Description
QLF131F-P16 is a 1305 nm quantum dot FP laser diode chip for use in telecom and datacom applications up to 110 deg.C temperature. Since quantum dot technologies are equipped with active layers of the device, it realizes excellent temperature characteristics and low power consumption.
1305 nm 16 mW FP LASER DIODE
Specifications
| Center Wavelength: | 1.305 um |
|---|---|
| Output Power: | 22 mW |
Download Data Sheet
Features
- 1 05nm FP-LD Chip
- Wide temperature operation: -10 to 110C
Applications
- Optical Communications
Frequently Asked Questions
What is the maximum light output power of the QLF131F-P16 laser diode chip?
The maximum light output power of the QLF131F-P16 laser diode chip is 16 mW.
What is the maximum temperature that the QLF131F-P16 laser diode chip can operate at?
The QLF131F-P16 laser diode chip can operate at temperatures up to 110 degrees Celsius.
What is the slope efficiency of the QLF131F-P16 laser diode chip?
The slope efficiency of the QLF131F-P16 laser diode chip is 0.33 W/A at 25 degrees Celsius and 0.25-0.30 W/A at 85 degrees Celsius.
What is the spectral width of the QLF131F-P16 laser diode chip?
The spectral width of the QLF131F-P16 laser diode chip is 2.7 nm at 25 degrees Celsius and 2.2 nm at 85 degrees Celsius.
What is the wavelength of the QLF131F-P16 laser diode chip?
The wavelength of the QLF131F-P16 laser diode chip is 1305 nm.
