Description
The FiberTech® SMA500L ModeStrip Laser Cable is a cutting-edge solution designed to meet the demands of industrial laser applications. This innovative laser cable features a robust construction with an F-SMA freestanding fiber connector, ensuring reliable and efficient performance. The cable is encased in a PVC-coated, steel-armored protection tube, offering superior durability and protection against environmental factors.
At the heart of the FiberTech® SMA500L is a copper-based high-accuracy fiber ferrule. This component is essential for effective heat removal and maintaining high fiber centricity, which is crucial for optimal laser performance. Additionally, the integrated liquid-cooled cladding ModeStripper ensures the removal of unwanted cladding modes, enhancing the quality and precision of laser beam delivery.
Designed to handle laser power of up to 500 W, the FiberTech® SMA500L is an ideal choice for applications requiring high power and precision. Its all-silica step-index fiber is available with a numerical aperture (NA) of 0.22, with the option for a lower NA of 0.12 or a graded-index fiber upon request. The cable also features keyed SMA905 connectors and metal connector cuffs, providing secure and stable connections throughout its usage.
With fiber centricity maintained at less than 5 µm from the fiber core to the ferrule, the FiberTech® SMA500L ensures minimal signal loss and maximum efficiency. The squarelock, blue PVC-coated protection tube not only adds to its aesthetic appeal but also enhances the overall structural integrity of the cable. Whether for industrial use or other high-demand environments, this laser cable is engineered to deliver superior performance and reliability.
SMA500L Laser Cables - FCL26-10200-2000
Specifications |
|
|---|---|
| Fiber Core Diameter: | 100 um |
| Cable Length: | 2 m |
| Average Laser Power: | 500 W |
| Numerical Aperture (NA): | 0.22 |
| Fiber Centricity: | < 5 µm |
Features
- High-Performance Laser Cable: Equipped with F-SMA freestanding fiber connectors and a PVC-coated, steel-armored protection tube for robust and reliable performance.
- Efficient Heat Management: Features a copper-based high-accuracy fiber ferrule for effective heat removal and high fiber centricity.
- Integrated Liquid-Cooled Technology: Comes with a liquid-cooled cladding-ModeStripper, ensuring efficient cladding mode removal.
- Versatile Fiber Options: Utilizes VIS-IR all-silica (silica/silica) step-index fiber with NA = 0.22, with options for NA = 0.12 and graded-index fiber available upon request.
- Advanced Connector Design: SMA905 (F-SMA) connector with a free-standing fiber tip and hex nut, with keyed connectors available on request.
- Superior Construction: All copper alloy parts for improved heat removal and a fiber centricity of less than 5 µm fiber core to ferrule.
- Durable Protection: Squarelock, blue PVC-coated protection tube with metal connector cuffs for enhanced cable integrity.
- Electrical Isolation: Provides electrical isolation from end to end, ensuring safe and efficient operation.
- High Power Capacity: Supports average laser power up to 500 W, ideal for industrial laser applications.
Applications
- Industrial Laser Machining: Ideal for precision cutting, drilling, and micromachining operations.
- Laser Welding Systems: Supports robust and stable welding processes with high thermal loads.
- Medical Laser Applications: Suitable for surgical laser devices requiring safe and efficient delivery.
- Research and Development: Enables reliable performance in optical and laser laboratories.
- Laser Marking and Engraving: Ensures stable transmission for high-precision marking tasks.
Frequently Asked Questions
The SMA500L Laser Cables are made of VIS-IR all-silica (silica/silica) step-index fiber with NA = 0.22 NA = 0.12 on request Graded-index fiber on request, SMA905 (F-SMA) connector with free-standing fiber tip, hex nut, all copper alloy parts for improved heat removal, and a squarelock, blue PVC-coated protection tube.
Yes, there are different types of SMA500L Laser Cables available with varying fiber core Ø and cable length. The type designation and order numbers are listed in the datasheet.
The integrated liquid-cooled cladding-ModeStripper is used for cladding mode removal.
The fiber centricity of the SMA500L Laser Cables is < 5 μm fiber core to ferrule.
The SMA500L Laser Cables are applicable for laser beam delivery of up to 500 W.
