Page 4 - Pulsed DPSS Lasers

AONano 355-12W-30K ND:YV04 UV Laser
Advanced Optowave Corporation
Add to watch list
AONano 355-12W-30K ND:YV04 UV Laser
Compare
AWAVE UV Series models are Q-switched TEM00 mode lasers and are engineered for the highly demanding 24/7 production environment. Each system consists of a laser head and a laser controller connected with a 2.5 meter umbilical cable. The fiber-coupled pumping diodes are located in the laser controller for easy field-replacement. The ...

Specifications
Avg. Power: 12 W
Wavelength: 355 nm
Repetition Rate: 0-300kHz
Spatial Mode (M^2): 1.2
Pulse Duration: 15 ns
...
Data Sheet
FPYL-532-XXXT-Q DPSS Laser
Frankfurt Laser Company
Add to watch list
FPYL-532-XXXT-Q DPSS Laser
Compare
FLC offers a wide range of diode-pumped solid state laser products, the smallest DPSS laser heads, low cost modules, low power and high power laser systems and high quality single longitudinal mode laser systems with different power output and wavelengths.

Specifications
Avg. Power: 0.5 W
Wavelength: 532 nm
Repetition Rate: 4-6kHz
Spatial Mode (M^2): <1.5
Pulse Duration: ~1.3 ns
...
Data Sheet
Green High Power Q-switched DPSS Laser FPYL-532-30W-Q
Frankfurt Laser Company
Add to watch list
Green High Power Q-switched DPSS Laser FPYL-532-30W-Q
Compare
The FPYL-532-30W-Q is a high-power green DPSS (Diode-Pumped Solid-State) laser featuring Q-switched operation. With a wavelength of 532nm and an average power output of 30W at 10kHz repetition rate, this laser provides a powerful and precisely controlled pulsed laser beam. It offers a pulse duration of approximately 100ns and a peak ...

Specifications
Avg. Power: 30 W
Wavelength: 532 nm
Repetition Rate: 10-20kHz
Spatial Mode (M^2): --
Pulse Duration: 100 ns
...
Data Sheet
AONano 355-10W-30K ND:YV04 UV Laser
Advanced Optowave Corporation
Add to watch list
AONano 355-10W-30K ND:YV04 UV Laser
Compare
AWAVE UV Series models are Q-switched TEM00 mode lasers and are engineered for the highly demanding 24/7 production environment. Each system consists of a laser head and a laser controller connected with a 2.5 meter umbilical cable. The fiber-coupled pumping diodes are located in the laser controller for easy field-replacement. The ...

Specifications
Avg. Power: 10 W
Wavelength: 355 nm
Repetition Rate: 0-300kHz
Spatial Mode (M^2): 1.2
Pulse Duration: 20 ns
...
Data Sheet
AONano 355-6W-30K ND:YV04 UV Laser
Advanced Optowave Corporation
Add to watch list
AONano 355-6W-30K ND:YV04 UV Laser
Compare
AWAVE UV Series models are Q-switched TEM00 mode lasers and are engineered for the highly demanding 24/7 production environment. Each system consists of a laser head and a laser controller connected with a 2.5 meter umbilical cable. The fiber-coupled pumping diodes are located in the laser controller for easy field-replacement. The ...

Specifications
Avg. Power: 6 W
Wavelength: 355 nm
Repetition Rate: 0-300kHz
Spatial Mode (M^2): 1.2
Pulse Duration: 15 ns
...
Data Sheet
FPYL-1064-001-100W-Q DPSS Laser
Frankfurt Laser Company
Add to watch list
FPYL-1064-001-100W-Q DPSS Laser
Compare
FLC offers a wide range of diode-pumped solid state laser products, the smallest DPSS laser heads, low cost modules, low power and high power laser systems and high quality single longitudinal mode laser systems with different power output and wavelengths.

Specifications
Avg. Power: 100 W
Wavelength: 1064 nm
Repetition Rate: 400-2000kHz
Spatial Mode (M^2): 1.2
Pulse Duration: 0.01 ns
...
Data Sheet
FPYL-1064-10J-Q DPSS Laser
Frankfurt Laser Company
Add to watch list
FPYL-1064-10J-Q DPSS Laser
Compare
FLC offers a wide range of diode-pumped solid state laser products, the smallest DPSS laser heads, low cost modules, low power and high power laser systems and high quality single longitudinal mode laser systems with different power output and wavelengths.

