Filter Products

Operating Wavelength (nm)

Please enter number. to Please enter number.

Operating Bandwidth (nm)

Please enter number. to Please enter number.

Isolation (min) (dB)

Please enter number. to Please enter number.

Max Power Handling (W)

Please enter number. to Please enter number.

Fiber Optics
Optical Networking
Wavelength-Division Multiplexing (WDM)

Wavelength-Division Multiplexing (WDM) (Polarization Maintaining: No)

Filter (0)

Compact CWDM Module 1x6 (+1)

Inquire Price

Sold by: Lfiber Optic Limited Ships from: China

Specifications
Operating Wavelength:	1271 nm
Operating Bandwidth:	13 nm
Isolation (min):	40 dB
Max Power Handling:	300 W
Polarization Maintaining:	No

Mini CWDM 1x8 (+1)

Inquire Price

Sold by: Lfiber Optic Limited Ships from: China

Specifications
Connector:	None, LC/UPC, LC/APC, SC/UPC, SC/APC, Custom …
Channel Number (CH):	8
Fiber Type:	SMF-28e Compatible; 900 μm Loose Tube
Central Wavelength (nm):	1271 to 1611; 1270 to 1610
Operating Temperature (°C):	-5 to +70 (Commercial); -40 to +85(Industrial)

Mini-Sized CWDM 1x10 (+1)

Inquire Price

Sold by: Lfiber Optic Limited Ships from: China

Specifications
Connector:	None, LC/UPC, LC/APC, SC/UPC, SC/APC, Custom …
Channel Number (CH):	10
Insertion Loss (dB):	1.0 (Typical); 2.0 (Max)
Fiber Type:	SMF-28e Compatible; 900 μm Loose Tube
Operating Temperature:	-5 to +70 (Commercial); -40 to +85 (Industrial)

Low-Loss CWDM Module 1x18 (+1)

Inquire Price

Sold by: Lfiber Optic Limited Ships from: China

Specifications
Connector:	None, LC/UPC, LC/APC, SC/UPC, SC/APC, Custom …
Channel Number (CH):	18
Fiber Type:	SMF-28e Compatible; 900 μm Loose Tube
Central Wavelength (nm):	ITU CWDM Grid: 1271 to 1611; (OR) 1270 to 1610
Operating Temperature:	-5 to +70 (Commercia); -40 to +85 (Industrial)

CCWDM Module 1x16 (+1）

Inquire Price

Sold by: Lfiber Optic Limited Ships from: China

Specifications
Connector:	None, LC/UPC, LC/APC, SC/UPC, SC/APC, Custom …
Channel Number (CH):	16
Fiber Type:	SMF-28e Compatible; 900 μm Loose Tube
Central Wavelength (nm):	ITU CWDM Grid: 1271 to 1611; (OR) 1270 to 1610
Operating Temperature:	-5 to +70 (Commercial) ; -40 to +85(Industrial)

CWDM Modules

Inquire Price

Sold by: Lfiber Optic Limited Ships from: China

Specifications
Package:	ABS Box, LGX, 19” Rackmount
Channel Number:	4 Channel, 8 Channel, 16 Channe, 18 Channel
Central Wavelength (nm):	ITU CWDM Grid: 1271 to 1611; (OR) 1270 to 1610
Channel Spacing (nm):	20
Fiber Type:	SMF-28e compatible fiber

Bandpass Filter -1528-1565nm

Inquire Price

Sold by: GKER Photonics Ships from: China

Specifications
Wavelength Range:	1528 - 1565 nm
Max. Insertion Loss:	0.7 dB
Typ. Insertion Loss:	0.5 dB
Min. Isolation @ Wavelength ＜ 1521 Nm And ＞ 1574 Nm:	12 dB
Min. Return Loss:	50 dB

635-1064 nm Wavelength Division Multiplexers

Inquire Price

Sold by: GKER Photonics Ships from: China

Specifications
Longer Operating Wavelength:	1064 ± 5 nm
Max. Insertion Loss:	0.2 dB
Max. Polarization Dependent Loss:	0.1 dB
Min. Isolation:	20 dB
Shorter Operating Wavelength:	635 ± 5 nm

1080nm 5W Bandpass Filter

Inquire Price

Sold by: GKER Photonics Ships from: China

Specifications
Center Wavelength:	1080 nm
Min.Filter Pass Band @ - 0.5 DB:	5 nm
Max. Insertion Loss Over Pass Band:	1.0 dB
Wavelength Suppression (1030 - 1070 & 1090 - 1150 Nm):	25 dB
Max. Polarization Dependent Loss:	0.1 dB

1030nm 10w Bandpass Filter

Inquire Price

Sold by: GKER Photonics Ships from: China

Specifications
Center Wavelength:	1030 nm
Min. Filter Pass Band @ - 0.5 DB:	2 nm
Max. Insertion Loss Over Pass Band:	1.0 dB
Wavelength Suppression (1000 - 1025 & 1035 - 1100 Nm):	30 dB
Max. Insertion Loss Over Reflect Band For 3 Ports:	0.7 dB

Ascentta CWDM Module 8-channel (Ask for Mini Pkg.)

