Gentec-EO High Power Detector UP12E-70W-H5-D0

Gentec-EO
REQUEST QUOTE
Gentec-EO High Power Detector UP12E-70W-H5-D0

OVERVIEW

The Gentec-EO Ultra Series UP power detector family includes thirteen series (XLP12, UP12E, UP10K(P), UP17P, UP19K, UP25N(M), UP25T, UP50N(M), UP55N(M), UP55C, UP60N(M), UP55G, and UP60G) of opto-thermal sensors with different cooling options (stand alone, heat sink, fan and water), with or without amplification. The high power surface absorber sensors are designed for use at high average power densities.

SPECIFICATION

  • Detector Type: Thermal Absorber (thermopile)
  • Spectral Range: 0.19 - 20 um
  • Size: 12 mm
  • Maximum Power: 70 W
  • Noise Equivalent Power: 1000 uW
  • Max Average Power Density: 36 kW/cm2
Download Data Sheet

Applications

Laser power measurements

KEY FEATURES

The UP detectors are supplied with a 180 cm length flexible cable with output connection options of
a DB-15 "intelligent" male connector, an Integra USB connector, a BNC connector, a Molex
connector and a BNC/Molex connector. A few exception exist: the UP50N series is available with
BNC/Molex connector on special order only and the XLP12, UP60N(M), and UP60G series are only
supplied with a DB-15 “intelligent” male connector and the Integra USB connector.

NOTE: To eliminate possible damage, do not carry the detector using the connector cable.

The UP detectors may also be supplied with a stand. Be aware that when using a detector with a
heat sink, the fins should always be placed vertically.
For cases where Gentec-EO’s monitors don’t automatically read the wavelength correction factor,
you can use your detector’s “Personal wavelength correction TM Certificate” to adjust the power you
read to a power corrected for a particular wavelength.
