Stradus® 785-80 Diode Laser Module
For pricing, technical or any other questions please contact the supplier
- No registration required
- No markups, no fees
- Direct contact with supplier
Contact Supplier
How to order?
-
Ships from:
United States
-
Sold by:
-
On FindLight:
since 2015
Description
Introducing the Stradus® 785-80 Diode Laser Module, a state-of-the-art laser solution from Vortran Laser Technology, Inc. This fully integrated, plug-and-play, self-contained module is designed to deliver exceptional performance across a variety of applications. The Stradus® 785-80 is crafted with a patented sealed optical cavity and innovative electronics, ensuring unparalleled power stability and beam pointing stability, while maintaining low noise levels over time and across varying temperatures.
The Stradus® 785-80 boasts a wavelength of 785 nm with a power output of 80 mW, making it a robust choice for those requiring precise and reliable laser performance. Its compact design incorporates a small beam size with excellent circularity and centering, ensuring optimal beam quality. The laser's spatial mode is TEM00, which is ideal for applications demanding a high-quality beam profile.
Users can easily control and monitor the module remotely via a mini-USB or RS-232 interface, thanks to Vortran’s intuitive Graphical User Interface (GUI) software. This feature, combined with the module's capability for both analog and digital modulation, provides flexibility and ease of use. The laser operates efficiently within a temperature range of +10°C to +45°C, and its lightweight design makes it suitable for both OEM head and end-user systems.
The Stradus® 785-80 is CE Mark Certified, ensuring compliance with European Union standards, and it meets RoHS compliance for both the EU and China. With its exceptional beam quality, low noise, and robust design, this laser module is an excellent choice for medical, biomedical, and industrial applications. Vortran Laser Technology, Inc. is committed to continuous improvement, ensuring that the Stradus® 785-80 remains at the forefront of laser technology.
Stradus® 785-80 Diode Laser Module
Specifications |
|
|---|---|
| Center Wavelength: | 0.785 um |
| Output Power: | 80 mW |
| Spatial Mode: | TEM 00 |
| Small Beam: | ~1.1 mm, ~1.0 mrad |
| Standard Beam: | ~1.4 mm, ~0.6 mrad |
| M² (typical): | < 1.25 |
| Beam Circularity: | > 90% |
| Power Stability: | < 0.5% over 24 hours |
| Polarization Orientation: | Vertical ±2⁰ |
| Polarization Extinction Ratio: | >100:1 |
| Input Power (Head): | 12V DC, 1.5A (max) |
| Input Power (Control Box): | 90‐250 VAC, 50/60Hz |
| Storage Temperature: | -10⁰C to +60⁰C |
| Operating Temperature: | +10⁰C to +45⁰C |
| Laser Head Weight: | 210g |
| Communication: | Mini‐USB and RS‐232 |
| CDRH Class: | Class IIIb |
| ESD Protection: | Class 4 |
| EU Compliance: | CE Mark Certified with control box |
| RoHS Compliance: | EU and China |
Features
- Wavelength: 785 ± 10 nm
- Power Output: 80 mW (-0%, +10%)
- Spatial Mode: TEM 00
- Beam Size: Small Beam ~1.1 mm, ~1.0 mrad; Standard Beam ~1.4 mm, ~0.6 mrad
- Beam Quality (M²): < 1.25
- Beam Circularity: > 90%
- Beam Centration: < 0.5 mm
- Beam Alignment: < 5 mrad
- Pointing Stability: < 5 µrad/°C
- Power Stability: < 0.5% over 24 hours
- Polarization Orientation: Vertical ±2°
- Polarization Extinction Ratio: > 100:1
- RMS Noise: < 0.2% (10Hz to 10MHz)
- Digital Modulation: 200MHz
- Digital Rise Time: < 2 nsec
Applications
- Medical Diagnostics & Imaging: Ideal for Raman spectroscopy, fluorescence imaging, and biomedical diagnostics requiring stable 785 nm laser sources.
- Industrial Inspection & Metrology: Supports precision measurement and inspection systems demanding high beam quality and stability.
- Biophotonics Research: Suitable for optical trapping, cellular analysis, and research instrumentation.
- OEM System Integration: Designed for integration into end-user systems requiring reliable, modulated laser modules with compact footprints.
Frequently Asked Questions
The Stradus diode laser module is a fully integrated, plug and play, and self-contained laser module.
The Stradus diode laser module can be used in medical, biomedical, and industrial applications.
The power output of the Stradus diode laser module is 80 mW (-0%, +10%).
The Stradus diode laser module has a USB or RS-232 interface with GUI.
The weight of the Stradus diode laser module is 210g.
