Narrow Linewidth Laser Module
Description
Introducing the Narrow Linewidth Laser Module, P/N RZ-13-C34-10-FA-1-3kHz, designed for high precision applications in various fields such as distributed optical fiber sensing, optical fiber hydrophones, LIDAR, and scientific research. Our laser module features an external cavity semiconductor structure that offers narrow line-width, low noise, and high stability.
Our product comes with a single longitudinal mode output, with a line width of less than 3KHz, making it perfect for high-precision applications. The laser module is designed with low phase noise and relative intensity noise, ensuring excellent performance and stability.
The laser module is built with a stable structure and contains no moving parts, making it insensitive to vibration. Our product can operate within the 1530nm-1565nm wavelength range, and we can customize it according to your specific requirements. Additionally, we offer a small range of tuning for your convenience.
Our laser module is designed to meet a case temperature range of 0-70C, ensuring it stays stable even under harsh operating conditions. Plus, it complies with Telcordia GR-468, which guarantees its quality and reliability.
In summary, if you're looking for a high-precision, stable, and reliable laser module, the Narrow Linewidth Laser Module is the perfect choice. Contact us today to learn more about this exceptional product.
Narrow Linewidth Laser Module
Specifications |
|
|---|---|
| Center Wavelength: | 1.55 um |
| Output Power: | 16 mW |
| Power Stability: | -0.5 to 0.5 dB |
| Optical Signal To Noise Ration (SNR): | 60 dB |
| Polarization Extinction Ratio: | 60 dB |
| Operating Temperature: | 0-70 degC |
| Center Wavelength Deviation: | 1550.12 nm |
| Phase Noise @200Hz (1mOPD): | 8 urad/Hz |
| Edge-to-touch Rejection Ratio: | 50 dB |
| Laser Linewidth: | 3 kHz |
| Optical Signal-to-noise Ratio: | 60 dB |
| Isolation: | 40 dB |
| Operating Voltage: | 5.25 V |
| Operating Temperature: | 0 to +70 °C |
| Storage Temperature: | -40 to +85 °C |
| Working Humidity: | 5 tto 90 %RH |
| Storage Humidity: | 5 tto 90 %RH |
| Pigtail Length: | 178 mm |
| Connector: | LC/APC |
Features
- Single Longitudinal Mode Output: Ensures a narrow linewidth of less than 3 kHz
- Low Phase Noise and Intensity Noise: Offers stable performance with minimal noise interference
- Stable, Vibration-Insensitive Structure: No moving parts, immune to vibration
- Customizable Wavelength Range (1530 nm–1565 nm): Fine-tunable within a small range
- Wide Operational Temperature Range: Reliable operation between 0°C to 70°C with no mode jumps
- Compliant with Telcordia GR-468: Meets high reliability and performance standards
- Polarization Extinction Ratio (PER): High PER of 20 dB with slow-axis alignment
Applications
- Distributed Optical Fiber Sensing: Ideal for fiber optic sensing systems requirin stable and narrow linewidth lasers
- Optical Fiber Hydrophones: Suitable for underwater acoustics and sensing applications
- LIDAR Systems: Essential for LIDAR technology, providing stable, narrow linewidth output
- Scientific Research: Perfect for precision measurement and research environments
- Telecommunications: Can be used in high-precision fiber optic communication systems
For pricing, technical or any other questions please contact the supplier
- No registration required
- No markups, no fees
- Direct contact with supplier
Contact Supplier
How to order?
-
Ships from:
China
-
Sold by:
-
On FindLight:
since 2020
Frequently Asked Questions
The laser module can operate within the 1530nm-1565nm wavelength range, and we can customize it according to your specific requirements.
The laser module features a narrow line width of less than 3KHz.
The laser module is built with a stable structure and contains no moving parts, making it insensitive to vibration. It also has low phase noise and relative intensity noise for excellent performance and stability.
The laser module is designed to operate within a case temperature range of 0-70C, and there is no mode jump within this range.
The laser module can be used in various fields such as distributed optical fiber sensing, optical fiber hydrophones, LIDAR, and scientific research.
Yes, the laser module complies with Telcordia GR-468 for quality and reliability.
The Narrow Linewidth Laser Module is used for high precision applications in fields such as distributed optical fiber sensing, optical fiber hydrophones, LIDAR, and scientific research.
The laser module features an external cavity semiconductor structure, narrow line-width (<3KHz), low phase noise and relative intensity noise, single longitudinal mode output, stable structure with no moving parts, and insensitivity to vibration.
Yes, the laser module operates within the 1530nm-1565nm wavelength range and can be customized with a small tuning range.
The laser module is designed to operate within a case temperature range of 0-70C, ensuring stability even under harsh operating conditions.
Yes, the laser module complies with Telcordia GR-468, guaranteeing its quality and reliability.
