Description
SemiNex’s High Power Multi-Mode Laser Bars deliver exceptional performance at infrared wavelengths ranging from 1310 nm to 1625 nm, offering up to 25 Watts of continuous wave (CW) optical power. Engineered with InP laser chip technology, these laser bars provide high efficiency, high dynamic power range, and stable operation for demanding applications. Each bar features 19 emitters with a standard emitter width of 95 µm, ensuring optimal beam quality and power output.
SemiNex laser bars are ideal for integration into medical laser equipment, LIDAR systems, free space optical communication, DPSS pump lasers, and military/aerospace applications where reliable high-power infrared sources are required. These devices can be custom-designed to meet specific optical and electrical performance requirements, ensuring application flexibility. Tested and qualified to meet rigorous market demands, SemiNex laser bars provide industry-leading slope efficiency, low threshold currents, and excellent power conversion efficiency.
For customers requiring additional customization, SemiNex offers tailored designs across wavelengths, cavity lengths, and packaging options. Contact SemiNex to discuss your precise requirements and discover solutions for your next high-power infrared system design.
High Power Multimode Laser Bars
Specifications |
|
|---|---|
| Center Wavelength: | 1.55 um |
| Output Power: | 25000 mW |
| Optical Wavelength: | 1310 - 1615 |
| Emitter Width: | 85 µm |
| Chip Cavity Length: | 1500-2500 µm |
| Spectral Width: | 15 nm |
| Slope Efficiency: | 0.3 W/A |
| Operating Current ): | 65 A |
| Operating Voltage: | 1.3 V |
Features
- High Power Multi-Mode Laser Bars: Offering 25 Watts of continuous wave (CW) power for robust performance.
- Infrared Wavelength Range: Available wavelengths include 1310, 1470, 1532, 1550, and 1625 nm. Custom wavelengths are also available to meet specific needs.
- Customizable Design: SemiNex can optimize InP laser chips to meet specific optical and electrical performance requirements.
- High Output Power: Ensures superior performance across various applications.
- High Dynamic Power Range: Enables versatile usage and adaptability in different scenarios.
- High Efficiency: Designed for maximum power output with minimal energy consumption.
- 19 Emitters Standard: Provides enhanced power and performance.
Applications
- Medical Laser Equipment: Provides precise high-power infrared light for therapeutic and surgical procedures.
- LIDAR Systems: Enables powerful and efficient light sources for advanced range-finding applications.
- Free Space Optical Communication: Supports high-data-rate communication with reliable infrared output.
- DPSS Pump Lasers: Ideal as pump sources for diode-pumped solid-state laser systems.
- Military and Aerospace: Suitable for infrared illumination, targeting, and sensor applications.
Frequently Asked Questions
The maximum CW power of SemiNex High Power Multimode Laser Bars is 25 Watts.
The standard wavelengths of SemiNex High Power Multimode Laser Bars are 1310, 1470, 1532, 1550, and 1625nm.
SemiNex High Power Multimode Laser Bars can be used for medical, LiDAR, free space optical communication, DPSS pump lasers, military, and aerospace applications.
Yes, custom wavelengths are available for SemiNex High Power Multimode Laser Bars.
Laser radiation from this product is considered an acute hazard to the skin and eyes. Direct exposure to the beam should be avoided.
