Description

The OPTOMAN PCX-F350-UVFS-25.4-ET2.0-AR548-AR548 is a 25.4 mm plano-convex lens featuring a 350 mm focal length and UVFS (JGS1) substrate. Designed for 1030 nm laser applications, this precision optical lens incorporates AR548 anti-reflective coatings on both surfaces to minimize reflection losses and support efficient laser transmission. Its optical specifications make it well suited for integration into ultrafast laser systems, particularly femtosecond and picosecond platforms.

The lens combines a greater than 80% clear aperture with 20-10 surface quality, λ/6 surface irregularity, and less than 3 arcmin centration error. With a 2.5 mm center thickness and 2.0 mm edge thickness, it provides a compact optical solution for beam focusing, laser beam delivery, and precision photonics applications operating at 1030 nm.

CX-F350-UVFS-25.4-ET2.0-AR548-AR548 350mm UVFS Plano-Convex Lens

Visit the Optoman Store

Specifications

Lens Type: Plano-Convex
Material: UVFS
Diameter: 25.4 mm
Focal Length: 350 mm
Edge Thickness, Te: 2 mm
Surface Quality, S1/S2 (scratch-dig): 20-10
Surface Irregularity, S1/S2: <= Lambda/6
Manufacturer Part Number (MPN): PCX-F350-UVFS-25.4-ET2.0-AR548-AR548
FindLight SKU: FL-24752

Got questions about specs? Use the inquiry form to ask.

Document icon Download Data Sheet Download icon

Features

  • 350 mm focal length for controlled convergence and focusing of laser beams
  • 25.4 mm diameter provides compatibility with standard 1-inch optical mounting systems
  • UVFS (JGS1) fused silica substrate offers reliable optical performance for demanding laser applications
  • AR548 coating on both surfaces is optimized for 1030 nm operation
  • Less than 0.1% reflectance at 1030 nm and normal incidence helps maximize transmitted laser energy
  • Greater than 80% clear aperture provides an effective usable optical area
  • 20-10 surface quality minimizes scattering and supports clean beam transmission
  • λ/6 surface irregularity provides accurate optical wavefront control.
  • Less than 3 arcmin centration error supports precise alignment in optical assemblies
  • Estimated LIDT above 0.5 J/cm² at 1030 nm, 500 fs, and 10 kHz

Applications

  • 1030 nm Ultrafast Laser Systems for beam focusing and optical beam delivery
  • Yb Laser Platforms requiring precision optics optimized for near-infrared laser wavelengths
  • Femtosecond Laser Systems for high-peak-power ultrashort-pulse applications
  • Picosecond Laser Systems for precision beam manipulation and focusing
  • Laser Micromachining for controlled focusing in precision material processing systems
  • Scientific and Photonics Research for laboratory laser setups and experimental optical systems
  • Laser Beam Delivery for directing and focusing 1030 nm laser radiation within integrated optical assemblies

Export & Trade Information

ECCN: EAR99
HTS Code: 9001.90.4000
Estimated US Tariff: 10%

Importing, tariffs & codes (Quick Guide) →

Frequently Asked Questions

What is the focal length of the OPTOMAN PCX-F350-UVFS-25.4-ET2.0-AR548-AR548 lens?
The lens has a positive focal length of 350 mm, making it suitable for controlled focusing and convergence of collimated laser beams.
What wavelength is the PCX-F350-UVFS-25.4-ET2.0-AR548-AR548 optimized for?
The lens is optimized for 1030 nm laser applications. Its AR548 coating provides less than 0.1% reflectance at 1030 nm at normal incidence.
What is the substrate material of this plano-convex lens?
The lens is manufactured from UVFS (JGS1) fused silica, a material suitable for high-performance laser optics and demanding photonics applications.
Can this lens be used with femtosecond lasers?
Yes. The lens is designed for ultrafast laser applications and has an estimated laser-induced damage threshold above 0.5 J/cm² under the specified 1030 nm, 500 fs, 10 kHz conditions.
What are the dimensions of this UVFS plano-convex lens?
The optical diameter is 25.4 mm. The lens has a 2.5 mm center thickness, 2.0 mm edge thickness, and a clear aperture exceeding 80%.

Got more questions? Use the inquiry form to ask the supplier directly.