Specifications
Avg. Power: 200 W
Wavelength: 1064 nm
Repetition Rate: 0.001-0.020kHz
Spatial Mode (M^2): --
Pulse Duration: 100000 ns
...
Data Sheet
SOL 10W-1064nm: 1064nm Nanosecond Laser
RPMC Lasers, Inc.
Add to watch list
SOL 10W-1064nm: 1064nm Nanosecond Laser
Compare
The SOL series is the most compact, air-cooled, Q-switched DPSS nanosecond laser available in the power range from 4W to 40W @ 1064nm. Available @ 1064nm, 532nm, and 355nm, the SOL laser series offers excellent beam quality and high peak power, capable of up to 10W and 650µJ at 532nm and 4W @ 355nm, making it the ideal source ...

Specifications
Avg. Power: 10 W
Wavelength: 1064 nm
Repetition Rate: 1-100kHz
Spatial Mode (M^2): 2
Pulse Duration: 10 ns
...
Data Sheet
SOL 6W-1064nm: 1064nm Nanosecond Laser
RPMC Lasers, Inc.
Add to watch list
SOL 6W-1064nm: 1064nm Nanosecond Laser
Compare
The SOL series is the most compact, air-cooled, Q-switched DPSS nanosecond laser available in the power range from 4W to 40W @ 1064nm. Available @ 1064nm, 532nm, and 355nm, the SOL laser series offers excellent beam quality and high peak power, capable of up to 10W and 650µJ at 532nm and 4W @ 355nm, making it the ideal source ...

Specifications
Avg. Power: 6 W
Wavelength: 1064 nm
Repetition Rate: 0.001-100kHz
Spatial Mode (M^2): 1.5
Pulse Duration: 15 ns
...
Data Sheet
SOL 30W-1064nm: 1064nm Nanosecond Laser
RPMC Lasers, Inc.
Add to watch list
SOL 30W-1064nm: 1064nm Nanosecond Laser
Compare
The SOL series is the most compact, air-cooled, Q-switched DPSS nanosecond laser available in the power range from 4W to 40W @ 1064nm. Available @ 1064nm, 532nm, and 355nm, the SOL laser series offers excellent beam quality and high peak power, capable of up to 10W and 650µJ at 532nm and 4W @ 355nm, making it the ideal source ...

Specifications
Avg. Power: 30 W
Wavelength: 1064 nm
Repetition Rate: 0.001-100kHz
Spatial Mode (M^2): 1.5
Pulse Duration: 7 ns
...
Data Sheet
SOL 20W-1064nm: 1064nm Nanosecond Laser
RPMC Lasers, Inc.
Add to watch list
SOL 20W-1064nm: 1064nm Nanosecond Laser
Compare
The SOL series is the most compact, air-cooled, Q-switched DPSS nanosecond laser available in the power range from 4W to 40W @ 1064nm. Available @ 1064nm, 532nm, and 355nm, the SOL laser series offers excellent beam quality and high peak power, capable of up to 10W and 650µJ at 532nm and 4W @ 355nm, making it the ideal source ...

Specifications
Avg. Power: 20 W
Wavelength: 1064 nm
Repetition Rate: 0.001-100kHz
Spatial Mode (M^2): 2.5
Pulse Duration: 10 ns
...
Data Sheet
SOL 40W-1064nm: 1064nm Nanosecond Laser
RPMC Lasers, Inc.
Add to watch list
SOL 40W-1064nm: 1064nm Nanosecond Laser
Compare
The SOL series is the most compact, air-cooled, Q-switched DPSS nanosecond laser available in the power range from 4W to 40W @ 1064nm. Available @ 1064nm, 532nm, and 355nm, the SOL laser series offers excellent beam quality and high peak power, capable of up to 10W and 650µJ at 532nm and 4W @ 355nm, making it the ideal source ...

Specifications
Avg. Power: 40 W
Wavelength: 1064 nm
Repetition Rate: 0.001-100kHz
Spatial Mode (M^2): 2.5
Pulse Duration: 5 ns
...
Data Sheet
Wedge HF 1064nm: 1064nm Picosecond Laser
RPMC Lasers, Inc.
Add to watch list
Wedge HF 1064nm: 1064nm Picosecond Laser
Compare
Wedge family has been fully renewed in terms of  performances and available models. Wedge HB is available both at 1064nm and at 532 nm; pulse energy can reach 4 mJ in 1 ns. Wedge-HF and Wedge-XF are now available in a very  compact unit, only 8x9x19 cm, both at 1064nm and  532nm. Repetition rate can ...

