50mm Dome windows for Pyranometer
BRD Optical Ltd
Add to watch list
50mm Dome windows for Pyranometer
Compare
Optical domes can be found on forward looking infrared systems, seeker head optical systems, in submersibles, and underwater camera systems. Airborne systems must be designed to withstand sand, intense temperature differentials, and other challenging environmental conditions.
  • Material: BK7
  • Diameter: 50 mm
  • ROC1: 25 mm
  • ROC2: 21 mm
  • Material : BK7
  • ...
Data Sheet
Meniscus Lens
Optical Surfaces
Add to watch list
Meniscus Lens
Compare
Optical Surfaces lens production has been a core part of its business from the beginning. The range offered includes singlets, doublets, meniscus and cylindrical lenses all up to 600mm in diameter. We hold an extensive range of test plates and tools to cover most sizes and radii. Custom air spaced assemblies are available on request.
  • Material: BK7
  • Diameter: 600 mm
  • ROC1: Custom mm
  • ROC2: Custom mm
Data Sheet
Sumita Ultra Micro Lens
Sumita Optical Glass
Add to watch list
Sumita Ultra Micro Lens
Compare
The ultra micro lens made of high index glass enables endoscopes to take wide pictures.
  • Material: BK7
  • Diameter: 0.35 mm
  • ROC1: 0.4 mm
  • ROC2: -- mm
Data Sheet
YuTai Optics Meniscus Lens
Yutai Optics
Add to watch list
YuTai Optics Meniscus Lens
Compare
One side of meniscus lens is convex, another side is concave. It can be a convergent lens or a divergent lens, which is decided together by refractive index, curvature and radius.
  • Material: BK7, FS, CaF2, Ge
  • Diameter: 300 mm
  • ROC1: -- mm
  • ROC2: -- mm
Data Sheet
West Coast Tech Limited Negative Meniscus Lens
West Coast Tech
Add to watch list
West Coast Tech Limited Negative Meniscus Lens
Compare
The best lens from where one conjugates is relatively for from the lens or where both conjugates are the same size of the lens.
  • Material: BK7, FS, CaF2, Ge
  • Diameter: 100 mm
  • ROC1: Custom mm
  • ROC2: Custom mm
Data Sheet
West Coast Tech Limited Positive Meniscus Lens
West Coast Tech
Add to watch list
West Coast Tech Limited Positive Meniscus Lens
Compare
These lenses may be used to increase the numerical aperture of a positive lens assembly, without an undue increase in the aberrations.
  • Material: BK7, FS, CaF2, Ge
  • Diameter: 25 mm
  • ROC1: Custom mm
  • ROC2: Custom mm
Data Sheet
Technooptic Negative Meniscus Lens
Technooptic
Add to watch list
Technooptic Negative Meniscus Lens
Compare
Negative or divergent meniscus lens for applications in laser optics, vision, and more.
  • Material: BK7
  • Diameter: Custom mm
  • ROC1: Custom mm
  • ROC2: Custom mm
Data Sheet
Technooptic Positive Meniscus Lens
Technooptic
Add to watch list
Technooptic Positive Meniscus Lens
Compare
Positive or convergent meniscus lens for applications in laser optics, vision, and more.
  • Material: BK7
  • Diameter: Custom mm
  • ROC1: Custom mm
  • ROC2: Custom mm
Data Sheet
Meniscus Lenses
Sunny Precision Optics
Add to watch list
Meniscus Lenses
Compare
Meniscus Lenses for applications in vision, microscopy, laser optics, and more.
  • Material: BK7
  • Diameter: Custom mm
  • ROC1: Custom mm
  • ROC2: Custom mm
Data Sheet
ONTF Meniscus Lens
ONTF Company
Add to watch list
ONTF Meniscus Lens
Compare
Lenses can be made of all types of fine-annealing colourless optical glass and fused silica.
