Description
The Stradus® 633-80 diode laser module by Vortran Laser Technology, Inc. represents the pinnacle of precision and reliability in laser technology. This fully integrated, plug-and-play solution is designed to meet the rigorous demands of modern applications. With its patented sealed optical cavity, the Stradus® laser ensures unparalleled power stability and beam pointing stability, making it a dependable choice for users who require consistent performance over time and varying temperatures.
Engineered with cutting-edge electronics, the Stradus® 633-80 offers low noise operation, enhancing its suitability for sensitive environments. Its compact and self-contained design is not only space-efficient but also simplifies installation and integration. The laser module's excellent beam quality is complemented by its robust construction, ensuring durability and longevity in diverse settings.
For ease of use, the Stradus® 633-80 comes equipped with Vortran’s Graphical User Interface (GUI) software. This feature allows users to control and monitor the laser module remotely via USB or RS-232, providing flexibility and convenience. Whether utilized in medical, biomedical, or industrial applications, the Stradus® 633-80 stands out with its versatile analog and digital modulation capabilities, catering to both OEM head or end-user systems.
Stradus® 633-80 Diode Laser Module
Specifications |
|
|---|---|
| Center Wavelength: | 0.633 um |
| Output Power: | 80 mW |
| Spatial Mode: | TEM00 |
| Small Beam: | ~1.0 mm, ~1.0 mrad |
| Standard Beam: | ~1.3 mm, ~0.7 mrad |
| M² (typical): | < 1.25 |
| Pointing Stability: | < 5 µrad/⁰C |
| Power Stability: | < 0.5% (over 24 hours) |
| Polarization Orientation: | Vertical ±5⁰ |
| Polarization Extinction Ratio: | >100:1 |
| Input Power (Head): | 12V DC, 1.5A (max) |
| Input Power (Control Box): | 90-250 VAC, 50/60Hz |
| Storage Temperature: | -10⁰C to +60⁰C |
| Operating Temperature: | +10⁰C to +45⁰C |
| Laser Head Weight: | 210g |
| Communication: | Mini-USB and RS-232 |
| CDRH Class: | Class IIIb |
| ESD Protection: | Class 4 |
| EU Compliance: | CE Mark Certified with control box |
| RoHS Compliance: | EU and China |
Features
- 633 nm Wavelength: Bright red emission for biomedical and optical applications
- 80 mW Power Output: Delivers stable output for demanding tasks
- Superior Beam Quality: TEM00 mode with M² < 1.25 for high focusability
- Ultra Low Noise: RMS noise <0.1% (10Hz–10MHz) for clean and stable performance
- Excellent Pointing Stability: <5 µrad/°C ensures reliable beam alignment
- Fast Modulation Response: Digital modulation up to 200 MHz (<2 ns rise time); analog up to 500 kHz (<0.7 µs rise time)
- Compact & Integrated: Self-contained design with patented sealed optical cavity
- User-Friendly Interface: Control via Mini-USB and RS-232 with GUI software
- Certified Compliance: CE Mark certified and RoHS compliant for EU and Chin
Applications
- Biomedical Research: Ideal for fluorescence imaging and optical manipulation
- Medical Diagnostics: Suitable for diagnostic and analytical instrumentation
- Industrial Measurement: Precise alignment and inspection systems
- OEM System Integration: Compact design integrates seamlessly into equipment
- Scientific Instrumentation: Stable operation for spectroscopy and advanced R&D
Frequently Asked Questions
The Stradus® diode laser module is a fully integrated, plug and play, and self-contained laser module that provides unparalleled power stability, beam pointing stability, and low noise over time and temperature.
The Stradus® diode laser module has a Mini-USB and RS-232 communication interface with GUI software that allows remote control and monitoring.
The Stradus® diode laser module is suitable for medical, biomedical, and industrial applications.
The RMS noise of the Stradus® diode laser module is less than 0.1% from 10Hz to 10MHz.
The Stradus® diode laser module has a TEM 00 spatial mode.
