QSI 660nm 120mw QL66O7SA-S Red Laser Diode is a high-performance red laser diode designed for precision and reliability in demanding environments. With a lasing wavelength centered around 660nm, this red laser diode delivers an optical output power of 120mW, making it an ideal choice for applications requiring consistent and powerful red laser emission. Its compact 5.6mm package ensures easy integration into various systems, while maintaining robust performance across a wide range of operating conditions.
Engineered for versatility, the this laser diode operates efficiently within a temperature range of -10°C to +70°C, ensuring stable performance even in challenging environments. The laser diode's continuous wave (CW) operation and single transverse/TE mode provide a stable and uniform beam, essential for applications that demand precision and accuracy. This makes it particularly suitable for use in medical and industrial optical sensor applications, where reliability and precision are paramount.
Designed with durability in mind, this red laser diode features a rugged construction that withstands the rigors of industrial use. Its electrical and optical characteristics are optimized for performance, with a typical operating current of 140mA and an operating voltage of 2.5V to 3.0V. The laser diode also boasts a slope efficiency of 1.2mW/mA, ensuring efficient power conversion and minimal energy loss. With a beam divergence of 9.5 degrees and a full width at half maximum (FWHM) of 15 degrees, this laser diode provides a focused and precise beam, essential for high-precision applications.
Overall, the QSI 660nm 120mw QL66O7SA-S Red Laser Diode is a reliable and efficient solution for applications requiring a high-quality red laser source. Its robust design, coupled with its exceptional performance characteristics, makes it a preferred choice for professionals in the medical and industrial sectors. Whether used in optical sensors or other precision instruments, this laser diode delivers consistent and reliable results, ensuring optimal performance in every application.
QSI is founded in July 2000 and headquartered in South Korea, and is a publicly listed company with full vertical integration, handling R&D, wafer processing, chip production, packaging, and sales in-house.
QSI 660nm 120mw QL66O7SA-S Red Laser Diode is one of the unique items in the laser diode market for medical, industrial optical sensors, etc.
Notes on order quantity options and delivery times to the USA:
Minimum Order Quantity (MOQ): 10 (in multiples of 10)
Price for QTY 50: $750
Price for QTY 100: $1,400
Price for QTY 500: $6,500
Price for QTY 1000: $12,000
Delivery time to the USA: 5 to 7 days
Estimated tariff for the USA: 25%
QSI 660nm 120mw Red Laser Diode QL66O7SA-S
Specifications
Center Wavelength: | 0.66 um |
---|---|
Output Power: | 120 mW |
Optical Output Power: | 120 mW |
Laser Diode Reverse Voltage: | 2 V |
Photo Diode Reverse Voltage: | 30 V |
Beam Angle: | -3 - 3 deg |
Monitor Current: | 0.2 - 0.8 mA |
Optical Distance: | ±60 μm |
Operating Temperature: | -10 ~ +70 ℃ |
Storage Temperature: | -40 ~ +85 ℃ |
Threshold Current: | 30 - 60 mA |
Operating Current: | 140 - 170 mA |
Operating Voltage: | 2.5 - 3.0 V |
Slope Efficiency: | 0.9 - 1.5 mW/mA |
Lasing Wavelength: | 653 - 667 nm |
Beam Divergence: | 6 - 12 deg |
FWHM: | 10 - 20 deg |
Minimum Order Quantity: | 10 diodes (in multiples of 10) |
Price For QTY 50: | $750 |
Price For QTY 100: | $1,400 |
Price For QTY 500: | $6,500 |
Price For QTY 1000: | $12,000 |
ECCN: | EAR99 |
HTS: | 8541.41.0000 |
Approximate Delivery Time To USA: | 5 to 7 days |
Estimated Tariff In USA: | 25% |
Features
- 660nm Red Laser
- CW laser (Continuous Wave)
- Single Transvers / TE mode laser
- 5.6mm Package
Applications
- Medical
- Industrial Optical Sensor
Frequently Asked Questions
What is the QSI 660nm 120mw QL66O7SA-S Red Laser Diode laser used for?
What are the key features of the QL66O7SA/B/C-S laser?
What is the maximum optical output power of this red diode laser?
What are the operating temperature limits for the QL66O7SA/B/C-S laser diode?
What precautions should be taken to prevent damage to the QL66O7SA/B/C-S laser diode?
What is the recommended soldering temperature and time for the QSI 660nm 120mw QL66O7SA-S Red Laser Diode?
What safety measures should be taken when operating the QSI 660nm 120mw QL66O7SA-S Red Laser Diode?
