Page 2 - Pulsed DPSS Lasers

FLC offers a wide range of diode-pumped solid state laser products, the smallest DPSS laser heads, low cost modules, low power and high power laser systems and high quality single longitudinal mode laser systems with different power output and wavelengths.

Specifications

Avg. Power: 0.5 W
Wavelength: 532 nm
Repetition Rate: 4 – 6 kHz
Spatial Mode (M^2): 1.5
Pulse Duration: 1.3 ns
FLC offers a wide range of diode-pumped solid state laser products, the smallest DPSS laser heads, low cost modules, low power and high power laser systems and high quality single longitudinal mode laser systems with different power output and wavelengths.

Specifications

Avg. Power: 200 W
Wavelength: 1064 nm
Repetition Rate: 0.001 – 0.02 kHz
Spatial Mode (M^2): Not Specified
Pulse Duration: 100000 ns
A heart of Diode-Pumped Solid-State (DPSS) lasers or laser amplifiers are Laser Gain Module (pump chamber). By evolving laser gain modules, Geola Digital can provide DPSS laser gain modules based on Vertical Cavity Surface Emitting Laser (VCSEL) pumping engine technology. Our DPSS laser gain module ...

Specifications

Avg. Power: 1300 W
Wavelength: 808 nm
Repetition Rate: 0.02 – 1 kHz
Spatial Mode (M^2): 1.3
Pulse Duration: 0.1 ns
A heart of Diode-Pumped Solid-State (DPSS) lasers or laser amplifiers are Laser Gain Module (pump chamber). By evolving laser gain modules, Geola Digital can provide DPSS laser gain modules based on Vertical Cavity Surface Emitting Laser (VCSEL) pumping engine technology. Our DPSS laser gain module engines assures uniform gain ...

Specifications

Avg. Power: 1800 W
Wavelength: 808 nm
Repetition Rate: 0.02 – 0.02 kHz
Spatial Mode (M^2): 1.3
Pulse Duration: 200000 ns
Talon® is a rugged industrial laser capable of supplying the long-term performance and low cost of ownership necessary for a 24/7 precision manufacturing tool. Talon lasers are ideal for a wide range of micromachining applications where extended production cycles rely on stable beam quality and high uptime. Features such as E-Pulse™, ...

Specifications

Repetition Rate: 50 – 200 kHz
Spatial Mode (M^2): 1.2
Pulse Duration: 25 ns
Pulse-to-Pulse Stability (RMS): 2 %
Cooling: Water-to-Water
The Explorer® One™ is the most compact series of UV and green diode pumped solid state (DPSS) q-switch lasers in its class. The It’s in the Box™ design incorporates features such as the very compact air cooled design, short pulse width, high peak power and a feature rich software into one single package to satisfy customer needs with ...

Specifications

Spatial Mode (M^2): 1.2
Pulse-to-Pulse Stability (RMS): 2 %
Cooling: Water-to-Water
Power: 800 mW at 355 nm
Power: 2 W at 532 nm
IceFyre® redefines picosecond micromachining lasers with a patent-pending design to achieve exceptional performance and unprecedented versatility at industry leading cost-performance. Based on Spectra-Physics’ It’s in the Box™ design, IceFyre integrates laser and controller into the industry’s smallest package.

Specifications

Avg. Power: Not Specified
Wavelength: Not Specified
Repetition Rate: Not Specified
Spatial Mode (M^2): Not Specified
Pulse Duration: Not Specified
Talon Mark is a high-performance industrial laser engineered for ultra-high-speed on-the-fly marking and coding applications in the Food & Beverage industry. Its broad operating range makes it ideal for demanding environments where extended production cycles depend on consistent beam quality and maximum uptime. Key features such ...

Specifications

Avg. Power: 20 W
Wavelength: 355 nm
Spatial Mode (M^2): 1.2
Pulse Duration: 28 ns
Pulse-to-Pulse Stability (RMS): 2 %
Wedge XF sub-nanosecond (300ps), DPSS laser produces up to 70uJ of pulse energy at 1064nm, with operation from single shot to 100 kHz, in a compact, air-cooled OEM solution. Second, Third and Fourth Harmonics (532, 355 and 266nm output) and wavelength conversion option (1.5um) widen the suitable applications range for the ...

Specifications

Avg. Power: 1.5 W
Wavelength: 1064 nm
Repetition Rate: 10 – 100 kHz
Spatial Mode (M^2): 1.2
Pulse Duration: 0.4 ns
The Sol 6W 1064nm Q-Switched Compact ns DPSSL Laser is a high-performance, all-solid-state laser designed for precision material processing and medical applications. With a maximum pulse energy of 300 µJ and a pulse width range of 15 to 60 ns, it delivers exceptional power and pulse duration control. The laser operates at a ...

Specifications

Avg. Power: 6 W
Wavelength: 1064 nm
Repetition Rate: 0.001 – 100 kHz
Spatial Mode (M^2): 1.5
Pulse Duration: 15 ns
The SB1-532-20-1 of our Microchip Series is a short nanosecond pulsed, 20uJ, low SWaP, ultra-compact, 1 kHz, passively Q-switched, DPSS laser. Bright Microlaser has pushed its unique microchip laser technology further with the new, completely re-designed all-in-one SB1 model. Thanks to its advanced optical, mechanical and electronic ...

