Description

The OPTOMAN PCX-F175-UVFS-25.4-ET2.0-AR909-AR909 is a premium plano-convex laser lens engineered for high-power 1064 nm laser systems where exceptional transmission, low optical loss, and outstanding laser damage resistance are critical. Manufactured from high-quality UV-grade fused silica (JGS1) and coated with ion beam sputtered (IBS) anti-reflection coatings on both surfaces, this lens delivers reflectance below 0.1% at 1064 nm while maintaining excellent wavefront quality.

Featuring a 25.4 mm diameter, 175 mm focal length, λ/6 surface accuracy, and a high laser-induced damage threshold of 55 J/cm² (1064 nm, 5 ns), it is well suited for demanding industrial, scientific, and research applications involving Nd:YAG and other high-energy infrared laser sources. The precision optical finish minimizes scattering and thermal effects, enabling stable beam focusing and long operational lifetime even under intense laser exposure.

PCX-F175-UVFS-25.4-ET2.0-AR909-AR909 Plano-Convex UV Fused Silica Lens 175 mm

Specifications

Lens Type: Plano-Convex
Material: UVFS
Diameter: 25.4 mm
Focal Length: 175 mm
Edge Thickness, Te: 2 mm
Surface Quality, S1/S2 (scratch-dig): 20-10
Surface Irregularity, S1/S2: <= Lambda/6
Manufacturer Part Number (MPN): PCX-F175-UVFS-25.4-ET2.0-AR909-AR909
FindLight SKU: FL-24749

Got questions about specs? Use the inquiry form to ask.

Document icon Download Data Sheet Download icon

Features

  • Manufacturer Part Number: PCX-F175-UVFS-25.4-ET2.0-AR909-AR909
  • Plano-convex spherical lens for efficient laser beam focusing
  • UV-grade fused silica (JGS1) substrate with excellent transmission and thermal stability
  • Precision IBS anti-reflection coating on both surfaces
  • Reflectance below 0.1% at 1064 nm
  • 175 mm focal length with ±1% tolerance
  • 25.4 mm diameter for compatibility with standard optomechanical mounts
  • High laser damage threshold of 55 J/cm² (1064 nm, 5 ns)
  • λ/6 transmitted wavefront accuracy over the clear aperture
  • 20-10 scratch-dig surface quality for reduced scattering
  • Centration error below 3 arcmin for accurate beam alignment
  • Designed for demanding nanosecond high-power laser applications

Applications

  • High-power Nd:YAG laser beam focusing
  • Industrial laser micromachining
  • Laser welding and cutting systems
  • Laser marking and engraving equipment
  • Scientific laser laboratories
  • Optical research and photonics experiments
  • Precision spectroscopy systems
  • Beam delivery and optical integration
  • High-energy laser test setups
  • OEM laser equipment operating at 1064 nm

Export & Trade Information

ECCN: EAR99
HTS Code: 9001.90.4000
Estimated US Tariff: 10%

Importing, tariffs & codes (Quick Guide) →

Frequently Asked Questions

What makes this lens suitable for high-power laser applications?
Its UV fused silica substrate, IBS anti-reflection coatings, and laser damage threshold of 55 J/cm² at 1064 nm enable reliable operation with high-energy nanosecond laser pulses while minimizing absorption and thermal effects.
Which laser wavelength is this lens optimized for?
The lens is optimized for 1064 nm and features anti-reflection coatings with reflectance below 0.1% on both optical surfaces at normal incidence, maximizing transmission for Nd:YAG and similar infrared laser systems.
Why choose a plano-convex lens for laser focusing?
Plano-convex lenses efficiently focus collimated laser beams while introducing less spherical aberration than many alternative spherical lens geometries when oriented correctly toward the incoming beam.
Can this lens be integrated into existing optical systems?
Yes. The standard 25.4 mm diameter, precision centration, and high optical quality make it compatible with a wide range of commercial optomechanical mounts and laser beam delivery assemblies.
What industries commonly use this optical lens?
This lens is widely used in industrial laser processing, scientific research, photonics laboratories, precision manufacturing, spectroscopy, laser system integration, and OEM equipment requiring efficient 1064 nm beam focusing.

Got more questions? Use the inquiry form to ask the supplier directly.
