Page 4 - CW Semiconductor Lasers

The Connet VENUS series 1480nm High Stability Single-Mode Pump Laser Source is a cutting-edge laser source engineered for high-performance applications such as EDFA (Erbium-Doped Fiber Amplifier), Raman amplifiers, and more. With built-in isolation protection, Connet ensures added safety for the pump laser source. This highly ...

Specifications

Center Wavelength: 1.480 um
Output Power: 800 mW
Output Power: 100 to 800 mW
Peak Operating Wavelength: 1460 to 1490 nm
Spectral Width (FWHM): 5 nm
...
Data Sheet
World Star Tech proudly offers a comprehensive range of OSRAM laser diodes in blue, green, and infrared wavelengths. We provide complete characterization services for these diodes, streamlining your manufacturing process for enhanced reliability and cost-efficiency. Our services cover crucial parameters such as wavelength, laser ...

Specifications

Center Wavelength: 0.520 um
Output Power: 100 mW
Operating Modes: Efficient for both CW and Pulsed operation
Laser Mode: Single Transverse Mode Semiconductor Laser
Modulation Bandwidth: High Bandwidth for Dynamic Control (CW)
...
Data Sheet
The LR-0.4-670 Laser Diode Module offered by World Star Tech is a compact and reliable laser module designed for a variety of applications including measurement, automation, and alignment. It emits laser radiation at a wavelength of 670 nm, which falls within the visible spectrum. This laser module is built for continuous operation ...

Specifications

Center Wavelength: 0.670 um
Output Power: 0.4 mW
Laser Power Stability (with Heat Sink): < 1%
Wavelength Drift: 0.2 nm/°C
Laser Class: Class 1
...
Data Sheet
The UT5-10G-658 Laser Diode Module, designed by World Star Tech, is a versatile and highly precise laser solution suitable for a wide range of applications, including measurement, automation, and alignment tasks. This laser module emits a laser beam with exceptional stability and low noise, making it ideal for demanding and precise ...

Specifications

Center Wavelength: 0.658 um
Output Power: 10 mW
Laser Power Stability (with Heat Sink): < 1%
Wavelength Drift: 0.2nm/oC
Laser Class: Class IIIB
...
Data Sheet
The TECRL-658 Red Laser Diode Module by World Star Tech is a powerful and precise laser solution designed for a wide range of applications, including measurement, bioanalytical tasks, and confocal microscopy. This module emits a red laser beam with exceptional stability and low noise, making it ideal for demanding applications in ...

Specifications

Center Wavelength: 0.658 um
Output Power: 10-150 mW
Laser Power Stability: < 0.5%
Laser RMS Noise: < 0.5%
Polarization Ratio: 100:1
...
Data Sheet
Overview: The LQB-1S-635 Laser Diode Module from World Star Tech is a reliable and precise optical solution designed for various applications, including measurement, automation, and alignment. This module emits a 635 nm laser beam with exceptional stability and low noise, making it a versatile tool for demanding tasks. Operational ...

Specifications

Center Wavelength: 0.635 um
Output Power: 1 mW
Laser Power Stability (with Heat Sink): < 1%
Wavelength Drift: 0.2 nm/°C
Laser Class: Class 2
...
Data Sheet
World Star Tech offers a comprehensive range of precision laser diodes spanning the spectral range from 405nm to 830nm, all conveniently housed in compact 5.6mm packages. These specialized laser diodes serve as ideal laser excitation sources for a variety of applications, ensuring reliable and efficient performance. Our laser diode ...

Specifications

Center Wavelength: 0.827 um
Output Power: 260 mW
Threshold Current: 30mA (min) - 60mA (max)
Operating Current (CW): 250mA (min) - 350mA (max)
Operating Voltage (CW): 2.1V (min) - 2.9V (max)
...
Data Sheet
The WLD-7-650N is a high-performance laser diode module designed to meet your precision laser needs. With an optical output power of 7 mW and exceptional electrical and optical characteristics, it's a reliable choice for a wide range of applications. Trust in the WLD-7-650N Laser Diode for its impressive capabilities and versatility ...

