Cylindrical

Cylindrical Lenses
Chang Chun Bo Xin Photoelectric Co., Ltd.
Add to watch list
Cylindrical Lenses
Compare
The cylindrical lens is a spherical lens, which is able to reduce the ball difference and color difference effectively. It divided into flat convex cylindrical lens, plane concave cylindrical lens, double convex cylindrical lens and double concave cylindrical lens. Have a single-dimensional amplification function. High Precision ...

Specifications
Lens Type: Positive
Material: BK7
Size: 50 mm
Focal Length: 150 mm
Data Sheet
Photonchina Cylindrical Lens
Photonchina
Add to watch list
Photonchina Cylindrical Lens
Compare
Cylindrical lens, also called a cylinder, is an optical lens which focuses light on to a line instead of on to a point, as a spherical lens would. The curved face or faces of a cylindrical lens are sections of a cylinder, and focus the image passing through it onto a line parallel to the intersection of the surface of the lens and a ...

Specifications
Lens Type: Positive, Negative
Material: BK7, FS, UVFS, CaF2, ZnSe, Ge, H-K9L
Size: Custom mm
Focal Length: Custom mm
Data Sheet
Cylindrical Achromatic Doublets
Photonchina
Add to watch list
Cylindrical Achromatic Doublets
Compare
Cylindrical Achromatic Doublets Photonchina manufactures cylindrical achromatic doublets in both wavelength of visible and NIR. Our lenses are typically used to focus polychromatic light in one direction only while minimizing chromatic aberration. They create a line focus instead of a point focus, as seen in spherical lenses. Our ...

Specifications
Lens Type: Positive, Negative
Material: BK7, FS, UVFS, CaF2, ZnSe, Ge, H-K9L
Size: custom mm
Focal Length: custom mm
Data Sheet
Rod Lenses -Cylindrical Lenses
SZLASER
Add to watch list
Rod Lenses -Cylindrical Lenses
Compare
Rod Lenses are a special variant of cylindrical lenses. They are complete rods where the light passes through the sides of the rod and focuses a line. Rod lenses have a barrel face that is polished and the ends ground. Call Us via +86-755-8378 2881  |  Email us sales@szlaser.com | www.szlaser.com

Specifications
Lens Type: Positive, Negative
Material: BK7, UVFS
Size: 1~10 mm
Focal Length: on request mm
Diameter Tolerance: ±10%
...
Data Sheet
Micro Size Rod Lenses- For Endoscope
SZLASER
Add to watch list
Micro Size Rod Lenses- For Endoscope
Compare
Micro Rod Lenses are available with flat, plano-convex, plano-concave, cemented etc which applied in medical endoscopes.Rod lens systems use special glass rods with optically finished ends, providing images with higher brightness, contrast and colour reproduction than conventional lenses.   Call Us via +86-755-8378 2881  ...

Specifications
Lens Type: Positive, Negative
Material: BK7, UVFS
Size: Ø0.6mm or customization mm
Focal Length: on request mm
Lens Type: 1. Cemented 2. Flat/Flat 3. Plano-Convex 4. Plano-Concave 5. Double Convex
...
Data Sheet
Laser Grade Plano convex cylinder lens
BRD Optical Ltd
Add to watch list
Laser Grade Plano convex cylinder lens
Compare
A positive cylindrical lens is able to create a line image from a point of light, to change the aspect ratio of an image or to focus collimated input light to a line. Plano- convex cylindrical lenses are typically used for illumination of slit and line detector arrays, laser projection, laser line focussing and anamorphic beam shaping.

Specifications
Lens Type: Positive
Material: BK7
Size: 30 mm
Focal Length: 50 mm
Material: Optical glass/ Fused silica
...
Data Sheet
Optical Lenses Of Intricate Shapes
A Optical Components Ltd
Add to watch list
Optical Lenses Of Intricate Shapes
Compare
Singlet, doublets and triplets lenses.‎ any required size Ø5 mm- 300mm‎ A. Optical Components LTD supplies custom made optical lenses, ‎made to perform different functions, ranging from a simple collection of light to ‎precise imaging. Optical Lenses may be made to precision or commercial quality.‎ ...

Specifications
Lens Type: Positive
Material: BK7, ZnSe
Size: 5-300 mm
Focal Length: -- mm
Data Sheet
Custom Plano-Concave Cylindrical Lenses
Changchun Long Ze Precision Optics Co Ltd
Add to watch list
Custom Plano-Concave Cylindrical Lenses
Compare
CLZ precision optics provide custom optical component for laser systems and imaging systems. Such as cylindrical lenses. Plano-Concave Cylindrical Lenses is a common cylindrical lenses,  it available with negative focal lengths, ideal for laser line, anamorphic beam expansion. When used in combination with a plano-convex ...

