Description
The BFLD-D1030-50SM-FA is a high-performance 1030 nm Distributed-Feedback (DFB) laser-diode module designed for precision instrumentation and sensing.
Built on a multi-quantum-well ridge waveguide chip, it delivers up to 50 mW of continuous, single-frequency power from a polarization-maintaining HI1060 fiber pigtail.
The 14-pin butterfly package integrates a thermoelectric cooler, thermistor and monitor photodiode, ensuring wavelength stability of 0.01 nm °C⁻¹ and side-mode suppression >45 dB across -40 to +50 °C. With a linewidth below 3 MHz and polarization extinction above 20 dB, the source is ideal for high-resolution spectroscopy, interferometry and seeding of ultrafast amplifiers.
The device is Telcordia GR-468 qualified, epoxy-free and RoHS compliant, offering long-term reliability for laboratory or field deployment.
1030nm DFB Laser Diode Module
Specifications |
|
|---|---|
| Laser Type: | Continuous Wave (CW) |
| Fiber Type: | Single Mode |
| Wavelength: | 1030 nm |
| Output Power: | 50 mW |
| Fiber Core Diamater: | 6.2 um |
| Fiber Cladding Diameter: | 125 um |
| Fiber Type: | Hi1060 fiber or PM fiber |
| Pigtail Type: | Bare fiber |
| Pigtail Length: | 1.5±0.1m |
Features
- Multi-Quantum well(MQW) Distributed feedback (DFB) lasers;
- CW or pulsed operation;
- Operating temperature range -40℃ to +50℃;
- Wavelength/temperature coefficient 0.01nm/℃;
- Built-in monitor photodiode, thermo-electric cooler and thermistor;
- Single mode fiber pigtail (Corning HI1060, NA=0.14, MFD=6.2um@1060nm);
- Optional FC/APC connector.
Applications
- Spectroscopy;
- Telecom;
- Illumination;
- Sensing.