Inquire Price

Sold by: Ascentta Ships from: United States

Specifications
Insertion Loss (23℃, All SOP) Max.:	2.6 dB
Directivity Min.:	50 dB
Return Loss Min.:	45 dB
Operating Temperature:	0 to +70 °C
Storage Temperature:	-40 to +85 °C

1530 -1542nm C Band Red/Blue Wavelength Division Multiplexer

Inquire Price

Sold by: GKER Photonics Ships from: China

Specifications
Pass Band Wavelength Range:	1530 - 1542 (1548 - 1560) nm
Max. Insertion Loss:	0.6 dB
Storage Temperature:	- 40 to + 85 ℃
Typ. Insertion Loss:	0.4 dB
Min. Isolation:	22 dB

1528 -1565nm Bandpass Filter

Inquire Price

Sold by: GKER Photonics Ships from: China

Specifications
Wavelength Range:	1528 - 1565 nm
Max. Insertion Loss:	0.7 dB
Typ. Insertion Loss:	0.5 dB
Min. Isolation @ Wavelength ＜ 1521 Nm And ＞ 1574 Nm:	12 dB
Min. Return Loss:	50 dB

635 -1064 nm Wavelength Division Multiplexers-WDM

Inquire Price

Sold by: GKER Photonics Ships from: China

Specifications
Longer Operating Wavelength:	1064 ± 5 nm
Max. Insertion Loss:	0.2 dB
Max. Polarization Dependent Loss:	0.1 dB
Min. Isolation:	20 dB
Shorter Operating Wavelength:	635 ± 5 nm

976 -1064 nm Singlemode Wavelength Division Multiplexers-WDM

Inquire Price

Sold by: GKER Photonics Ships from: China

Specifications
Center Wavelength (λc):	976, 1064 nm
Operating Wavelength:	λc ± 5 nm
Min. Isolation:	13 dB
Max. Insertion Loss:	0.35 dB
Thermal Stability:	≤ 0.002 dB/℃

635 -1064nm Fused Wavelength Division Multiplexer

Inquire Price

Sold by: GKER Photonics Ships from: China

Specifications
Longer Operating Wavelength:	1064 ± 50, specified nm
Max. Insertion Loss:	0.7 dB
Min. Isolation:	10 dB
Shorter Operating Wavelength:	635 ± 10, or specified dB
Max. Insertion Loss:	1 nm

Dense Wavelength Division Multiplexer

Inquire Price

Sold by: GKER Photonics Ships from: China

Specifications
Filter Type:	100 GHz 200 GHz -
Center Wavelength:	ITU Grid nm
Min. Bandwidth @ 0.5 DB:	0.22 0.5 nm
Max. Insertion Loss:	0.8 dB
Min. Channel Isolation:	25 dB

2 µm Fused Wavelength Division Multiplexer

Inquire Price

Sold by: GKER Photonics Ships from: China

Specifications
Longer Operating Wavelength:	2000 ± 20, or specified nm
Max. Insertion Loss:	0.6 dB
Min. Isolation:	13 dB
Max. Polarization Dependent Loss:	0.15 dB
Shorter Operating Wavelength:	1570 ± 20 800± 20 650 ± 20 nm

980/1550 nm Singlemode Wavelength Division Multiplexers

Inquire Price

Sold by: GKER Photonics Ships from: China

Specifications
Center Wavelength (λc):	980/1550 nm
Operating Wavelength:	λc ± 15 nm
Min. Isolation:	20 dB
Max. Insertion Loss:	0.15 dB
Max. Polarization Dependent Loss:	0.1 dB

2 µm Filter Wavelength Division Multiplexer

Inquire Price

Sold by: GKER Photonics Ships from: China

Specifications
Pass Band Wavelength Range:	1950 - 2050 nm
Typ. Insertion Loss:	0.6 dB
Storage Temperature:	- 40 to + 85 ℃
Max. Insertion Loss:	0.8 dB
Typ. Isolation:	30 dB

980nm Filter Wavelength Division Multiplexer

Inquire Price

Sold by: GKER Photonics Ships from: China

Specifications
Pass Band Wavelength Range:	980 ± 10 nm
Max. Insertion Loss:	0.7 dB
Min. Isolation:	25 dB
Reflection Band Wavelength Range:	1060 ± 40 nm
Max. Insertion Loss:	0.6 dB

1064nm 300mw Bandpass Filter

Inquire Price

Sold by: GKER Photonics Ships from: China

Specifications
Center Wavelength:	1064 nm
CWL Tolerance:	± 1 ± 0.5 nm
Filter Pass Band @ -0.5 DB:	2 8 nm
Max. Insertion Loss Over Pass Band:	0.8 0.8 dB
Wavelength Suppression @ (1020 - 1058 & 1070 - 1100 Nm) For 2 Nm:	25 N/A dB

1550nm Filter Wavelength Division Multiplexer

Inquire Price

Sold by: GKER Photonics Ships from: China

Specifications
Pass Band Wavelength Range:	1550 nm
Min.Pass Band Width@0.5 DB:	5 nm
Max. Insertion Loss:	0.6 dB
Min. Isolation:	25 dB
Reflection Band Wavelength Range:	1520 - 1544 & 1556 - 1610 nm

Coarse Wavelength Division Multiplexers

Inquire Price

Sold by: GKER Photonics Ships from: China

Specifications
Filter Type:	Half Band Full Band -
Operating Wavelength Range:	1460 - 1620 1260 - 1620 nm
Center Wavelength:	1471,1491,1511,1531,1551,1571,1591,1611 nm
Min. 0.5 DB Pass Bandwidth:	13 nm
Max. Transmission Insertion Loss:	0.6 dB

On FindLight marketplace you will find 39 different Wavelength-Division Multiplexing (WDM) (Polarization Maintaining: No) from top global suppliers. Compare features, request pricing, and connect instantly with manufacturers — no registration required.
