Description
The QLF1339-AA is 1310 nm quantum dot laser diode device for use in telecom and datacom applications up to 2.5Gbps speed. The laser is mounted into a TO-56 header without PD monitor and hermetic sealed with a lens cap. Since quantum dot technologies are equipped with active layers of the device, it realizes excellent temperature characteristics and low power consumption.
1310 nm FP LASER
Specifications
| Center Wavelength: | 1.31 um |
|---|---|
| Output Power: | 6 mW |
Download Data Sheet
Features
- 1 10 nm FP-LD
- 5 6mm TO-CAN package
- Wide temperature operation: -10 to 85 deg.C
- PD less type
Applications
- Optical Communications
Frequently Asked Questions
Does the QLF1339-AA laser come with a PD monitor?
No, the QLF1339-AA laser is mounted into a TO-56 header without PD monitor.
What is the maximum light output power of the QLF1339-AA laser?
The maximum light output power of the QLF1339-AA laser is 6 mW.
What is the maximum speed that the QLF1339-AA laser can be used for?
The QLF1339-AA laser can be used for telecom and datacom applications up to 2.5Gbps speed.
What is the temperature range in which the QLF1339-AA laser can operate?
The QLF1339-AA laser can operate in a wide temperature range of -10 to 85 deg.C.
What is the wavelength of the QLF1339-AA laser?
The QLF1339-AA laser has a wavelength of 1310 nm.