Specifications
Lens Type: Negative
Material: UVFS
Size: -- mm
Focal Length: -- mm
Data Sheet
UV Fused Silica Plano-Concave Cylindrical Positive Lenses
Changchun Long Ze Precision Optics Co Ltd
Add to watch list
UV Fused Silica Plano-Concave Cylindrical Positive Lenses
Compare
Plano-Convex Cylindrical Lenses is a common cylindrical lenses,  it available with positive focal lengths, ideal for laser line, uni-axial magnification,  Circularizing the Beam from a Laser Diode and combined with other lenses to form complex imaging systems.

Specifications
Lens Type: Positive
Material: UVFS
Size: -- mm
Focal Length: -- mm
Data Sheet
UV Fused Silica Plano-Concave Cylindrical Negative Lenses
Changchun Long Ze Precision Optics Co Ltd
Add to watch list
UV Fused Silica Plano-Concave Cylindrical Negative Lenses
Compare
Plano concave (PCV) cylindrical lenses is negative cylinders lenses, it have one flat surface and one concave surface and have a negative focal length, used to diverge collimated light in a single axis, best for one-dimensional compression of images, laser line generation, and anamorphic beam shaping.

Specifications
Lens Type: Negative
Material: UVFS
Size: -- mm
Focal Length: -- mm
Data Sheet
Fused Silica Plano-Convex Cylindrical Lens PCX2712
Changchun Fortune Optronics Inc
Add to watch list
Fused Silica Plano-Convex Cylindrical Lens PCX2712
Compare
Fused Silica Plano-Convex Cylindrical Lenses.

Specifications
Lens Type: Positive
Material: UVFS
Size: 7.2 mm
Focal Length: 8 mm
Data Sheet
BK7 Plano-Concave Cylindrical Lens PXV001
Changchun Fortune Optronics Inc
Add to watch list
BK7 Plano-Concave Cylindrical Lens PXV001
Compare
BK7 Plano-Concave Cylindrical Lenses.

Specifications
Lens Type: Negative
Material: BK7
Size: 6 mm
Focal Length: -3.9 mm
Data Sheet
BK7 Plano-Convex Cylindrical Lens PXC101
Changchun Fortune Optronics Inc
Add to watch list
BK7 Plano-Convex Cylindrical Lens PXC101
Compare
BK7 Plano-Convex Cylindrical Lenses.

Specifications
Lens Type: Positive
Material: BK7
Size: 6 mm
Focal Length: 3.9 mm
Data Sheet
Doric Lenses Cylindrical Lenses
Doric Lenses Inc
Add to watch list
Doric Lenses Cylindrical Lenses
Compare
Single cylindrical macrolenses are made of optically transparent and homogeneous materials limited by cylindrical surfaces of constant radius. When one of these radii is infinite, it becomes plano-convex or plano-concave lens. We can produce these lenses in lengths of up to 500 mm.

Specifications
Lens Type: Positive
Material: BK7
Size: 500 mm
Focal Length: -- mm
Data Sheet
GRIN Rod Lenses Numerical Aperture 0.5 1.80mm
GRINTECH GmbH
Add to watch list
GRIN Rod Lenses Numerical Aperture 0.5 1.80mm
Compare
Gradient index lenses for fiber coupling and beam shaping of laser diodes.

Specifications
Lens Type: Positive
Material: ZnSe
Size: 4.24 mm
Focal Length: 1.66 mm
Data Sheet
GRIN Rod Lenses Numerical Aperture 0.5 1.0mm
GRINTECH GmbH
Add to watch list
GRIN Rod Lenses Numerical Aperture 0.5 1.0mm
Compare
Gradient index lenses for fiber coupling and beam shaping of laser diodes.

Specifications
Lens Type: Positive
Material: ZnSe
Size: 2.25 mm
Focal Length: 0.88 mm
Data Sheet
GRIN Rod Lenses Numerical Aperture 0.5 0.50mm
GRINTECH GmbH
Add to watch list
GRIN Rod Lenses Numerical Aperture 0.5 0.50mm
Compare
Gradient index lenses for fiber coupling and beam shaping of laser diodes.

