Description
The 0785L-15A is a 785 nm diode laser that is fiber-coupled to a single-mode polarization-maintaining fiber. It offers a maximum optical power of up to 130 mW with a polarization contrast of at least 20 dB. The laser features a robust and reliable metal fiber jacket, making it suitable for various applications.
It comes with an FC/PC connector by default, but other fiber terminations can be accommodated upon request. Please consult with the Integrated Optics sales team for details on non-standard connectors and fiber options.
PM Fiber-Coupled Diode Laser (785 nm | 120mW | 0.2nm Linewidth)
Specifications
Laser Type: | Continuous Wave (CW), Modulated |
---|---|
Fiber Type: | Single Mode |
Wavelength: | 785 nm |
Output Power: | 120 mW |
Fiber Core Diamater: | Not Specified |
Fiber Cladding Diameter: | Not Specified |
Spectral Line Width FWHM: | 0.2 nm |
Power Stability: | 0.05 % |
Intensity Noise: | 0.25 % |
Polarization Extinction Ratio: | 27 dB |
Modulation Bandwidth: | 10 MHz |
Input Voltage: | 5 VDC |
External Power Supply Requirement: | +5 V DC, 1.5 A |
Fiber Length: | 1 m |
Optimum Heatsink Temperature: | 20 °C |
Warm-up Time: | 0.5 min |
Dimensions: | 50 x 30 x 18 mm |
Features
- 785 nm diode laser with direct diode technology
- Fiber-coupled to a single-mode polarization-maintaining (PM) fiber
- Maximum optical power output: 130 mW
- Polarization contrast: ≥20 dB
- Robust metal fiber jacket for durability
- FC/PC connector (other terminations available upon request)
- Suitable for optical systems with strong back-reflections (optical isolator required)
- Control interface: UART
- Operation mode: APC (CW)
- Compact dimensions: 50 x 30 x 18 mm
Applications
- Interferometry
- Confocal microscopy (especially with reflective samples)
- Other scientific and industrial applications requiring a 785 nm laser source
Frequently Asked Questions
What is the wavelength of the 0785L-15A-NI-PT-NF laser diode module?
The wavelength of the 0785L-15A-NI-PT-NF laser diode module is 785nm.
What is the output power of the 0785L-15A-NI-PT-NF laser diode module?
The output power of the 0785L-15A-NI-PT-NF laser diode module is 120mW.
What is the warranty period for the 0785L-15A-NI-PT-NF laser diode module?
The warranty period for the 0785L-15A-NI-PT-NF laser diode module is 12 months.
What are the applications of the 0785L-15A-NI-PT-NF laser diode module?
The applications of the 0785L-15A-NI-PT-NF laser diode module include laser diffraction particle analysis, confocal microscopy, food sorting, and flow cytometry.
What are the dimensions of the 0785L-15A-NI-PT-NF laser diode module?
The dimensions of the 0785L-15A-NI-PT-NF laser diode module are 50 x 30 x 18 mm.
