Description

The OPTOMAN PCX-F50-UVFS-25.4-ET2.0-AR548-AR548 is a high-precision plano-convex laser lens engineered for efficient focusing and beam conditioning in 1030 nm ultrafast laser systems. Manufactured from UV-grade fused silica (JGS1), this 25.4 mm diameter optical lens delivers excellent transmission, low absorption, and reliable performance in high-power laser environments. The lens incorporates OPTOMAN’s ion beam sputtering (IBS) AR548 anti-reflective coating, providing less than 0.1% reflectance at 1030 nm to minimize optical losses and unwanted reflections.

With a 50 mm focal length, tight surface quality specifications, and low wavefront distortion, this plano-convex lens is optimized for applications requiring accurate beam focusing, harmonic generation, laser processing, and precision optical systems.

PCX-F50-UVFS-25.4-ET2.0-AR548-AR548 50mm Plano-Convex Laser Lens

Specifications

Lens Type: Plano-Convex
Material: UVFS
Diameter: 25.4 mm
Focal Length: 50 mm
Edge Thickness, Te: 2 mm
Surface Quality, S1/S2 (scratch-dig): 20-10
Surface Irregularity, S1/S2: <= Lambda/6
Manufacturer Part Number (MPN): PCX-F50-UVFS-25.4-ET2.0-AR548-AR548
FindLight SKU: FL-24735

Got questions about specs? Use the inquiry form to ask.

Document icon Download Data Sheet Download icon

Features

  • Manufacturer part number: PCX-F50-UVFS-25.4-ET2.0-AR548-AR548
  • Plano-convex laser lens design for precise beam focusing
  • 50 mm focal length optimized for 1030 nm laser systems
  • UV fused silica (JGS1) substrate for excellent transmission and thermal stability
  • 25.4 mm diameter with 2.0 mm edge thickness
  • IBS anti-reflective coating with AR<0.1% reflectance at 1030 nm
  • High surface quality: 20-10 scratch-dig specification
  • Surface irregularity better than λ/6 over clear aperture
  • Low centration error for improved beam alignment accuracy
  • Suitable for ultrafast femtosecond and picosecond laser applications
  • Laser damage threshold greater than 0.5 J/cm² at 1030 nm, 500 fs, 10 kHz conditions

Applications

  • 1030 nm ultrafast laser systems
  • Yb-based femtosecond and picosecond laser setups
  • Laser beam focusing and beam conditioning modules
  • Nonlinear frequency conversion and harmonic generation systems
  • Precision laser micromachining and material processing
  • Semiconductor and electronics manufacturing
  • Optical measurement and diagnostic systems
  • Research and development laser laboratories
  • High-power laser instrumentation

Export & Trade Information

ECCN: EAR99
HTS Code: 9001.90.4000
Estimated US Tariff: 10%

Importing, tariffs & codes (Quick Guide) →

Frequently Asked Questions

What is the focal length of the OPTOMAN PCX-F50-UVFS-25.4-ET2.0-AR548-AR548 lens?
The lens has a 50 mm focal length, making it suitable for applications requiring compact and precise focusing of 1030 nm laser beams.
What material is used for this OPTOMAN plano-convex lens?
The lens is manufactured from UV-grade fused silica (JGS1), which provides excellent optical transmission, low thermal expansion, and strong resistance to laser-induced damage.
What wavelength is the AR548 coating designed for?
The AR548 anti-reflective coating is optimized for 1030 nm operation and provides reflectance below 0.1% to improve transmission efficiency and reduce optical losses.
Can this lens be used with ultrafast laser systems?
Yes. The PCX-F50-UVFS-25.4-ET2.0-AR548-AR548 is designed for ultrafast laser applications, including femtosecond and picosecond systems where low absorption and minimal dispersion are important.
What are the main advantages of using a plano-convex lens in laser applications?
A plano-convex lens provides efficient focusing of collimated laser beams while maintaining good optical performance, making it widely used for focusing, beam shaping, and precision laser processing applications.

Got more questions? Use the inquiry form to ask the supplier directly.