Specifications
Lens Type: Positive
Material: ZnSe
Size: 1.15 mm
Focal Length: 0.45 mm
Data Sheet
Precision Grade Plano-Convex Cylindrical Lens NBK-7 200-120
K&S Optics Inc
Add to watch list
Precision Grade Plano-Convex Cylindrical Lens NBK-7 200-120
Compare
Precision Grade Plano-Convex Cylindrical Lens NBK-7.

Specifications
Lens Type: Positive
Material: BK7
Size: 12.5 mm
Focal Length: 4.0 mm
Data Sheet
Commercial Grade Plano-Concave Cylindrical Lens NBK-7 150-0120
K&S Optics Inc
Add to watch list
Commercial Grade Plano-Concave Cylindrical Lens NBK-7 150-0120
Compare
Commercial Grade Plano-Concave Cylindrical Lens NBK-7.

Specifications
Lens Type: Negative
Material: BK7
Size: 12.5 mm
Focal Length: -4.0 mm
Data Sheet
Commercial Grade Plano-Convex Cylindrical Lens NBK-7 100-0120
K&S Optics Inc
Add to watch list
Commercial Grade Plano-Convex Cylindrical Lens NBK-7 100-0120
Compare
Commercial Grade Plano-Convex Cylindrical Lens NBK-7.

Specifications
Lens Type: Positive
Material: BK7
Size: 12.5 mm
Focal Length: 4.0 mm
Data Sheet
Cylindrical and toroid lenses
Sinoptix
Add to watch list
Cylindrical and toroid lenses
Compare
Cylindrical and toroid custom lenses.  Manufacturing and control of these lenses need specific equipments, we can provide you with the best solution for it.  https://sinoptix.fr/optical-components-showroom/lenses/cylindrical-lenses/

Specifications
Lens Type: Positive, Negative
Material: BK7, FS, UVFS, CaF2, ZnSe, Ge, H-K9L
Size: up to 500 mm
Focal Length: custom mm
Customization: according to your drawings
Data Sheet
Rod Lens
Unioriental Optics Co Ltd
Add to watch list
Rod Lens
Compare
Rod Lens is designed for use in a variety of laser and imaging applications. The addition of this product line is part of a continued effort to support current trends toward miniaturization. Unioriental produces kinds rod lens based on different material and sizes. N-BK7 and UV Fused Silica substrates are available. Its ...

Specifications
Lens Type: Positive
Material: BK7, UVFS
Size: -- mm
Focal Length: -- mm
Data Sheet
High Performance Cylinder Lenses
Edmund Optics
Add to watch list
High Performance Cylinder Lenses
Compare
Focuses light in only one dimension. Similar to a PCX lens in profile, but is a portion of a cylinder instead of a sphere. Cylinder lenses can transform a point of light into a line image. This is useful for making laser line generators. The lens magnifies in one dimension so it can be used for stretching images. Can be used for ...

Specifications
Lens Type: Positive
Material: BK7
Size: 5.00 mm
Focal Length: 8.00 mm
Data Sheet
Optical Surfaces Cylindrical Lenses
Optical Surfaces
Add to watch list
Optical Surfaces Cylindrical Lenses
Compare
Optical Surfaces lens production has been a core part of its business from the beginning. The range offered includes singlets, doublets, meniscus and cylindrical lenses all up to 600mm in diameter. We hold an extensive range of test plates and tools to cover most sizes and radii. Custom air spaced assemblies are available on request.

Specifications
Lens Type: Positive
Material: BK7
Size: 600 mm
Focal Length: Custom mm
Data Sheet
Sumita Aspherical Cylindrical Lens Array
Sumita Optical Glass
Add to watch list
Sumita Aspherical Cylindrical Lens Array
Compare
Precision molding actualized, aspherical cylindrical lens array, of which the shape is designed so that cylindrical surfaces with different shapes are orthogonal to both sides of a glass plate. Each cylindrical surface can also be designed as aspherical shape. This is optimum for integrator optics. The shape is designed so that ...

Specifications
Lens Type: Positive
Material: BK7
Size: 8 mm
Focal Length: 1 mm
Data Sheet

Did You know?

Unlike ordinary lenses, cylindrical lens focusses the light onto a line rather than on point due to the spherical radius being in one direction only. Cylindrical lenses are used in different applications like the correction of astigmatism, bar code scanning or laser projection. They are ideal for circularization of diode laser outputs, energy collection for linear detectors or for coupling to a slit input on monochromators or spectrometers. Another typical application of a is in the light sheet microscope where a cylindrical lens is placed in front of the illumination objective to create the light sheet used for imaging.
