolet (DUV) to far infrared (FIR).

Specifications

Max Average Power: 700 W
Effective Aperture: 55 mm
Spectral Range: 0.19-20um
Cooling Method: Water
Noise Equivalent Power: 45 mW
...
Gentec-EO offers UP19-W series laser power detectors for laboratory and industrial applications.

Specifications

Max Average Power: 50 W
Effective Aperture: 17 mm
Spectral Range: 0.19-10um
Cooling Method: Water
Max Average Power (1 Minute): 85 W
The Gentec-EO Ultra Series UP power detector family includes thirteen series (XLP12, UP12E, UP10K(P), UP17P, UP19K, UP25N(M), UP25T, UP50N(M), UP55N(M), UP55C, UP60N(M), UP55G, and UP60G) of opto-thermal sensors with different cooling options (stand alone, heat sink, fan and water), with or without amplification. The high-power ...

Specifications

Max Average Power: 350 W
Effective Aperture: 25 mm
Spectral Range: 0.19-20um
Cooling Method: Water
Max Output Signal: N. A.
...
Gentec-EO offers UP55H series high power detectors.

Specifications

Max Average Power: 200 W
Effective Aperture: 55 mm
Spectral Range: 0.3-2.5um
Cooling Method: Water
Gentec-EO offers UP50 series high power detectors for industrial and laboratory applications.

Specifications

Max Average Power: 50 W
Effective Aperture: 50 mm
Spectral Range: 0.19-10um
Cooling Method: Water
Max Average Power (1 Minute): 85 W
The Gentec-EO UP series of laser power detectors include seven families (XLP12, UP12, UP10, UP17, UP19, UP25, UP55) of opto-thermal sensors with different cooling options (stand alone, heat sink, fan and water), with or without amplification.  The high power surface absorber sensors are designed for use at high average power ...

Specifications

Max Average Power: 70 W
Effective Aperture: 12 mm
Spectral Range: 0.19-20um
Cooling Method: Water, Heatsink
The UP12E-20H-H5-D0 is a high-quality thermal detector designed for precise laser power measurement applications. With a maximum continuous power handling capacity of 20 W, this detector provides accurate and reliable results across a broad spectral range. Its exceptional sensitivity and fast response time make it an ideal choice for ...

Specifications

Max Average Power: 40 W
Effective Aperture: 12 mm
Spectral Range: 0.19-20um
Cooling Method: Water, Heatsink
Maximum Average Power (continuous): 20 W
...
The Gentec-EO UP series of laser power detectors include seven families (XLP12, UP12, UP10, UP17, UP19, UP25, UP55) of opto-thermal sensors with different cooling options (stand alone, heat sink, fan and water), with or without amplification.  The high power surface absorber sensors are designed for use at high average power ...

Specifications

Max Average Power: 200 W
Effective Aperture: 19 mm
Spectral Range: 0.19-20um
Cooling Method: Water, Heatsink, Fan-cooled
The Gentec-EO UP series of laser power detectors include seven families (XLP12, UP12, UP10, UP17, UP19, UP25, UP55) of opto-thermal sensors with different cooling options (stand alone, heat sink, fan and water), with or without amplification.  The high power surface absorber sensors are designed for use at high average power ...

Specifications

Max Average Power: 150 W
Effective Aperture: 19 mm
Spectral Range: 0.19-20um
Cooling Method: Water, Heatsink, Fan-cooled
The UP19K-110F-H9-D0 is a high-performance thermal detector designed for laser power measurement up to 110 W. It offers a compact design, fast rise time, and a high damage threshold. With its modular concept, it provides flexibility in increasing the power capability of the detector. The detector is equipped with a smart interface ...

Specifications

Max Average Power: 110 W
Effective Aperture: 19 mm
Spectral Range: 0.19-20um
Cooling Method: Water, Heatsink, Fan-cooled
Dimensions: 50H x 50W x 63D mm
...
The UP19K-50L-H5-D0 is a highly efficient thermal detector designed for laser power measurement, capable of handling powers up to 50 W. With a modular concept and five different cooling modules, it offers versatility and power capability. This detector boasts high performance with a fast rise time of 0.6 seconds and a high damage ...