Specifications

Avg. Power: 0.02 W
Wavelength: 532 nm
Repetition Rate: 0.001 – 1 kHz
Spatial Mode (M^2): 1.3
Pulse Duration: 1.3 ns
The Q-SHIFT Diode-Pumped Air-Cooled Q-Switched Laser is a state-of-the-art solution designed for applications requiring high peak intensity and precise wavelength control. Featuring a built-in nonlinear wavelength conversion stage, this laser generates wavelengths not achievable with conventional solid-state laser sources. It ...

Specifications

Avg. Power: 1 W
Wavelength: 1163 nm
Repetition Rate: 0.01 – 0.1 kHz
Spatial Mode (M^2): Not Specified
Pulse Duration: 2 ns
With a focus on innovative system architectures, such as monolithic designs for enhanced stability and modular configurations for customizable performance, high-E Photonics delivers industry-leading reliability in demanding environments.

Specifications

Avg. Power: 100 W
Wavelength: 1500 nm
Repetition Rate: 10000 – 100000 kHz
Spatial Mode (M^2): 1.3
Pulse Duration: 0.1 ns
The Onda nanosecond laser series, available with up to 10W at 1064nm and 532nm, was developed as a high-energy seeder for advanced MOPA systems. The Onda is a DPSS ns-laser platform aimed at high-end applications requiring both excellent beam quality and high peak power in materials such as metals, glass, plastics, and various ...

Specifications

Avg. Power: 10 W
Wavelength: 532 nm
Repetition Rate: 1 – 100 kHz
Spatial Mode (M^2): 1.5
Pulse Duration: 10 ns
The Lampo series by Bright Solutions is a family of compact, ultrafast DPSS lasers designed to deliver high peak power picosecond pulses with a selectable repetition rate from 50 kHz to 4 MHz. These lasers offer pulse durations as short as 50-70 ps, delivering peak powers up to 4.5 MW and a wide range of wavelengths from IR (1064 nm) ...

Specifications

Avg. Power: 20 W
Wavelength: 1064 nm
Repetition Rate: 50 – 40000 kHz
Spatial Mode (M^2): Not Specified
Pulse Duration: 0.05 ns
The KAUKAS Series is a line of compact, low-SWaP Er:glass pulsed lasers operating at 1.54µm, offering “eye-safe” performance. These nanosecond pulsed lasers are designed for integration into portable, handheld devices, providing high pulse energy and repetition rates up to 5Hz. With less than 3% energy stability and ...

Specifications

Avg. Power: 0.004 W
Wavelength: 1534 nm
Repetition Rate: 0 – 0.002 kHz
Spatial Mode (M^2): 2
Pulse Duration: 11 ns
The SB1-1064-20-10 of our Microchip Series is a short nanosecond pulsed, 20uJ, low SWaP, ultra-compact, 10 kHz, passively Q-switched, DPSS laser. Bright Microlaser has pushed its unique microchip laser technology further with the new, completely re-designed all-in-one SB1 model. Thanks to its advanced optical, mechanical and ...

Specifications

Avg. Power: 0.2 W
Wavelength: 1064 nm
Repetition Rate: 1 – 10 kHz
Spatial Mode (M^2): 1.3
Pulse Duration: 1.3 ns
The SB1-1064-15-15 of our Microchip Series is a short nanosecond pulsed, 15uJ, low SWaP, ultra-compact, 10 kHz – 15 kHz, passively Q-switched, DPSS laser. Bright Microlaser has pushed its unique microchip laser technology further with the new, completely re-designed all-in-one SB1 model. Thanks to its advanced optical, ...

Specifications

Avg. Power: 0.225 W
Wavelength: 1064 nm
Repetition Rate: 0.001 – 15 kHz
Spatial Mode (M^2): 1.3
Pulse Duration: 1.3 ns
The SB1-1064-2-55 of our Microchip Series is a short nanosecond pulsed, 2uJ, low SWaP, ultra-compact, 55 kHz, passively Q-switched, DPSS laser. Bright Microlaser has pushed its unique microchip laser technology further with the new, completely re-designed all-in-one SB1 model. Thanks to its advanced optical, mechanical and ...

Specifications

Avg. Power: 0.11 W
Wavelength: 1064 nm
Repetition Rate: 0.001 – 55 kHz
Spatial Mode (M^2): 1.3
Pulse Duration: 0.47 ns
The SB1-1064-2-100 of our Microchip Series is a short nanosecond pulsed, 2uJ, low SWaP, ultra-compact, 100 kHz, passively Q-switched, DPSS laser. The Microchip series, available at 1064, 946, 532, 473, 355 266, and 236.5nm, is capable of producing single-frequency operation with narrow linewidths, and an M^2 of <1.3 with a ...

Specifications

Avg. Power: 0.2 W
Wavelength: 1064 nm
Repetition Rate: 0.001 – 100 kHz
Spatial Mode (M^2): 1.3
Pulse Duration: 0.4 ns