Specifications

Center Wavelength: 0.650 um
Output Power: 7 mW
LD Reverse Voltage: 2 V
PD Reverse Voltage: 30 V
Storage Temperature: -40°C to 85°C
...
Data Sheet
The UH-Series Laser Modules from World Star Tech represent the pinnacle of precision laser solutions. Engineered for versatility and performance, these laser modules are meticulously designed to meet your exacting requirements. Versatile Options: Our standard UH-Series lasers are equipped with adjustable focus lenses and preset ...

Specifications

Center Wavelength: 0.658 um
Output Power: 50 mW
Laser Power Stability (with Heat Sink): < 1%
Wavelength Drift: 0.2 nm/°C
Laser Class: Class IIIB
...
Data Sheet
The LR-1-635 Laser Diode Module from World Star Tech is a versatile and reliable solution for various applications. This compact module emits a 635nm wavelength laser with an optical output power of less than 1mW, making it suitable for precision tasks. Whether you require laser modules for measurement, automation, or alignment ...

Specifications

Center Wavelength: 0.635 um
Output Power: 1 mW
Laser Power Stability (with Heat Sink): < 1%
Wavelength Drift: 0.2 nm/°C
Laser Class: Class 2
...
Data Sheet
World Star Tech offers an extensive range of high-quality OSRAM laser diodes in blue, green, and infrared wavelengths. Our comprehensive characterization services streamline your manufacturing process, enhancing reliability and cost-effectiveness. We provide essential data, including wavelength, laser threshold current, slope ...

Specifications

Center Wavelength: 0.488 um
Output Power: 60 mW
Operating Temperature: -20 to +60 C
Storage Temperature: -40 to +85 C
Juncture Temperature: 150 C
...
Data Sheet
UH-Series Laser Modules are complete, all-in-one solutions featuring an integrated laser driver circuit, meticulously polished surface glass aspherical lenses, and a high-performance laser diode. These modules are characterized by their compact anodized aluminum housing, precise focus adjustment, pristine beam quality, minimal ...

Specifications

Center Wavelength: 0.658 um
Output Power: 7 mW
Laser Power Stability (with Heat Sink): < 1%
Wavelength Drift: 0.2 nm/°C
Laser Class: Class IIIB
...
Data Sheet
The UT5-1G-635 is a state-of-the-art laser diode module, embodying precision and versatility. With a distinct 635nm wavelength and 1mW optical output power, this unit ensures unparalleled accuracy. Designed for seamless integration into various applications such as measurement, automation, and alignment, it stands out due to its ...

Specifications

Center Wavelength: 0.635 um
Output Power: 1 mW
Laser Power Stability (with Heat Sink): < 1%
Laser Class: Class 2
Spot Size: Elliptical Adjustable (default) or Collimated (5mm) at 1m
...
Data Sheet
The LR-Series Laser modules seamlessly combine the prowess of an integrated laser driver circuit, aspherical plastic lens optics, and a laser diode, all encased within a sleek brass body. Boasting a compact footprint, these modules deliver a precise circular beam backed by robust industrial durability. For applications demanding ...

Specifications

Center Wavelength: 0.650 um
Output Power: 0.4 mW
Laser Power Stability (with Heat Sink): < 1 %
Wavelength Drift: 0.2 nm/°C
Laser Class: Class 1
...
Data Sheet
The UL5-5G-650 Laser Diode Module by WORLD STAR TECH is a cutting-edge laser solution designed for precision tasks in measurement, automation, and alignment. With a prominent 650nm wavelength, this single mode laser is engineered for users who prioritize both versatility and performance. Its standout feature is the adjustable focus ...

Specifications

Center Wavelength: 0.650 um
Output Power: 5 mW
Laser Power Stability (with Heat Sink): <1 %
Wavelength Drift: 0.2 nm/°C
Laser Class: Class IIIA/3R
...
Data Sheet
LR-1-650 Laser Diode Module by WORLD STAR TECH: Crafted for precision, the LR-1-650 laser diode module is distinguished for its collimated beam quality, high stability, and low noise. Featuring ESD & reverse polarity protection, this laser module ensures safety and longevity. All these stellar features are presented at a ...

