Description

The OPTOMAN PCV-F100-UVFS-25.4-CT2.0-AR784 is a precision plano-concave laser lens designed for demanding ultrafast laser applications operating at 515 nm. Manufactured from premium UV-grade fused silica (JGS1), this 25.4 mm diameter lens features advanced ion beam sputtered (IBS) anti-reflective coatings on both optical surfaces, delivering less than 0.1% residual reflection for maximum transmission and minimal optical losses.

Its high laser-induced damage threshold, excellent wavefront quality, and low absorption make it an excellent choice for femtosecond and picosecond laser systems used in scientific research, precision manufacturing, and advanced photonics. The -100 mm focal length provides reliable beam expansion and divergence control while maintaining exceptional optical performance.

PCV-F100-UVFS-25.4-CT2.0-AR784 – UV Fused Silica Plano-Concave Lens

Specifications

Lens Type: Plano-Concave
Material: UVFS
Diameter: 25.4 mm
Focal Length: -100 mm
Edge Thickness, Te: 3.788 mm
Surface Quality, S1/S2 (scratch-dig): 20-10
Surface Irregularity, S1/S2: <= Lambda/6
Manufacturer Part Number (MPN): PCV-F100-UVFS-25.4-CT2.0-AR784-AR784
FindLight SKU: FL-24742

Got questions about specs? Use the inquiry form to ask.

Document icon Download Data Sheet Download icon

Features

  • Manufacturer Part Number: PCV-F100-UVFS-25.4-CT2.0-AR784
  • Plano-concave UV fused silica (JGS1) laser lens optimized for 515 nm operation
  • 25.4 mm diameter with -100 mm focal length for controlled beam expansion
  • IBS anti-reflective coatings on both surfaces with <0.1% residual reflectance
  • High laser-induced damage threshold suitable for ultrafast femtosecond and picosecond lasers
  • Surface quality of 20-10 scratch-dig and surface irregularity better than λ/6 @ 633 nm
  • Clear aperture greater than 80% for efficient beam utilization
  • Centration error below 3 arcminutes for precise optical alignment
  • Precision-manufactured for demanding industrial and scientific laser applications

Applications

  • eam expansion in ultrafast laser systems
  • Laser beam shaping and divergence control
  • Frequency-doubled Yb:YAG laser platforms operating at 515 nm
  • Precision laser micromachining
  • Semiconductor and electronics manufacturing
  • Medical laser instrumentation
  • Scientific spectroscopy and optical research
  • High-power photonics laboratories
  • Ultrafast laser material processing

Export & Trade Information

ECCN: EAR99
HTS Code: 9001.90.4000
Estimated US Tariff: 10%

Importing, tariffs & codes (Quick Guide) →

Frequently Asked Questions

What is the PCV-F100-UVFS-25.4-CT2.0-AR784 lens designed for?
This plano-concave lens is designed for ultrafast laser systems operating at 515 nm, where high transmission, low optical losses, and excellent wavefront quality are essential for beam expansion and divergence control.
Why is UV-grade fused silica used for this lens?
UV-grade fused silica (JGS1) provides outstanding optical transmission, low absorption, excellent thermal stability, and high resistance to laser damage, making it ideal for high-power and ultrafast laser applications.
What advantages do the IBS anti-reflective coatings provide?
Ion Beam Sputtered coatings offer exceptionally low reflectance, excellent environmental durability, minimal absorption, and consistent optical performance, helping maximize laser throughput while reducing unwanted reflections.
Can this lens be used with femtosecond and picosecond lasers?
Yes. The lens is specifically engineered for ultrafast laser systems and combines a high laser-induced damage threshold with premium optical quality to preserve beam performance during high-peak-power operation.
Which applications benefit most from this plano-concave lens?
The lens is well suited for beam expansion, laser beam conditioning, precision material processing, scientific instrumentation, spectroscopy, semiconductor manufacturing, and other photonics applications requiring accurate control of 515 nm laser beams.

Got more questions? Use the inquiry form to ask the supplier directly.