  • Material: BK7, FS, UVFS, CaF2, ZnSe, Ge, H-K9L
  • Diameter: 180 mm
  • ROC1: 12000 mm
  • ROC2: 12000 mm
Data Sheet
160 UO 65 Meniscus Cylindrical Lens
COMAR Optics
Add to watch list
160 UO 65 Meniscus Cylindrical Lens
Compare
These economical meniscus lenses provide a wide range of longer focal lengths at low cost. The 60mm lenses have moulded edges whilst the 25mm are edged and centred. Each lens has one spherical and one toroidal surface, giving zero power in one cross-section and positive or negative power in the orthogonal section. The overall effect ...
  • Material: BK7
  • Diameter: 65 mm
  • ROC1: 165 mm
  • ROC2: -- mm
Data Sheet
80 JO 60 Meniscus Negative Lens
COMAR Optics
Add to watch list
80 JO 60 Meniscus Negative Lens
Compare
This economical range of meniscus lenses offers a wide breadth of powers at very low cost; the lenses are particularly useful as supplementary elements to reduce the power of another lens. The 60/65mm lenses may have moulded edges whilst the 25mm are edged and centred.
  • Material: BK7
  • Diameter: 60 mm
  • ROC1: 80 mm
  • ROC2: -- mm
Data Sheet
100 IO 60 Crown Glass Meniscus Lens
COMAR Optics
Add to watch list
100 IO 60 Crown Glass Meniscus Lens
Compare
This economical range of meniscus lenses offers a wide breadth of powers at low cost, especially in longer focal lengths. The 60/65mm lenses may have moulded edges whilst the 25mm are edged and centred.
  • Material: BK7
  • Diameter: 65 mm
  • ROC1: Custom mm
  • ROC2: Custom mm
Data Sheet
10 IT 04 Meniscus Laser Lens
COMAR Optics
Add to watch list
10 IT 04 Meniscus Laser Lens
Compare
A high-index meniscus lens can be added to a focusing lens to increase its power and relative aperture with very little extra spherical aberration or coma. Those listed here are designed to be used with another lens of the same focal length (with collimated input), such as the PX series or achromatic doublets. The power and ...
  • Material: FS
  • Diameter: 4.0 mm
  • ROC1: 1.2 mm
  • ROC2: 1.0 mm
Data Sheet
Meniscus Lens MgF2
CHANGCHUN QIANHAO
Add to watch list
Meniscus Lens MgF2
Compare
Meniscus Lens MgF2
  • Material: BK7, FS, UVFS, CaF2, ZnSe, Ge, H-K9L
  • Diameter: Custom mm
  • ROC1: Custom mm
  • ROC2: Custom mm
Data Sheet
Meniscus Lens N-BK7
CHANGCHUN QIANHAO
Add to watch list
Meniscus Lens N-BK7
Compare
Meniscus Lens N-BK7
  • Material: BK7
  • Diameter: Custom mm
  • ROC1: Custom mm
  • ROC2: Custom mm
Data Sheet
Meniscus Lens H-LAK 10
CHANGCHUN QIANHAO
Add to watch list
Meniscus Lens H-LAK 10
Compare
Meniscus Lens H-LAK 10
  • Material: BK7, FS, UVFS, CaF2, ZnSe, Ge, H-K9L
  • Diameter: Custom mm
  • ROC1: Custom mm
  • ROC2: Custom mm
Data Sheet
Convex-Concave Lenses N-BK7 Meniscus
CeNing Optics
Add to watch list
Convex-Concave Lenses N-BK7 Meniscus
Compare
Convex-Concave Lenses N-BK7 Meniscus.
  • Material: BK7
  • Diameter: 25.4 mm
  • ROC1: 33.72 mm
  • ROC2: 90 mm
Data Sheet
Alkor Meniscus Lenses
Alkor Technologies
Add to watch list
Alkor Meniscus Lenses
Compare
We produce custom CaF2 plano-convex lens, plano-concave CaF2 lenses; biconvex and bi-concave CaF2 lenses to 100% meet customer\'s demands. We can make lenses from 3 to 80mm diameter with almost any focal length. Calcium Fluoride is used for lenses in transmision range 0.17-10µm. Degradation due to to moisture in the atmosphere is ...