Specifications
Avg. Power: 4 W
Wavelength: 1064 nm
Repetition Rate: 10-100kHz
Spatial Mode (M^2): 1.5
Pulse Duration: 1.5 ns
...
Data Sheet
Wedge HF 266nm: 266nm Picosecond Laser
RPMC Lasers, Inc.
Add to watch list
Wedge HF 266nm: 266nm Picosecond Laser
Compare
The Wedge-HF laser is a sub-nanosecond, single shot to 100kHz DPSS laser capable of up to 4W of average power at 1064nm and is available with harmonics options at 532nm, 355nm and 266nm. Second, third and fourth harmonics options (532, 355 and 266nm) and wavelength conversion option (1.5um) widen the Wedge’s applications ...

Specifications
Avg. Power: 0.180 W
Wavelength: 266 nm
Repetition Rate: 10-100kHz
Spatial Mode (M^2): 1.5
Pulse Duration: 1.5 ns
...
Data Sheet
Wedge HF 355nm: 355nm Picosecond Laser
RPMC Lasers, Inc.
Add to watch list
Wedge-HF-355: 355nm Picosecond Laser
Compare
Wedge family has been fully renewed in terms of performances and available models.    Wedge HB and XB models are currently available at 1064nm, 1570nm, 3100nm, 532nm, 355nm and 266nm. laser pulse energy reaches 4 mJ with 1.5 ns pulse width. Wedge-HF and Wedge-XF models are available in a very compact unit, only 8x9x19 ...

Specifications
Avg. Power: 0.8 W
Wavelength: 355 nm
Repetition Rate: 10-100kHz
Spatial Mode (M^2): 1.5
Pulse Duration: 0.6 ns
...
Data Sheet
Wedge XF 532nm: 532nm Picosecond Laser
RPMC Lasers, Inc.
Add to watch list
Wedge XF 532nm: 532nm Picosecond Laser
Compare
Wedge XF sub-nanosecond (300ps), DPSS laser produces up to 70uJ of pulse energy at 1064nm, with operation from single shot to 100 kHz, in a compact, air-cooled OEM solution. Second, Third and Fourth Harmonics (532, 355 and 266nm output) and wavelength conversion option (1.5um) widen the suitable applications range for the ...

Specifications
Avg. Power: 0.5 W
Wavelength: 532 nm
Repetition Rate: 10-100kHz
Spatial Mode (M^2): 1.3
Pulse Duration: 0.4 ns
...
Data Sheet
Wedge XF 1064nm: 1064nm Picosecond Laser
RPMC Lasers, Inc.
Add to watch list
Wedge XF 1064nm: 1064nm Picosecond Laser
Compare
Wedge XF sub-nanosecond (300ps), DPSS laser produces up to 70uJ of pulse energy at 1064nm, with operation from single shot to 100 kHz, in a compact, air-cooled OEM solution. Second, Third and Fourth Harmonics (532, 355 and 266nm output) and wavelength conversion option (1.5um) widen the suitable applications range for the ...

Specifications
Avg. Power: 1.5 W
Wavelength: 1064 nm
Repetition Rate: 10-100kHz
Spatial Mode (M^2): 1.2
Pulse Duration: 0.4 ns
...
Data Sheet
Wedge HB 532nm: 532nm Nanosecond Laser
RPMC Lasers, Inc.
Add to watch list
Wedge HB 532nm: 532nm Nanosecond Laser
Compare
The Wedge-HB laser series is a sub-nanosecond, 4mJ, single shot to 2KHz, air-cooled laser capable of 4MW of peak power at 1064nm. Second, third and fourth harmonics options (532nm, 355nm and 266nm) and wavelength conversion option (1.5um) widen the Wedge’s applications range. Based on a proprietary fast active Q-Switching ...

Specifications
Avg. Power: 2 W
Wavelength: 532 nm
Repetition Rate: 0.001-2kHz
Spatial Mode (M^2): 2
Pulse Duration: 1.5 ns
...
Data Sheet
Wedge XB 1064nm: 1064nm Nanosecond Laser
RPMC Lasers, Inc.
Add to watch list
Wedge XB 1064nm: 1064nm Nanosecond Laser
Compare
The Wedge-XB laser series is a sub-nanosecond, 4mJ, single shot to 2KHz, air-cooled laser capable of 4MW of peak power at 1064nm. Second, third and fourth harmonics options (532nm, 355nm and 266nm) and wavelength conversion option (1.5um) widen the Wedge’s applications range. Based on a proprietary fast active Q-Switching ...

