Page 2 - Fiber Bragg Grating

The apodized FBGs have special profile of induced refractive index modulation and grating strength along the grating length. Therefore, side lobes level becomes smaller in compared to ordinary gratings. There are a lot of apodization profiles which lead to the optimization of various FBG parameters such as strength, FWHM, SLSR, the ...

Specifications

Center Wavelength Range: 633-2300nm
FBG Length: Custom
Reflectivity: Not Specified
Reflectivity, %: 5 ÷99
Chirp Rate, Nm/cm: 0.01 ÷ 25
...
Data Sheet
Fiber Bragg Gratings have many applications in optical communication, laser technique and sensing systems. The FBGs are widely used like in-fiber mirrors or optical filters with narrow band optical spectrum. FBGs can be used like a sensitive element for strain and temperature measuring.

Specifications

Center Wavelength Range: 600-2300nm
FBG Length: Custom
Reflectivity: Not Specified
Reflectivity, % (Low-reflection(LR)): 5 ÷ 40
Reflectivity, % (High-reflection(HR)): › 99
...
Data Sheet
Fiber Bragg Gratings have many applications in optical communication, laser technique and sensing systems. The FBGs are widely used in-fiber mirrors and optical filters with narrow band optical spectrum. FBGs can be used as a sensitive element for strain and temperature measurements.

Specifications

Center Wavelength Range: 600-2300nm
FBG Length: Custom
Reflectivity: Not Specified
SLSR, DB : ‹ 8 ÷ 25
Reflectivity, %: 50 ÷ 99
...
Data Sheet
Fiber Bragg Gratings have many applications in optical communication, laser technique and sensing systems. The FBGs are widely used in-fiber mirrors or optical filters with narrow band optical spectrum. FBGs can be used like a sensitive element for strain and temperature measuring.

Specifications

Center Wavelength Range: 600-2300nm
FBG Length: Not Specified
Reflectivity: >90%
Reflectivity, %: 0.5 ÷ 99.9
Bandwidth (WFHM), Nm: 0.1 ÷ 1.2
...
Data Sheet
Highly efficiently multicascaded Raman lasers based on phosphosilicate fibers can be created at different wavelength. Raman shift by 1330 cm-1 in opposite to Ge-doped fibers is approximately three times larger.  Output emission spectrum of two-cascade 1.48 µm Raman fiber laser is presented in the graph.

Specifications

Center Wavelength Range: 1240-1484nm
FBG Length: Not Specified
Reflectivity: >90%
Wavelength Range, Nm: 1240,1270,1484
Types Of Fiber: Single-Mode, PM, Double clad, LMA
...
Data Sheet
The Tilted FBG has an angle between wave vector of the grating and fiber axis. Therefore cladding modes resonances peaks become more intensive compared to ordinary gratings. TFBG cladding modes resonances wavelength are highly sensitive to the refractive index of the medium outside the fiber cladding. TFBGs are useful in sensing ...

Specifications

Center Wavelength Range: 600-2300nm
FBG Length: Custom
Reflectivity: >90%
Tilt Angle, °: 1 ÷ 45
Reflectivity, %: 5 ÷ 99
...
Data Sheet
Standard Phase shifted FBG
Advanced Optics Solutions
Phase shifted Fiber Bragg gratings show a very narrow transmission band within its reflection bandwidth. Using special structures, even multiple transmission bands are possible. The phase shifted FBGs can be applied to an athermal setup or a temperature stabilization, as well as to a tuning setup.

Specifications

Center Wavelength Range: 1280-1620nm
FBG Length: Custom
Reflectivity: >90%, >70%, >50%, >30%, >20%
Data Sheet
Premium Phase shifted FBG
Advanced Optics Solutions
Phase shifted Fiber Bragg gratings show a very narrow transmission band within its reflection bandwidth. Using special structures, even multiple transmission bands are possible. The phase shifted FBGs can be applied to an athermal setup or a temperature stabilization, as well as to a tuning setup.