  • Material: CaF2
  • Diameter: custom mm
  • ROC1: custom mm
  • ROC2: custom mm
Negative Meniscus Spheric Lens
FOCTek Photonics
Add to watch list
Negative Meniscus Spheric Lens
Compare
FOCtek provides five kinds of spheric lens forms, or shapes, that determine the imaging Characteristics of the lenses, they are plano-convex, plano-concave, Double-convex, Double-concave and Meniscus.
  • Material: CaF2, UVFS, FS, BK7
  • Diameter: custom mm
  • ROC1: custom mm
  • ROC2: custom mm
Data Sheet
Positive Meniscus Spheric Lens
FOCTek Photonics
Add to watch list
Positive Meniscus Spheric Lens
Compare
FOCtek provides five kinds of spheric lens forms, or shapes, that determine the imaging Characteristics of the lenses, they are plano-convex, plano-concave, Double-convex, Double-concave and Meniscus.
  • Material: CaF2, UVFS, FS, BK7
  • Diameter: custom mm
  • ROC1: custom mm
  • ROC2: custom mm
Data Sheet
CONVEX AND CONCAVE MENISCUS LENSES MCX - MCC
Tecnottica Consonni
Add to watch list
CONVEX AND CONCAVE MENISCUS LENSES MCX - MCC
Compare
Meniscus lenses are divided into positive and negative: both are distinguished from other lenses since, by definition, have a convex surface and a concave surface. These lenses are often used to shorten or lengthen the focal length of an optical system that already exists. In addition, meniscus lenses can be properly designed so that ...
  • Material: UVFS, BK7
  • Diameter: custom mm
  • ROC1: custom mm
  • ROC2: custom mm
Data Sheet
Positive Meniscus Convex-­Concave Lens
BoJen Optics, Inc.
Add to watch list
Positive Meniscus Convex-­Concave Lens
Compare
Positive meniscus (convex-concave) lenses, with center thickness bigger, are designed to minimize spherical aberration. When used in combination with another lens, a positive meniscus lens will shorten the focal length and increase the numerical aperture (NA) of the system without introducing significant spherical aberration. When ...
  • Material: Ge, ZnSe, CaF2, UVFS, FS, BK7, H-K9L
  • Diameter: 3 mm
  • ROC1: -- mm
  • ROC2: -- mm
  • Available Focal Lengths: 100mm to 1000mm
  • ...
Data Sheet
Negative  Meniscus Convex-­Concave Lens
BoJen Optics, Inc.
Add to watch list
Negative  Meniscus Convex-­Concave Lens
Compare
Negative meniscus (convex-concave) lenses, with center thickness smaller, are designed to minimize spherical aberration in optical systems. When used in combination with another lens, a negative meniscus lens will increase the focal length and decrease the numerical aperture (NA) of the system. When used to diverge light, as shown in ...
  • Material: Ge, ZnSe, CaF2, UVFS, FS, BK7, H-K9L
  • Diameter: 3 mm
  • ROC1: -- mm
  • ROC2: -- mm
  • Available Focal Lengths: -100mm to -1000mm
  • ...
Data Sheet
Meniscus Spherical Lens
Wuhan Union Optic, Inc
Add to watch list
Meniscus Spherical Lens
Compare
Dimension Tolerance +0/-0.2mm Thickness Tolerance ±0.2mm Design Wavelength 546.1nm Surface Quality 60/40 scratch and dig Flatness λ/4@632.8nm Centration <3 arc minutes Focal Length Tolerance ±2% Clear Aperture >90% Chamfer Protective <0.5mmx45deg
  • Material: UVFS, FS, BK7, H-K9L
  • Diameter: 25.4 mm
  • ROC1: 20.58 mm
  • ROC2: 90 mm
Data Sheet

Did You know?

Meniscus lenses have a combination of concave on one side and convex on the other side surfaces. They are also known as convex-concave lenses. Depending on the relative sharpness of the curvature between the outer and inner surfaces these lenses can be positive or negative. The key properties of these lenses are the minimized spherical aberrations and increased numerical aperture, which makes them critical for optical corrective applications such as optical glasses, various optical systems and multi lens focussing objective in photo cameras.
