Fiber Optic ATR-Probes for Broad Spectra Applications

Name: Fiber Optic ATR-Probes for Broad Spectra Applications
Brand: Art photonics GmbH

Description

The Fiber Optic ATR-Probes from art photonics are high-performance probes designed for a broad spectral range, including UV-Vis-NIR and Mid-IR. These probes offer high throughput, no dead zone, and robustness suitable for industrial applications in harsh environments. Compatible with various spectrometers and automated process interfaces, they provide accurate and reliable measurements for reaction monitoring in lab, pilot plant, and industrial settings.

Specifications

Transmission:	1.1 – 18 um
Temperature Range:	-150 – 140 C
Pressure (max):	200Bar, 300Bar on request
Compatibility:	FT-NIR, FT-IR, and other IR-spectrometers, photometers, IR-LED, or QCL
Design:	Patented design for ATR immersion fiber optic probes
Throughput:	High throughput
Dead Zone:	No dead zone

Got questions about specs? Use the inquiry form to ask.

Download Data Sheet

Features

High throughput in any part of the Near- and Mid-IR spectrum
No dead zone for accurate measurements
Flexible and robust design for industrial applications in harsh environments
Compatible with all spectrometers and automated process interfaces

Applications

Reaction monitoring in lab, pilot plant, and industrial environments
Automated process control
Spectroscopic analysis in UV, visible, near-IR, and Mid-IR ranges

Request Quote

To: Art photonics GmbH
Re: Fiber Optic ATR-Probes for Broad Spectra Applications

Name

Work Email

Organization

Country

Your message to supplier

Thank you, your message was sent successfully.

Ships from:: Germany
Sold by:: Art photonics GmbH
On FindLight:: since 2014

Why contact via FindLight?

Message the supplier directly
No signup or account needed
No FindLight fees or markups
Expect a fast reply
Autofill forms with a Buyer Account

Frequently Asked Questions

What is the FlexiSpec Fiber Optic Probe Diamond ATR used for?

The FlexiSpec Fiber Optic Probe Diamond ATR is used for reaction monitoring in real time, process analytical technologies (PAT), remote polymerization control, crystallization process screening, and in-situ IR-spectroscopy for PAT in chemical, petrochemical, atomic, biopharmaceutical, and food industry.

What is the FlexiSpec product line?

The FlexiSpec product line is the latest generation of Attenuated Total Reflection Near & Mid IR-fiber ATR-Probes produced for any type of FT-NIR, FT-IR and other IR-spectrometers, photometers and IR-LED or QCL spectral sensors.

What is the patented design of the ATR immersion fiber optic probes?

The ATR immersion fiber optic probes have a patented design that makes them suitable for reaction monitoring in lab, pilot plant and for full automated process control.

What are the applications of the FlexiSpec Fiber Optic Probe Diamond ATR?

The applications of the FlexiSpec Fiber Optic Probe Diamond ATR include reaction monitoring in real time, process analytical technologies (PAT), remote polymerization control, crystallization process screening, and in-situ IR-spectroscopy for PAT in chemical, petrochemical, atomic, biopharmaceutical, and food industry.

What type of instruments is the FlexiSpec Fiber Optic Probe Diamond ATR compatible with?

The FlexiSpec Fiber Optic Probe Diamond ATR is compatible with any type of FT-NIR, FT-IR and other IR-spectrometers, photometers and IR-LED or QCL spectral sensors.
