PMMA Optical Fiber Cable for Communication POF Cable for Data Transmission
For pricing, technical or any other questions please contact the supplier
- No registration required
- No markups, no fees
- Direct contact with supplier
Contact Supplier
How to order?
-
Ships from:
China
-
Sold by:
Jiangsu TX Plastic Optical Fibers Co.,Ltd -
On FindLight:
since 2022
Description
Jiangsu TX Plastic Optical Fibers Co., Ltd is a leading manufacturer specializing in the production of high-quality plastic optical fibers. Located in the Economic Development Area of Yangzhou, Jiangsu, China, our company is dedicated to providing innovative fiber optic solutions that meet the demands of modern communication technologies. Our commitment to excellence is reflected in our state-of-the-art manufacturing processes and rigorous quality control standards.
The TX-CC1000-1A is a premium product designed to deliver superior performance in various communication applications. This optical fiber features a core made from PMMA (Polymethyl Methacrylate) and is clad with a fluorinated polymer, ensuring optimal light transmission and minimal signal loss. With a core refractive index of 1.492 and a numerical aperture of 0.5, the TX-CC1000-1A is engineered to provide exceptional clarity and efficiency in data transmission.
Our optical fibers are encased in a durable black PE (Polyethylene) outer jacket, offering robust protection against environmental factors. The TX-CC1000-1A boasts a minimum bend radius of 25mm, allowing for flexible installation without compromising performance. Additionally, the product is designed to withstand a wide range of mechanical stresses, including repeated bending, twisting, and impact endurance, ensuring long-lasting reliability even in challenging conditions.
Operating efficiently in temperatures ranging from -50℃ to +70℃, the TX-CC1000-1A is versatile and adaptable to various environments. Its superior optical properties, including a transmission loss of ≤180 dB/km under 650nm collimated light, make it an ideal choice for high-performance communication networks. At Jiangsu TX Plastic Optical Fibers Co., Ltd, we are committed to delivering products that not only meet but exceed industry standards, ensuring our customers receive the best in optical fiber technology.
PMMA Optical Fiber Cable for Communication POF Cable for Data Transmission
Specifications |
|
|---|---|
| Core Diameter: | 980 um |
| Wavelength Range: | 530 – 650 um |
| Fiber Core Material: | Plastic |
| Cable Length: | 2500 m |
| Inner Fiber Diameter: | 0.5mm,1.0mm,1.5mm,2.5mm,etc |
| Storage Temperature: | -55~ +70℃ |
| Inner Fiber Material: | PMMA |
| Cladding Material: | Fluorinated Polymer |
| Outer Jacket Material: | PVC, PE, TPU,TPE, optional |
| Structure: | Step Numerical |
| Numerical Aperture: | 0.5 |
| Core Refractive Index: | 1.49 |
| Transmission Loss(at 650nm): | ≤240 dB/km |
Features
- High-Quality PMMA Core: Ensures efficient light transmission and consistent optical performance.
- Fluorinated Polymer Cladding: Maintains core integrity and precise refractive index.
- Low Transmission Loss: ≤180 dB/km at 650 nm for high-efficiency communication.
- Durable PE Jacket: Provides mechanical protection and environmental resistance.
- Wide Operating Temperature: Functional from -50°C to +70°C for diverse applications.
- Mechanical Endurance: Withstands repeated bending, twisting, and impact with minimal loss.
- Flexible Design: Minimum bend radius of 25 mm for easy installation.
Applications
- Communication: The TX-CC1000-1A optical fiber is designed for efficient data transmission, making it ideal for communication applications.
- Data Transmission: With low transmission loss, this fiber is suitable for high-speed data transfer over long distances.
- Networking: Perfect for use in networking environments where reliable and fast data exchange is crucial.
- Telecommunications: Suitable for use in telecommunications infrastructure, supporting voice and data communication.
- Industrial Applications: Can be used in industrial settings where robust and durable fiber optics are required.
- Environmental Monitoring: Ideal for applications that require operation in a wide temperature range from -50℃ to +70℃.
Frequently Asked Questions
The main application of the PMMA Optical Fiber Cable is communication.
The PMMA Optical Fiber Cable features high speed, high width, high performance, anti-interference, low loss, and anti-wear.
The specifications of the PMMA Optical Fiber Cable include a core diameter of 980 ± 60 μm, cladding diameter of 1000 ± 60 μm, outer jacket diameter of 2.2 ± 0.1 mm, and a transmission loss of ≤ 180 dB/km under 650nm collimated light.
The minimum bend radius of the PMMA Optical Fiber Cable is 25mm.
The PMMA Optical Fiber Cable can operate in temperatures ranging from -50°C to +70°C.
