Description
Managed Gigabit Media Converter is an IEEE 802.3ah OAM compliant copper to fiber Gigabit Ethernet solution designed to make conversion between 10/100/1000Base-TX and 1000Base-FX with SFP modules and fixed type 1×9 modules. With SNMP and Web-based management in the 2U 16 Slots Managed Media Converter Chassis, the administrator can monitor, configure and control the activity of each 802.3ah series card and remotely connected OAM compliant converter. Converter settings include bandwidth control, duplex, and speed configuration, VLAN tagging, limited Q-in-Q support and SFP DDMI. When used as stand-alone converters, it can be managed by a friendly Web Smart user interface via any web browser.
Managed Gigabit Fiber Media Converter
Specifications
| Number Of Ports: | 1 – 2 |
|---|---|
| Wavelength Range: | 850 – 1550 nm |
| Insertion Loss (typical): | 1.1 dB |
| Return Loss: | -50 dB |
Download Data Sheet
Features
- Supporting 10/100/1000M, full/half duplex autosensing
- Supporting auto-MDI/MDIX
- Supporting 1*9 transceiver and SFP transceiver
- Support SFP DMI (Diagnostic Monitoring Interface) function
- Supporting 850nm, 1310nm, 1550nm and DWDM/CWDM wavelength ruled by ITUT
- 2046 bytes’ packet at store-and-forward mode; Max. 9K bytes’ packet at cut-through
- Rate Limit function, 64Kbps
- Supporting Loopback, precisely locating the failure, convenient for link test
- Supporting LFP quickly locates the failure
- Supporting remote power off alarming
- Economical management function within the bandwidth, supporting 802.3ah and TS 1000
- With powerful network management function, supporting WEB and SNMP
- Supporting hot plug
- Supporting Remote management
- Easy installation with complete LED indicators for working situation
- Supporting 2U chassis (16 slots) and standalone use
