REP2004-DM-B: 2004nm Stabilized Narrow-Linewidth Laser Diode 1950-2150nm

Name: REP2004-DM-B: 2004nm Stabilized Narrow-Linewidth Laser Diode 1950-2150nm
Brand: RPMC Lasers, Inc.
Availability: InStock

Description

The REP series includes high-performance, tunable, single-frequency (DFB-like) diode lasers and Fabry-Perot laser diodes in wavelengths from 1270nm thru 2350nm, designed to address challenges in Gas Sensing, LIDAR, Spectroscopy, and Telecom. The REP series includes high-power and narrow linewidth options, covering various product ranges at the most popular wavelengths, and providing customizable units with multiple packaging options, including the Fiber coupled 14-pin butterfly, TO39 (w/TEC), and TO56.

Benefits:

Discrete-Mode manufacturing technology provides industry-leading performance and fully scalable, consistent production and integration capability.
Highly customizable units with several package options enable customers to choose the right product for their specific needs.
High-power and narrow linewidth options allow customers to optimize performance for their particular applications.
Various product ranges at the most popular wavelengths provide customers with a wide range of options to choose from.

Specifications

Center Wavelength:	2.004 um
Output Power:	3 mW
Forward Current:	140 mA
Forward Voltage:	1.6 V
TEC Current:	1.2 A
Reverse Voltage LD:	2 V
Case Temperature:	-20 to 65 °C
Chip Submount Temperature:	0 to 50 °C
Storage Temperature:	-40 to 85 °C

Got questions about specs? Use the inquiry form to ask.

Download Data Sheet

Features

Integral TEC
PM/SMF Coupled with FC/APC
Built-in Optical Isolator

Applications

Telecommunications: Ideal for use in fiber optic communication systems due to its single-mode operation and compatibility with FC/APC connectors.
Sensing Applications: Suitable for various sensing applications that require precise and stable laser sources.
Research and Development: Useful in laboratory settings for experiments requiring a reliable laser source with a 14-pin butterfly package.
Industrial Applications: Can be integrated into industrial systems that require laser components with specific wavelength bands and packaging options.
Medical Equipment: Applicable in medical devices that utilize laser technology for diagnostics or treatment.

Name

Work Email

Organization (recommended)

Country

Your message to supplier

Ships from:

United States

Sold by:

RPMC Lasers, Inc. ✓ Verified Supplier

On FindLight:

since 2014

Why contact via FindLight?

Message the supplier directly
No signup or account needed
No FindLight fees or markups
Expect a fast reply
Autofill forms with a Buyer Account

Frequently Asked Questions

What is the REP2004-DM-B laser diode used for?

The REP2004-DM-B laser diode is designed to address challenges in Gas Sensing, LIDAR, Spectroscopy, and Telecom.

What are the benefits of the REP2004-DM-B laser diode?

The benefits of the REP2004-DM-B laser diode include industry-leading performance, fully scalable production and integration capability, customizable units with multiple packaging options, high-power and narrow linewidth options, and various product ranges at the most popular wavelengths.

What are the maximum ratings for the REP2004-DM-B laser diode?

The maximum ratings for the REP2004-DM-B laser diode include a forward current of 140 mA, a forward voltage of 1.6 V, a TEC current of 1.2 A, a reverse voltage LD of -2 V, a case temperature range of -20 to 65◦C, and a chip submount temperature range of 0 to 50◦C.

What is the laser safety classification of the REP2004-DM-B laser diode?

The REP2004-DM-B laser diode is classified as a Class 3R Laser Product as defined by International Standard IEC 60825-1, Edition 3.

How can I order the REP2004-DM-B laser diode?

To order the REP2004-DM-B laser diode, you can email your order to sales@eblanaphotonics.com or call +353 1 675 3228. You can also construct your part number using the example provided and include your desired packaging and connector/fiber options.
