Description
The RPMC Lasers Inc 785L-1XA is an advanced laser diode module featuring a single-mode 785nm wavelength. This compact, all-in-one design offers exceptional performance and reliability, making it ideal for various applications in the fields of research, industrial, and life sciences.
With multiple fiber-coupled options and automatic power control, this laser diode module provides precise and stable operation.
0785L-14A-NI-PT-NF: Laser Diode Module Single Mode (785nm | 150mW)
Specifications
| Laser Type: | Continuous Wave (CW), Modulated |
|---|---|
| Fiber Type: | Single Mode |
| Wavelength: | 785 nm |
| Output Power: | 150 mW |
| Fiber Core Diamater: | 100 um |
| Fiber Cladding Diameter: | 200 um |
| Fiber Length: | 1 m |
| Laser Safety Class: | 3B |
| Net Weight: | 0.12 kg |
| Longitudinal Modes: | Multiple |
| Modulation Bandwidth: | 10 MHz |
| Transversal Modes: | Multiple |
| Intensity Noise: | 0.25 % |
| Power Stability: | 0.05 % |
| Spectral Line Width FWHM: | 0.2 nm |
| Temperature Stabilization: | Internal TEC |
| Overheat Protection: | Yes |
| Optimum Heatsink Temperature: | 20 °C |
| Warm Up Time: | 0.5 min |
| Storage Temperature: | -10 to +50 ℃ |
| Max. Power Consumption: | 2 W |
| Input Voltage: | 5 VDC |
| External Power Supply Requirement: | +5 V DC, 1.5 A |
| Dimensions: | 50 x 30 x 18 mm |
Download Data Sheet
Features
- Wavelength: 785nm
- Multiple Fiber Coupled Options
- Ultra-compact All-in-one Design
- Thermally Stabilized Optics
- Monolithic Design
- Hermetically Sealed
- Automatic Power Control
- 5VDC Input Voltage
Applications
- Life Science Applications
- Flow Cytometry
- Raman Spectroscopy
- Confocal Microscopy
- Holography
- Interferometry
- Spectroscopy
Frequently Asked Questions
What are some applications of the 0785L-14A-NI-PT-NF laser diode module?
The laser diode module can be used in laser diffraction particle analysis, confocal microscopy, food sorting, and flow cytometry.
What is the wavelength of the 0785L-14A-NI-PT-NF laser diode module?
The wavelength of the 0785L-14A-NI-PT-NF laser diode module is 785nm.
What is the maximum optical power that the laser diode module can emit?
The laser diode module can emit up to 150mW of optical power.
What is the warranty period for the Matchbox series laser diode modules?
All the Matchbox series modules include a 12-month warranty.
What is the length of the FC/PC fiber that comes with the laser diode module?
The laser diode module comes with a 1m length, FC/PC fiber.
