15mm Sapphire Lens with Anti-Reflection (AR) Coating – 3mm Thickness
For pricing, technical or any other questions please contact the supplier
- No registration required
- No markups, no fees
- Direct contact with supplier
Contact Supplier
How to order?
-
Ships from:
China
-
Sold by:
Henyuan Sapphire Optics Co., Ltd. -
On FindLight:
since 2025
Description
The SL15-3PE Sapphire Lens is a high-performance optical component designed for demanding applications that require superior durability, chemical resistance, and broad spectral transmission.
Made from optical-grade single-crystal sapphire, this 15.0mm diameter, 3.0mm thick lens offers excellent optical clarity across UV, visible, and infrared wavelengths (0.15–5.5µm).
The anti-reflection (AR) coating enhances transmission, achieving >90% efficiency in the 610–1200nm range, reducing reflection losses for high-precision optical systems. With extreme hardness (Mohs 9), exceptional thermal stability, and resistance to abrasion, high pressures, and harsh chemicals, this lens is ideal for use in laser optics, infrared imaging, aerospace, and industrial applications.
15mm Sapphire Lens with Anti-Reflection (AR) Coating – 3mm Thickness
Specifications |
|
|---|---|
| Material: | Al2O3 (Sapphire) |
| Diameter: | 15 mm |
| Edge Thickness, Te: | 3 mm |
| Lens Type: | Plano-Concave |
| Diameter Options: | 2.0 mm – 200 mm |
| Lens Types Available: | Concave, Convex, Meniscus |
| Surface Quality: | 40/20, 20/10 |
| Edge Finish: | Fine Ground |
| Dimensional Tolerance: | ±0.1 mm |
| Centration: | ≤ 3 arc minutes |
| Clear Aperture: | >90% |
Features
A leading manufacturer of Sapphire optics in China, Henyuan Sapphire Optics offers a wide range of sapphire components including Sapphire windows, sapphire lens, sapphire balls, Ruby balls, Sapphire tubes, Ruby rods & Sapphire rods, Sapphire orifice, Sapphire substrate, Sapphire prisms.
- Broad Optical Transmission: High clarity across UV, visible, and IR (0.15–5.5µm).
- Durability & Scratch Resistance: Mohs hardness of 9 prevents scratches and mechanical wear.
- Anti-Reflective Coating: AR-coated for >90% transmission efficiency at 610–1200nm, reducing light loss.
- High Thermal Stability: Melting point of 2030°C ensures performance in extreme temperatures.
- Chemical Resistance: Inert to strong acids and corrosive environments, making it highly durable.
- Precision Engineering: High-quality surface finish (60/40 S/D), tight dimensional tolerances (±0.1mm), and fine-ground edges for superior optical performance.
Applications
- Laser Systems & Optics – Ideal for high-energy laser applications due to its high damage threshold and thermal stability.
- Infrared Imaging & Sensors – Used in thermal cameras, night vision devices, and IR spectroscopy.
- Aerospace & Defense – Resistant to extreme temperatures, pressure, and radiation, making it suitable for satellites and military optics.
- Medical & Scientific Equipment – Utilized in microscopy, biomedical imaging, and spectroscopy.
- Industrial & Harsh Environments – Performs exceptionally well in vacuum chambers, high-pressure systems, and chemically aggressive settings.
Frequently Asked Questions
The Sapphire Lens SL15-3PE is made from optical grade single Sapphire crystal.
The Sapphire Lens SL15-3PE has a diameter of 15.0mm and a thickness of 3.0mm, with a tolerance of ±0.1mm.
The AR coating on the Sapphire Lens provides a transmission greater than 90% in the range of 610 to 1200nm.
The surface quality of the Sapphire Lens SL15-3PE is specified as 60/40 S/D.
Sapphire Lenses have excellent transmission bandwidths between the UV and IR at 0.15-5.5µm, are extremely hard and resistant to strong acids, highly resistant to scratching and abrasion, and have an extremely high melting temperature of 2030°C. They are suitable for extreme conditions such as high-pressure, vacuum, and corrosive atmospheres.
Custom specifications for Sapphire Lenses include diameters from 2.0 mm to 200mm, various radii of curvature (concave, convex, meniscus), surface qualities of 40/20 or 20/10, fine ground edges, tolerance of ±0.1mm, centration of 3 arc minutes, and a clear aperture of greater than 90%.
Sapphire Lenses have a hardness of 9 on the Mohs scale of mineral hardness.
