Stradus® 705-30 Diode Laser Module
For pricing, technical or any other questions please contact the supplier
- No registration required
- No markups, no fees
- Direct contact with supplier
Contact Supplier
How to order?
-
Ships from:
United States
-
Sold by:
-
On FindLight:
since 2015
Description
The Stradus® 705-30 diode laser module by Vortran Laser Technology, Inc. represents a pinnacle of innovation in laser technology. This fully integrated, plug-and-play laser module is designed to offer unparalleled performance with its patented sealed optical cavity. This unique design ensures exceptional power stability and beam pointing stability, making it a reliable choice for various demanding applications. The module's low noise operation further enhances its performance, maintaining precision and consistency over time and temperature changes.
Vortran’s Stradus® laser module is engineered for ease of use with its self-contained, compact design. It incorporates advanced electronics that facilitate seamless operation and monitoring. The Graphical User Interface (GUI) software provided by Vortran allows users to control and monitor the laser module remotely via USB or RS-232 interfaces. This capability ensures that users can maintain optimal performance and adapt to changing conditions with ease.
The Stradus® 705-30 is not only robust in performance but also versatile in its applications. Whether used in medical, biomedical, or industrial settings, this laser module delivers excellent beam quality and precision. Its compatibility with both analog and digital modulation further expands its utility, making it suitable for a wide range of operational environments. The module is compliant with EU and China RoHS standards and comes with CE Mark Certification, ensuring it meets stringent safety and environmental regulations.
With a commitment to continuous improvement, Vortran Laser Technology, Inc. ensures that the Stradus® 705-30 remains at the forefront of laser technology. For more information or to inquire about this product, please contact Vortran Laser Technology, Inc. at their Sacramento office or reach out via email at sales@vortranlaser.com.
Stradus® 705-30 Diode Laser Module
Specifications |
|
|---|---|
| Center Wavelength: | 0.705 um |
| Output Power: | 30 mW |
| Spatial Mode: | TEM 00 |
| Beam Diameter: | ~1.3 or ~1.0 mm |
| Beam Divergence: | ~0.5 or ~1.0 mrad |
| M² (typical): | < 1.25 |
| Beam Circularity: | > 90% |
| Beam Centration: | < 0.5 mm |
| Beam Alignment: | < 5 mrad |
| Pointing Stability: | < 5 µrad/⁰C |
| Power Stability: | < 0.5% over 24 hours |
| Polarization Orientation: | Vertical ±2⁰ |
| Polarization Extinction Ratio: | >100:1 |
| Analog Modulation: | 500kHz |
| Input Power (Head): | 12V DC, 1.5A (max) |
| Input Power (Control Box): | 90‐250 VAC, 50/60Hz |
| Storage Temperature: | ‐10⁰C to +60⁰C |
| Operating Temperature: | +10⁰C to +45⁰C |
| Laser Head Weight: | 210g |
| Communication: | Mini‐USB and RS‐232 |
| CDRH Class: | Class IIIb |
| ESD Protection: | Class 4 |
| EU Compliance: | CE Mark Certified with control box |
| RoHS Compliance: | EU and China |
Features
- Wavelength: 705 ± 10 nm
- Power Output: 30 mW (‐0%, +10%)
- Spatial Mode: TEM 00
- Beam Diameter: ~1.3 mm or ~1.0 mm (1/e2)
- Beam Divergence: ~0.5 mrad or ~1.0 mrad
- M² (typical): < 1.25
- Beam Circularity: > 90%
- Beam Centration: < 0.5 mm
- Beam Alignment: < 5 mrad
- Pointing Stability: < 5 µrad/⁰C
- Power Stability (over 24 hours): < 0.5%
- Polarization Orientation: Vertical ±2⁰
- Polarization Extinction Ratio: >100:1
Applications
- Biomedical Imaging & Diagnostics: Ideal for fluorescence excitation and spectroscopy at 705 nm.
- Industrial Measurement & Metrology: Supports precision inspection systems requiring stable, narrow-linewidth output.
- Scientific Research & Instrumentation: Suitable for biophotonics, optical experiments, and analytical systems.
- OEM Laser Integration: Designed for incorporation into compact end-user products and custom instrumentation.
Frequently Asked Questions
The Stradus® diode laser module is a fully integrated, plug and play, and self-contained laser module.
The Stradus® diode laser module is used in medical, biomedical, and industrial applications.
The RMS noise of the Stradus® diode laser module is less than 0.2% (10Hz to 10MHz).
The Stradus® diode laser module has a Mini-USB and RS-232 communication interface.
The power output of the Stradus® diode laser module is 30 (‐0%, +10%) mW.