Specifications
Avg. Power: 1 W
Wavelength: 1064 nm
Repetition Rate: 0.001-1kHz
Spatial Mode (M^2): 5
Pulse Duration: 1.5 ns
...
Data Sheet
Wedge XB 532nm: 532nm Nanosecond Laser
RPMC Lasers, Inc.
Add to watch list
Wedge XB 532nm: 532nm Nanosecond Laser
Compare
The Wedge-XB laser series is a sub-nanosecond, 4mJ, single shot to 2KHz, air-cooled laser capable of 4MW of peak power at 1064nm. Second, third and fourth harmonics options (532nm, 355nm and 266nm) and wavelength conversion option (1.5um) widen the Wedge’s applications range. Based on a proprietary fast active Q-Switching ...

Specifications
Avg. Power: 2 W
Wavelength: 532 nm
Repetition Rate: 0.001-1kHz
Spatial Mode (M^2): 5
Pulse Duration: 1.5 ns
...
Data Sheet
Wedge HB 266nm: 266nm Nanosecond Laser
RPMC Lasers, Inc.
Add to watch list
Wedge HB 266nm: 266nm Nanosecond Laser
Compare
The Wedge-HB laser series is a sub-nanosecond, 4mJ, single shot to 2KHz, air-cooled laser capable of 4MW of peak power at 1064nm. Second, third and fourth harmonics options (532nm, 355nm and 266nm) and wavelength conversion option (1.5um) widen the Wedge’s applications range. Based on a proprietary fast active Q-Switching ...

Specifications
Avg. Power: 0.3 W
Wavelength: 266 nm
Repetition Rate: 0.001-2kHz
Spatial Mode (M^2): 5
Pulse Duration: 1.5 ns
...
Data Sheet
Wedge HF 532nm: 532nm Picosecond Laser
RPMC Lasers, Inc.
Add to watch list
Wedge HF 532nm: 532nm Picosecond Laser
Compare
The Wedge HF is a compact, air-cooled nanosecond laser delivering up to 0.18mJ at 1064nm with 700ps pulses. 532nm (green), 355nm, 266nm, 1572nm and 3300nm are also available. Applications include thin film removal, micromachining, LIDAR, LIBS, 2nd to 4th harmonic generation, OPO pumping and laser scribing The Wedge-HF laser is a ...

Specifications
Avg. Power: 1.5 W
Wavelength: 532 nm
Repetition Rate: 10-100kHz
Spatial Mode (M^2): 1.6
Pulse Duration: 0.75 ns
...
Data Sheet
Wedge XB 1572nm: 1572nm Nanosecond Laser
RPMC Lasers, Inc.
Add to watch list
Wedge XB 1572nm: 1572nm Nanosecond Laser
Compare
The Wedge-XB laser series is a sub-nanosecond, 4mJ, single shot to 2KHz, air-cooled laser capable of 4MW of peak power at 1064nm. Second, third and fourth harmonics options (532nm, 355nm and 266nm) and wavelength conversion option (1.5um) widen the Wedge’s applications range. Based on a proprietary fast active Q-Switching ...

Specifications
Avg. Power: 0.8 W
Wavelength: 1572 nm
Repetition Rate: 0.001-1kHz
Spatial Mode (M^2): 2.5
Pulse Duration: 2.5 ns
...
Data Sheet
Wedge XB 266nm: 266nm Nanosecond Laser
RPMC Lasers, Inc.
Add to watch list
Wedge XB 266nm: 266nm Nanosecond Laser
Compare
Based on a proprietary fast active Q-Switching technology, these sealed DPSS lasers are insensitive to vibrations and harsh environments. The compact and lightweight package represents a great benefit in LIDAR and other aerospace applications, while short pulses and high peak powers, with relatively low heat generation, allows for ...

Specifications
Avg. Power: 0.5 W
Wavelength: 266 nm
Repetition Rate: 0.001-1kHz
Spatial Mode (M^2): 5
Pulse Duration: 1.8 ns
...
Data Sheet
Wedge XB 355nm: 355nm Nanosecond Laser
RPMC Lasers, Inc.
Add to watch list
Wedge XB 355nm: 355nm Nanosecond Laser
Compare
The Wedge-XB laser series is a sub-nanosecond, 4mJ, single shot to 2KHz, air-cooled laser capable of 4MW of peak power at 1064nm. Second, third and fourth harmonics options (532nm, 355nm and 266nm) and wavelength conversion option (1.5um) widen the Wedge’s applications range. Based on a proprietary fast active Q-Switching ...

Specifications
Avg. Power: 0.600 W
Wavelength: 355 nm
Repetition Rate: 0-1kHz
Spatial Mode (M^2): 5
Pulse Duration: 1.5 ns
...
Data Sheet
