Iris 15 Scientific CMOS Camera
Description
Look at the Big Picture
The Iris 15 Scientific CMOS camera is designed with a large field of view for live cell microscopy applications. Its 15 megapixel sensor and 25 millimeter field of view provides extremely high-resolution images over a large imaging area. It is the only camera that provides high resolution with video rate acquisition speeds, ensuring dynamic cellular events are properly captured and documented.
Capture detailed 15 MP images using the 25mm microscope field-of-view at over 30 frames per second (fps). Iris 15 offers a 4.25µm x 4.25µm pixel area which meets the requirements for Nyquist spatial sampling at 40 times magnification, as well as high sensitivity with a 73 percent quantum efficiency and low noise levels.
Iris 15 Scientific CMOS Camera
Specifications |
|
|---|---|
| Sensor Type: | sCMOS |
| # Pixels (Width): | 5056 |
| # Pixels (Height): | 2968 |
| Pixel Size (Square): | 4.25 um |
| Peak Quantum Efficiency: | 73 % |
| Full Frame Rate: | 30 fps |
| Bit Depth: | 15 bit |
| Field Of View: | 25mm Field of View |
| Megapixel: | 15 Megapixel (5056 x 2968) |
Features
25mm Field of View
4.25µm x 4.25µm Pixel Area
30 Frames per Second
73% Quantum Efficiency
Applications
For pricing, technical or any other questions please contact the supplier
- No registration required
- No markups, no fees
- Direct contact with supplier
Contact Supplier
How to order?
-
Ships from:
United States
-
Sold by:
Photometrics -
On FindLight:
since 2015
Frequently Asked Questions
The Iris 15 Scientific CMOS camera is designed for live cell microscopy applications.
The Iris 15 camera has a resolution of 15 megapixels (5056 x 2968).
The Iris 15 camera has a 25 millimeter field of view.
The Iris 15 camera has a pixel size of 4.25µm x 4.25µm.
Some primary applications of the Iris 15 camera include light sheet microscopy, multi-color fluorescence, high content screening, and tiling applications.