Specifications

Center Wavelength Range: 800-1620nm
FBG Length: Custom
Reflectivity: >90%, >70%, >50%, >30%, >20%
Data Sheet
Standard Broad Band Filter FBG
Advanced Optics Solutions
Using the technique of \"chirped\" (linear variation of the period within the FBG structure) Fiber Bragg gratings, we are able to provide FBGs with a very broad bandwidth and with a high rejection. We can provide a wide range of center wavelengths, bandwidths, and reflectivities.

Specifications

Center Wavelength Range: 1535-1565nm
FBG Length: Custom
Reflectivity: >90%, >70%, >50%, >30%, >20%
Data Sheet
Premium Broad Band Filter FBG
Advanced Optics Solutions
Using the technique of \"chirped\" (linear variation of the period within the FBG structure) Fiber Bragg gratings, we are able to provide FBGs with a very broad bandwidth and with a high rejection. We can provide a wide range of center wavelengths, bandwidths, and reflectivities.

Specifications

Center Wavelength Range: 800-1620nm
FBG Length: Custom
Reflectivity: >90%, >70%, >50%, >30%, >20%
Data Sheet
Standard FBG for DWDM Application
Advanced Optics Solutions
Fiber Bragg gratings are compo- nents for a wide range of applica- tions in optical communications. The FBGs act there as in-fiber narrow band filters. Bragg gratings are imprinted into an optical fiber by a holographic process. They can be produced with standard single mode fiber as well as with special fibers, i. e. radiation mode ...

Specifications

Center Wavelength Range: 1280-1620nm
FBG Length: Custom
Reflectivity: >90%, >70%, >50%, >30%, >20%
Data Sheet
Premium FBG for DWDM Application
Advanced Optics Solutions
Fiber Bragg gratings are compo- nents for a wide range of applica- tions in optical communications. The FBGs act there as in-fiber narrow band filters. Bragg gratings are imprinted into an optical fiber by a holographic process. They can be produced with standard single mode fiber as well as with special fibers, i. e. radiation mode ...

Specifications

Center Wavelength Range: 800-1620nm
FBG Length: Custom
Reflectivity: >90%, >70%, >50%, >30%, >20%
Data Sheet
FEMTO Grating in Single Mode Acrylate Fiber FFT.FBG.S.00.01
FemtoFiberTec
Besides customer specific FBG solutions, FemtoFiberTec offers an attractive range of standardizedfs-written FBGs. Due to the worldwide leading, automated manufacturing technology, FemtoFiberTeccan provide high customer value in terms of quality and cost efficiency.

Specifications

Center Wavelength Range: 1500-1600nm
FBG Length: 6 mm
Reflectivity: >20%
Data Sheet
FEMTO Grating in Single Mode Acrylate Fiber FFT.FBG.S.00.02
FemtoFiberTec
Besides customer specific FBG solutions, FemtoFiberTec offers an attractive range of standardizedfs-written FBGs. Due to the worldwide leading, automated manufacturing technology, FemtoFiberTeccan provide high customer value in terms of quality and cost efficiency.

Specifications

Center Wavelength Range: 1500-1600nm
FBG Length: 6 mm
Reflectivity: >50%
Data Sheet
FEMTO Grating in Single Mode Acrylate Fiber FFT.FBG.S.00.03
FemtoFiberTec
Besides customer specific FBG solutions, FemtoFiberTec offers an attractive range of standardizedfs-written FBGs. Due to the worldwide leading, automated manufacturing technology, FemtoFiberTeccan provide high customer value in terms of quality and cost efficiency.

Specifications

Center Wavelength Range: 1500-1600nm
FBG Length: 6 mm
Reflectivity: >70%
Data Sheet
FEMTO Grating in Single Mode Polyimide Fiber FFT.FBG.S.01.01
FemtoFiberTec
Besides customer specific FBG solutions, FemtoFiberTec offers an attractive range of standardizedfs-written FBGs. Due to the worldwide leading, automated manufacturing technology, FemtoFiberTeccan provide high customer value in terms of quality and cost efficiency.