Specifications

Max Average Power: 50 W
Effective Aperture: 19 mm
Spectral Range: 0.19-20um
Cooling Method: Water, Heatsink, Fan-cooled
Noise Equivalent Power: 1.0 mW
...
The UP19K-30H-H5-D0 is a high-performance thermal detector designed for accurate laser power measurement. With a maximum capacity of 30 W, it provides precise and reliable measurements in a compact form factor. This detector is ideal for a wide range of laser applications and offers exceptional sensitivity.

Specifications

Max Average Power: 60 W
Effective Aperture: 19 mm
Spectral Range: 0.19-20um
Cooling Method: Water, Heatsink, Fan-cooled
Maximum Average Power (continuous): 30 W
...
The Gentec-EO HP280A-30KW-HD-IMP-D0 is a high-power detector designed for laser power measurement up to 30,000 W. With traceable calibration and award-winning technology, this wireless detector ensures accurate and reliable readings.  Its compact design, coupled with BLU wireless output, allows measurements in enclosures or ...

Specifications

Max Average Power: 30000 W
Effective Aperture: 280 mm
Spectral Range: 0.19-20um
Cooling Method: Water
Minimum Average Power: 1000 W
...
The Gentec-EO Super HP Laser Power Detector is a high-power solution for accurate laser power measurement. With customizable models handling up to 100,000 W of continuous power, it offers stability in readings, especially in water cooling variations. Its compact and lightweight design, unique to the market, comes with infinite ...

Specifications

Max Average Power: 25000 W
Effective Aperture: 210 mm
Spectral Range: 0.19-20um
Cooling Method: Water
Noise Equivalent Power: ±20 W
...
The Gentec HP100A-12KW-HD-TUBE-IMP-D0 is an advanced high-power detector designed for precise laser power measurements, capable of handling powers up to an impressive 12,000 W. Featuring an extension tube to reduce back reflections, this detector is ideal for applications requiring high-power lasers. With exceptional accuracy, ...

Specifications

Max Average Power: 12000 W
Effective Aperture: 125 mm
Spectral Range: 0.19-20um
Cooling Method: Water
Minimum Average Powe: 300 W
...
The Gentec HP125A-15KW-HD-IMP-D0 is a cutting-edge high-power detector meticulously crafted for precise laser power measurements, accommodating powers up to an impressive 15,000 W. Engineered with advanced features such as traceable calibration, water cooling, and a high-damage threshold, this detector ensures accurate and reliable ...

Specifications

Max Average Power: 15000 W
Effective Aperture: 125 mm
Spectral Range: 0.19-20um
Cooling Method: Water
Minimum Average Power: 500 W
...
The Gentec-EO HP Series power detector family includes HP100A-4KW-HE, HP60A-10KW-GD and HP100A-12KW-HD, HP125A-15KW-HD. The HP detectors can measure between - 100 W and 4 KW of average power for HP100A-4KW-HE & HP100A-4KW-HE-TUBE - 300 W and 10 KW of average power for HP60A-10KW-GD - 300 Wand 12 KW of average power for ...

Specifications

Max Average Power: 4000 W
Effective Aperture: 125 mm
Spectral Range: 0.19-20um
Cooling Method: Water
Achieve precision in laser power measurement with the Gentec IS50A-1KW-RSI-INT-D0 Water-Cooled Integrating Sphere Detector. Designed for applications requiring laser power measurements up to 1000 W, this detector combines water cooling and integrating sphere technology to deliver accurate and reliable results. The award-winning ...

Specifications

Max Average Power: 1000 W
Effective Aperture: 50 mm
Spectral Range: 0.34-1.1um
Cooling Method: Water
Noise Equivalent Power: 10 μW
...
HP60A-15KW-GD-QBH is a Power Detector for High Power Lasers (up to 15 kW). It works well for fiber lasers. This new laser power detector is ideal for measuring average laser power for burn-in tests over long periods of time or for quick on the field applications with the simplicity of connecting a fiber laser output directly to the ...

Specifications

Max Average Power: 15000 W
Effective Aperture: 70 mm
Spectral Range: 0.8-12um
Cooling Method: Water
Weight: 16 kg
...
The Gentec-EO UP series of laser power detectors include seven families (XLP12, UP12, UP10, UP17, UP19, UP25, UP55) of opto-thermal sensors with different cooling options (stand alone, heat sink, fan and water), with or without amplification.  The high power surface absorber sensors are designed for use at high average power ...

Specifications

Max Average Power: 500 W
Effective Aperture: 55 mm
Spectral Range: 0.19-20um
Cooling Method: Water, Heatsink, Fan-cooled
