Description

The OPTOMAN PCX-F150-UVFS-25.4-ET2.0-AR909-AR909 is a precision plano-convex lens manufactured from high-quality UV fused silica (JGS1) for demanding laser and photonics applications. Designed with an enhanced laser-induced damage threshold (LIDT) anti-reflection coating optimized for 1064 nm, this lens minimizes Fresnel reflections to below 0.1% per surface while maximizing optical transmission.

Its precision-polished surfaces, low wavefront error, and tight centration tolerances make it an excellent choice for beam focusing, laser processing, scientific instrumentation, and industrial optical systems operating at the Nd:YAG fundamental wavelength. Built using ion beam sputtering (IBS) coating technology, the lens provides exceptional coating durability, environmental stability, and long-term optical performance in high-power laser environments.

PCX-F150-UVFS-25.4-ET2.0-AR909-AR909 Plano-Convex UV Fused Silica Lens 1064 nm

Specifications

Lens Type: Plano-Convex
Material: UVFS
Diameter: 25.4 mm
Focal Length: 150 mm
Edge Thickness, Te: 2 mm
Surface Quality, S1/S2 (scratch-dig): 20-10
Surface Irregularity, S1/S2: <= Lambda/6
Manufacturer Part Number (MPN): PCX-F150-UVFS-25.4-ET2.0-AR909-AR909
FindLight SKU: FL-24721

Got questions about specs? Use the inquiry form to ask.

Document icon Download Data Sheet Download icon

Features

  • Manufacturer Part Number: PCX-F150-UVFS-25.4-ET2.0-AR909-AR909
  • Plano-convex optical design for efficient beam focusing and collimation
  • Premium UV fused silica (JGS1) substrate with excellent transmission and thermal stability
  • Precision AR coating with <0.1% reflectance at 1064 nm on both optical surfaces
  • Enhanced LIDT coating suitable for high-energy and high-peak-power laser systems
  • 25.4 mm diameter with 150 mm focal length
  • Surface quality: 20-10 scratch-dig
  • Surface irregularity: < λ/6 at 633 nm over the clear aperture
  • Centration error below 3 arcmin for precise beam alignment
  • Ion Beam Sputtered (IBS) coatings for superior durability and coating lifetime
  • Excellent environmental resistance and long-term optical stability

Applications

  • Nd:YAG laser beam focusing at 1064 nm
  • High-power laser material processing
  • Laser beam delivery systems
  • Scientific research and laboratory optics
  • Precision metrology instruments
  • Optical testing and alignment systems
  • Medical and life science laser equipment
  • Industrial laser manufacturing
  • Photonics OEM integration
  • Custom laser system development

Export & Trade Information

ECCN: EAR99
HTS Code: 9001.90.4000
Estimated US Tariff: 10%

Importing, tariffs & codes (Quick Guide) →

Frequently Asked Questions

What is the primary wavelength for this lens?
This lens is optimized for 1064 nm and features anti-reflection coatings that reduce surface reflections to below 0.1%, maximizing transmission at the Nd:YAG laser fundamental wavelength.
Why is UV fused silica used for this lens?
UV fused silica offers excellent optical transmission, low thermal expansion, outstanding chemical durability, and high resistance to laser-induced damage, making it ideal for demanding industrial and scientific laser applications.
What advantages does the enhanced LIDT coating provide?
The enhanced LIDT coating is engineered to withstand high laser fluence while maintaining extremely low reflection losses. This improves system efficiency and increases component lifetime in high-power laser applications.
Can this lens be used for both focusing and beam collimation?
Yes. As a precision plano-convex lens, it is well suited for focusing collimated laser beams or collimating divergent sources when installed with the proper orientation in the optical system.
Which applications benefit most from this lens?
The lens is particularly well suited for Nd:YAG laser systems, laser machining, spectroscopy, optical instrumentation, metrology, medical laser equipment, and research laboratories requiring reliable, high-performance optics at 1064 nm.

Got more questions? Use the inquiry form to ask the supplier directly.
