Description

The BOX OptronicsTech 980nm pump laser module, model BFLD-976F-4HSM-N0, integrates a planar construction DFB chip with fiber Bragg grating (FBG) frequency locking.

 It is capable of delivering up to 400mW of continuous power at wavelengths of either 974nm or 976nm, with excellent short-term (≤ ±0.02 dB) and long-term (≤ ±0.05 dB) stability.This module features a 14-pin butterfly package that is free of epoxy and flux, and includes an integrated thermoelectric cooler, thermistor, and monitor. It employs FBG stabilization to "lock" the emission wavelength, providing a noise-free narrowband spectrum even under changes in temperature, drive current, and optical feedback.

 For applications requiring the highest performance in spectrum control and the highest available power, this module also offers wavelength selection. The module complies with the Telcordia GR-468-CORE standard.

The 980nm pump laser module is suitable for applications such as dense wavelength division multiplexing (DWDM) erbium-doped fiber amplifiers (EDFA), reduced pump-count EDFA architectures, very long-distance cable television (CATV) trunks, and applications with very high node counts.

980nm Pump Laser Source for Fiber Lasers and Amplifiers

Specifications

Operating Wavelength: 974±1, 976±1 nm
Output Power: 200-700 mW
Power Dissipation: ≤ 60 W
Power Instability (Long-term 8hours): ≤±0.05 dB
Power Instability (Short-term 15mins): ≤±0.02 dB
Fiber Type: Hi1060/PM980
Dimensions: 195(W)×220(D)×120(H) , 150(W)×125(D)×20(H) mm
Connector: FC/APC , SC/APC

Got questions about specs? Use the inquiry form to ask.

Document icon Download Data Sheet Download icon

Features

  • High output power
  • Power and spectral stability
  • Module or Benchtop package
  • Color LCD status display

Applications

  • Fiber laser pumping
  • Erbium-doped fiber amplifier
  • Nonlinear optics research

Frequently Asked Questions

What is the 980nm Pump Laser Source used for?
The 980nm Pump Laser Source is used for fiber laser pumping, erbium-doped fiber amplifiers, and nonlinear optics research.
What are the available output power options for the 980nm Pump Laser Source?
The available output power options are 200mW, 400mW, and 600mW.
What packaging options are available for the 980nm Pump Laser Source?
The 980nm Pump Laser Source is available in either a benchtop or modular package.
What is the operating wavelength range of the 980nm Pump Laser Source?
The operating wavelength range is 974±1 nm and 976±1 nm.
What is the power instability specification for the 980nm Pump Laser Source?
The short-term (15 minutes) power instability is ≤±0.02 dB, and the long-term (8 hours) power instability is ≤±0.05 dB.
What are the dimensions of the benchtop and module versions of the 980nm Pump Laser Source?
The benchtop version dimensions are 195(W)×220(D)×120(H) mm, and the module version dimensions are 150(W)×125(D)×20(H) mm.
What is the operating temperature range for the 980nm Pump Laser Source?
The operating temperature range is -5°C to +55°C.
