Description

The FBLD-976-3W-FC105-VBG-2Pin Wavelength Stabilized Fiber-coupled Laser Diode offered by Frankfurt Laser Company is a compact and reliable laser diode module designed for precision applications. Operating at a wavelength of 976nm, it delivers a continuous wave (CW) output power of 3W.

The module features a fiber core diameter of 105µm and a numerical aperture (NA) of 0.22, ensuring efficient light transmission and accurate beam focusing. With its wavelength stabilization (VBG) and feedback protection filter, it guarantees stable performance and excellent beam quality.

This laser diode is ideal for various applications that require wavelength stability and moderate power output, such as scientific research, fiber optic communications, and spectroscopy.

FBLD-976-3W-FC105-VBG-2Pin Wavelength Stabilized Fiber-coupled Laser Diode

Specifications

Laser Type: Continuous Wave (CW)
Fiber Type: Multi-Mode
Wavelength: 976 nm
Output Power: 3000 mW
Fiber Core Diamater: 105 um
Fiber Cladding Diameter: 125 um
Numerical Aperture (NA): 0.22
Slope Efficiency: 1 W/A
Operation Current: 4 A
Threshold Current: 0.9 A
Minimum Bending Radius: 50 mm
Fiber Length: 1 m
Buffer Diameter: 250 µm
Core Diameter: 105 µm
Wavelength Shift With Current: 0.03 nm/A
Wavelength Shift With Temp.: 0.02 nm/°C
Back Reflection Isolation: 30 dB
Back Reflection Wavelength: 1020 nm

Got questions about specs? Use the inquiry form to ask.

Document icon Download Data Sheet Download icon

Features

  • Wavelength: 976nm
  • CW Output Power: 3W
  • Fiber Core Diameter: 105µm / NA 0.22
  • Wavelength Stabilized (VBG)
  • Feedback Protection Filter for enhanced stability

Applications

  • Scientific research
  • Fiber optic communications
  • Spectroscopy
  • Laser-induced fluorescence
  • Biomedical instrumentation
  • Laser display systems

Frequently Asked Questions

What is the feedback protection filter feature of the FBLD-976-3W-FC105-VBG-2Pin laser diode?
The feedback protection filter feature helps protect the laser diode from damage caused by feedback from the fiber laser.
What is the wavelength of the FBLD-976-3W-FC105-VBG-2Pin laser diode?
The laser diode has a wavelength stabilization feature (VBG) and operates at a wavelength of 976nm.
Is the FBLD-976-3W-FC105-VBG-2Pin laser diode fiber-coupled?
Yes, the laser diode is fiber-coupled and comes with an FC105 connector.
What is the application of the FBLD-976-3W-FC105-VBG-2Pin laser diode?
The laser diode is commonly used for fiber laser pumping.
What is the output power of the FBLD-976-3W-FC105-VBG-2Pin laser diode?
The laser diode has an output power of 3W.

Got more questions? Use the inquiry form to ask the supplier directly.
