The Optical Switch PMOSW-1×2 is a cutting-edge solution designed to enhance optical network performance with its superior engineering and precision. This optical switch is meticulously crafted to offer exceptional reliability and stability, ensuring seamless operation in various environments. Its compact design, with dimensions of 27mm (L) x 12.6mm (W) x 8.5mm (H), makes it an ideal choice for space-constrained applications, while its lightweight construction at just 16 grams ensures easy integration into existing systems.

Engineered for excellence, the PMOSW-1×2 optical switch boasts a low insertion loss, typically at 0.8 dB, with a maximum of 1.2 dB, ensuring minimal signal degradation. The switch operates efficiently across a wide wavelength range, supporting testing wavelengths of 780, 1310, 1490, 1550, 1625, and 1650 nm. Its high return loss of ≥50 dB and crosstalk of ≥50 dB further enhance signal integrity, making it a reliable choice for critical network applications.

Designed to withstand challenging conditions, the PMOSW-1×2 operates within a temperature range of -10 to +70°C and can be stored in temperatures ranging from -40 to +85°C. Its robust construction ensures a long lifetime of over 10 million cycles, providing consistent performance over time. The switch is available in both latching and non-latching configurations, offering flexibility to meet diverse operational needs. With a swift switch time of ≤8 ms and a maximum transmission power of 500 mW, this optical switch is optimized for high-speed, high-power applications.