Specifications

Center Wavelength Range: 1500-1600nm
FBG Length: 6 mm
Reflectivity: >20%
Data Sheet
FEMTO Grating in Single Mode Polyimide Fiber FFT.FBG.S.01.02
FemtoFiberTec
Besides customer specific FBG solutions, FemtoFiberTec offers an attractive range of standardizedfs-written FBGs. Due to the worldwide leading, automated manufacturing technology, FemtoFiberTeccan provide high customer value in terms of quality and cost efficiency.

Specifications

Center Wavelength Range: 1500-1600nm
FBG Length: 6 mm
Reflectivity: >50%
Data Sheet
FEMTO Grating in Single Mode Polyimide Fiber FFT.FBG.S.01.03
FemtoFiberTec
Besides customer specific FBG solutions, FemtoFiberTec offers an attractive range of standardizedfs-written FBGs. Due to the worldwide leading, automated manufacturing technology, FemtoFiberTeccan provide high customer value in terms of quality and cost efficiency.

Specifications

Center Wavelength Range: 1500-1600nm
FBG Length: 6 mm
Reflectivity: >70%
Data Sheet
FEMTO Grating in Pure Core Polyimide Fiber FFT.FBG.S.02.01
FemtoFiberTec
Besides customer specific FBG solutions, FemtoFiberTec offers an attractive range of standardizedfs-written FBGs. Due to the worldwide leading, automated manufacturing technology, FemtoFiberTeccan provide high customer value in terms of quality and cost efficiency.

Specifications

Center Wavelength Range: 1500-1600nm
FBG Length: 6 mm
Reflectivity: >20%
Data Sheet
FEMTO Grating in Pure Core Polyimide Fiber FFT.FBG.S.02.02
FemtoFiberTec
Besides customer specific FBG solutions, FemtoFiberTec offers an attractive range of standardizedfs-written FBGs. Due to the worldwide leading, automated manufacturing technology, FemtoFiberTeccan provide high customer value in terms of quality and cost efficiency.

Specifications

Center Wavelength Range: 1500-1600nm
FBG Length: 6 mm
Reflectivity: >50%
Data Sheet
FEMTO Grating in Pure Core Polyimide Fiber FFT.FBG.S.02.03
FemtoFiberTec
Besides customer specific FBG solutions, FemtoFiberTec offers an attractive range of standardizedfs-written FBGs. Due to the worldwide leading, automated manufacturing technology, FemtoFiberTeccan provide high customer value in terms of quality and cost efficiency.

Specifications

Center Wavelength Range: 1500-1600nm
FBG Length: 6 mm
Reflectivity: >70%
Data Sheet
FEMTOPlus® Grati ng in Single Mode Acrylate Fiber FFT.FBG.P.00.02
FemtoFiberTec
Besides customer specific FBG solutions, FemtoFiberTec offers an attractive range of standardizedfs-written FBGs. Due to the worldwide leading, automated manufacturing technology, FemtoFiberTeccan provide high customer value in terms of quality and cost efficiency.

Specifications

Center Wavelength Range: 1500-1600nm
FBG Length: 12 mm
Reflectivity: >50%
Data Sheet
IDIL Fibres Optiques offers tunable Fiber Bragg Gratings (FBG) using piezoelectric stack and electrical voltage.  A way to tune the optical wavelength (nanometer scale) of a photo-imprinted Fiber Bragg Grating is to fix it on a piezoelectric stack. When applying an electric voltage on the piezo, it creates an elongation of the ...

Specifications

Center Wavelength Range: 1000-2000nm
FBG Length: From 1mm to 20mm, Custom
Reflectivity: Not Specified
Fiber Type: SM, PM, RC
Weight (typical): 10 g g
...
Data Sheet
