BOSA Modules for Optical Networking Applications

Did You Know?

Did you know that a typical bidirectional optical sub-assembly (BOSA) achieves over 40 dB isolation between its transmit laser and receive photodiode, despite both sharing the same fiber via a tiny WDM filter or beamsplitter? This isolation is critical because back-reflections and residual transmit light can saturate the PIN/APD receiver long before you approach the −28 to −34 dBm sensitivity range common in access and PON optics. BOSAs also have to maintain tight optical alignment on the order of a few micrometers between the laser, filter, and photodiode to keep insertion loss below about 1–2 dB in compact TO or TOSA/ROSA-style packages.
Read more in our Blog

Related Resources

Frequently Asked Questions

A BOSA (Bidirectional Optical Sub-Assembly) is an integrated module that combines a transmitter and receiver on a single optical port to enable bidirectional communication over one fiber. Typically, it integrates a laser diode (TX), a photodiode (RX), WDM filter elements, and coupling optics in a compact package used in ONUs/ONTs and CPE for PON and other access systems.

What Is a BOSA?

A BOSA (Bi-directional Optical Sub-Assembly) is a compact module that integrates a laser transmitter and photodiode receiver into a single optical interface. In fiber-optic access systems, a BOSA enables upstream and downstream communication over a single fiber using wavelength-division multiplexing (WDM) with separate Tx/Rx wavelengths.

Typical BOSA designs include a laser diode (FP or DFB), a photodiode (PIN or APD), WDM filters or dichroic mirrors, and an optical coupling structure aligned to a fiber pigtail or receptacle. This integrated approach reduces footprint and alignment complexity compared with discrete Tx/Rx modules.

Typical Specifications for BOSA Modules

Key parameters you will encounter when evaluating a BOSA on FindLight include:

  • Data rate: Commonly 1.25 Gbps, 2.5 Gbps, 10 Gbps and above, depending on PON or Ethernet standard.
  • Wavelengths: Typical BOSA combinations include 1310/1490 nm, 1270/1330 nm, or other CWDM pairs, with defined Tx and Rx roles.
  • Optical output power: Laser average power (dBm) and extinction ratio, impacting link budget.
  • Receiver sensitivity: Minimum detectable power (dBm) at a specified BER, often 1E-12.
  • Package and interface: SFP/SFP+ compatible, TOSA/ROSA-style cans, or custom sub-assemblies with fiber pigtail or LC/SC connector.
  • Operating temperature: Commercial (0–70 °C) or industrial (–40–85 °C) ranges, with or without TEC.
  • Supply voltage and power consumption: For compatibility with existing transceiver or ONU designs.

Use Cases for BOSA Components

BOSA modules are used in FTTH/FTTx PON ONUs and OLTs, point-to-point bi-directional links, industrial Ethernet over single fiber, and compact media converters. They are suited to applications where fiber count, board space, or connector density is constrained.

Buyer Guidance on FindLight

When selecting a BOSA on FindLight, start by matching data rate and Tx/Rx wavelengths to your target standard (e.g., GPON, EPON, 10G-PON, BiDi Ethernet). Confirm that launch power, receiver sensitivity, and dispersion tolerance meet your link budget and distance requirements. Check package type, fiber connectorization, and pinout against your existing transceiver or board design.

Use the detailed product listings to compare BOSA specifications side by side, focusing on optical performance, operating temperature, and reliability ratings. For pricing, lead time, or customization of a BOSA (such as alternative wavelengths or pigtail options), you can request quotes from suppliers directly through FindLight. No registration is required to initiate technical inquiries or RFQs, allowing you to streamline component selection for your optical networking project.
