Thumbnail of EEL M12 825nm 140mW Laser Diode for Medical and AR/VR Applications photo 1

Description

The EEL M12 825nm AD82E00001 is a cutting-edge laser diode designed for precision and reliability. Operating at a wavelength of 825nm with an optical power output of 140mW, this device is engineered to deliver stable performance across various applications. Its excellent heat dissipation capabilities, bolstered by an Automatic Power Control (APC) circuit, ensure consistent optical power output, making it a dependable choice for professionals seeking high-quality laser solutions.

Crafted with a robust aluminum anode and treated for enhanced durability, the EEL M12 boasts a sturdy structure that offers high stability. The appearance color of the device can be customized to meet specific customer requirements, providing flexibility in design and integration. This laser diode is designed to align with one of the most common public version sizes of LECC, which significantly reduces the initial development costs associated with mold creation. Furthermore, its manufacturing capacity allows for immediate ordering and mass production, streamlining the development process and saving valuable time.

Incorporating the EEL M12 into your projects ensures a seamless blend of performance and efficiency. Its design not only meets Class 2M specifications but also allows for customization of different wavelengths on demand, catering to a wide range of industry needs. Whether you are involved in medical measurement, augmented reality (AR), virtual reality (VR), mixed reality (MR), or aiming devices, the EEL M12 provides a reliable and adaptable solution for your technological advancements.

EEL M12 825nm 140mW Laser Diode for Medical and AR/VR Applications

Visit the LECC Technology Co., Ltd. Store

Specifications

Center Wavelength: 0.825 um
Output Power: 140 mW
Wavelength At Peak Emission: 815 - 840 nm
Laser Wavelength Options: Select According to Customized Spec Sheet
Input Voltage: 3, 5, 6, 12 V
Operating Current: Varies by LD Type
Spot Size At 26mm (Fast-Axis) @13.5%: 3-4 mm
Operating Temp. Range: -10 to 60 °C
Spot Size At 26mm (Slow-Axis) @13.5%: 1.8-2.5 mm
Storage Temp. Range: -40 to 85 °C
Spot Size At 5m (Fast-Axis) @13.5%: 2-10 mm
Spot Size At 5m (Slow-Axis) @13.5%: 3-11 mm
Beam Angle: ±0.75 deg.

Got questions about specs? Use the inquiry form to ask.

Document icon Download Data Sheet Download icon

Features

  • Stable power output of 1-2mW
  • Excellent heat dissipation
  • APC circuit integration for consistent optical output
  • Customizable appearance color
  • Sturdy aluminum anode structure
  • High stability design
  • Saves on mold costs during initial development
  • Ready for mass production orders
  • Meets Class 2M specifications
  • Wavelength customization available on demand

Applications

Medical Applications:

  • Diagnostic tool illumination
  • Medical measurement location aids
  • Surgical site illumination

Augmented and Virtual Reality:

  • AR headset tracking systems
  • VR positional tracking
  • MR (Mixed Reality) device calibration

Aiming and Positioning:

  • Precision aiming devices
  • Surveying equipment illumination
  • Target designation in sports or recreational activities

Manufacturing and Production:

  • Assembly line positioning
  • Laser engraving and marking assistance
  • Quality control inspection aids

Research & Development:

  • Laboratory experiments requiring precise light sources
  • Photonics and optics research tools
  • Prototype development for new optical devices

Frequently Asked Questions

What is the EEL M12 AD82E00001?
The EEL M12 AD82E00001 is a laser diode with a wavelength of 825nm and an optical power output of 140mW, designed for applications such as medical measurement, AR/VR/MR, and aiming devices.
What are the key features of the EEL M12?
The key features of the EEL M12 include stable power output, compliance with Class 2M specifications, and customizable wavelengths and appearance colors.
What is the operating temperature range for the EEL M12?
The operating temperature range for the EEL M12 is from -10°C to 60°C.
What precautions should be taken to prevent damage to the laser diode?
To prevent damage, avoid exceeding the absolute maximum ratings, protect against ESD and surge currents, use anti-static measures, and ensure proper soldering techniques are followed.
What is the recommended soldering temperature for the EEL M12?
The recommended soldering temperature is less than 180°C for no more than 3 seconds, specifically for the leads.
What are the safety precautions regarding eye safety?
Directly looking into the laser beam, even through lenses or optical fibers, can cause severe eye damage. Proper eye safety measures should be observed when the laser diode is in operation.
Can the appearance color of the EEL M12 be customized?
Yes, the appearance color of the EEL M12 can be customized according to customer needs.
