1535nm Er Glass Eye-Safe Laser For Ranging Finder
For pricing, technical or any other questions please contact the supplier
- No registration required
- No markups, no fees
- Direct contact with supplier
Contact Supplier
How to order?
-
Ships from:
China
-
Sold by:
-
On FindLight:
since 2019
Description
Erbium Glass Eye-Safe Laser is a state-of-the-art laser technology designed to meet the demands of various precision applications while ensuring safety and efficiency. Operating at a wavelength of 1535nm, this laser is crafted with meticulous precision to deliver exceptional performance. Its eye-safe nature makes it an ideal choice for applications where human interaction is frequent and safety is paramount.
The Erbium Glass Laser is available in multiple models, each tailored to deliver specific energy outputs and pulse widths. The models, such as CL 1535-40μJ-SL004 and CL1535-300μJ-SL003, offer a range of single pulse energies from 40μJ to 300μJ, catering to diverse operational needs. Despite their powerful capabilities, these lasers are remarkably lightweight, with weights ranging from 9.5g to 11g, and compact sizes that make integration into existing systems seamless.
Designed to operate efficiently without the need for refrigeration, these lasers boast an impressive lifespan, ensuring long-term reliability and cost-effectiveness. They are engineered to perform in a wide range of temperatures, from -40°C to 65°C for operation and -50°C to 90°C for storage, making them highly versatile for various environmental conditions.
Each model is built with a consistent beam divergence angle of 12 mrad, ensuring precision in applications such as laser ranging. The repetition frequency varies across models, offering flexibility in usage. The robust construction and thoughtful design make the Erbium Glass Eye-Safe Laser a superior choice for industries requiring safe and reliable laser technology.
1535nm Er Glass Eye-Safe Laser For Ranging Finder
Specifications |
|
|---|---|
| Avg. Power: | 0.001 W |
| Wavelength: | 1535 nm |
| Repetition Rate: | 0.01 – 0.01 kHz |
| Spatial Mode (M^2): | 1.2 |
| Pulse Duration: | 4.6 ns |
| Pulse-to-Pulse Stability (RMS): | 0.8 % |
| Cooling: | N/A |
| Single Pulse Energy: | 40; 100; 200; 300 μJ |
| Pulse Width: | 5, 6, 4.5, 6 ns |
| Beam Divergence Angle: | ＜12 mrad |
| Repetition Frequency: | 1000; 10; 10; 10; Hz |
| Life: | ＞2×108 Shots |
| Weight: | 6; 6; 9; 9 g |
| Size: | 21×8×7; 25×8×7 mm |
| Wavelength: | 1535 nm |
Features
- Eye-Safe Laser Technology: Operates at a wavelength of 1535nm, ensuring eye safety.
- Models Available: CL 1535-40μJ-SL004, CL1535-100μJ-SL001, CL1535-200μJ-SL002, CL1535-300μJ-SL003.
- High Pulse Energy Options: Offers single pulse energy options of 40μJ, 100μJ, 200μJ, and 300μJ.
- Compact Design: Extremely lightweight with a small package size, making it easy to integrate.
- Wide Operating Temperature Range: Functions efficiently between -40°C to 65°C.
- Durable: Long life expectancy with up to 22 x 1010 shots.
- No Cooling Required: Operates without the need for refrigeration.
- Consistent Beam Quality: Small divergence angle of 12 mrad ensures precision.
- Customization Available: Can be customized for other energy ranges to suit specific needs.
- Advanced Laser Material Module: Features Er,Yb: Phosphate Glass with customizable concentration levels.
- Efficient Energy Use: High energy efficiency with stable and tolerant performance.
- Versatile Pump Light Options: Supports a wide range of pump light sizes and powers.
Applications
- Laser Ranging: Accurate distance measurement in compact systems.
- LIDAR: Reliable pulsed laser source for mapping and navigation.
- Target Recognition: Enhances detection in defense and security systems.
- DPSSL Pump Source: Suited for diode-pumped solid-state laser architectures.
Frequently Asked Questions
The applications of the eye-safe laser include laser ranging, laser irradiation, laser radar, target recognition, laser medical treatment, and optical fiber communication.
The eye-safe laser does not require refrigeration.
The pulse repetition rate of the eye-safe laser is less than 10 Hz.
The ranging range of the eye-safe laser is 3-5km with high stability.
The wavelength of the 1535nm Er Glass eye-safe laser is 1535nm.