Specifications

Center Wavelength: 650 um
Output Power: 1 mW
Power Stability (with Heat Sink): < 1 %
Wavelength Drift: 0.2 nm/°C
Laser Class: Class 2
...
Data Sheet
LQB-Series Laser diode modules encapsulate efficiency and precision in a compact brass body. Designed for robust industrial applications, they integrate a laser driver circuit, advanced aspherical plastic lens optics, and a high-performance laser diode. The module's compact design, superior beam quality, and cost-effectiveness set it ...

Specifications

Center Wavelength: 0.635 um
Output Power: 0.4 mW
Laser Power Stability (with Heat Sink): < 1 %
Wavelength Drift: 0.2 nm/°C
Laser Class: Class 1
...
Data Sheet
World Star Tech presents the WLD-175-405, a premium 405 nm single mode blue-violet laser diode that delivers 175 mW optical power (CW). With its compact 5.6mm package, this laser diode is an optimal choice for various applications, particularly in the biomedical field where consistent performance, longevity, and stability are ...

Specifications

Center Wavelength: 0.405 um
Output Power: 175 mW
Optical Output Power (Max): 210 mW
Reverse Voltage: 2 V
Operating Case Temperature Range: -5 to +85 °C
...
Data Sheet
Ushio Opto Semiconductor offers a diverse range of laser diodes spanning from 405nm to 850nm. The HL40033G, a 1000mW 405nm violet diode, is tailored for imaging, biomedical, and various industrial needs. For those seeking a single mode 405nm diode, the HL40071MG from Ushio offers up to 300 mW of power. Within the red laser diode ...

Specifications

Center Wavelength: 0.670 um
Output Power: 15 mW
Operation Temperature: -10 to +60 °C
Operating Voltage: 2.3 to 2.7 V
Package Diameter: φ5.6 mm
...
Data Sheet
Ushio Opto Semiconductor is at the forefront of laser diode technology, presenting a vast range of Ushio/Opnext Laser Diodes that span from 405nm to 850nm. Our collection is tailored to various power levels to address diverse needs: HL40033G (405nm, 1000mW): This violet diode is meticulously designed for imaging, biomedical, and ...

Specifications

Center Wavelength: 0.670 um
Output Power: 10 mW
Threshold Current (typ.): 20 mA
Operating Current (typ.): 30 mA
Operating Voltage (typ.): 2.2 V
...
Data Sheet
Ushio Opto Semiconductor, also known as Ushio/Opnext, offers an extensive range of Laser Diodes, spanning wavelengths from 405nm to 850nm and varying power levels. Highlighted Products: HL40033G (1000mW, 405nm): A violet diode, perfect for imaging, biomedical, and industrial applications. HL40071MG: A new addition to our ...

Specifications

Center Wavelength: 0.633 um
Output Power: 100 mW
LD Reverse Voltage: 2 V
Operating Temperature: -10 to +40 C
Storage Temperature: -40 to +85 C
...
Data Sheet
High-power diode laser bars for the most demanding applications. They are extremely reliable, efficient, and durable. This high power laser diode bar is available on the standard CS package. Other package options are available upon request. Our semiconductor products are easily assembled using standard soldering methods. The material ...

Specifications

Center Wavelength: 0.690 um
Output Power: 12000 mW
Operating Current: 22000 mA
Data Sheet
The 830L-1XA Laser Diode Module is a compact and versatile laser source from RPMC Lasers Inc. It operates at a wavelength of 830nm and offers multiple fiber-coupled options. With its ultra-compact all-in-one design and thermally stabilized optics, this laser module ensures reliable and maintenance-free operation. It features ...

Specifications

Center Wavelength: 0.83 um
Output Power: 130 mW
Polarization Direction: Horizontal
Polarization Contrast: 2000:1
Longitudinal Modes: Multiple
...
Data Sheet
The DWDM Butterfly Laser Module RZLD-1562.23-10-BP-FA-14 is a high-quality, high-power DFB laser diode with a butterfly package that's perfect for optical transmitter systems. With a built-in thermo-electric cooler (TEC), this laser diode is able to function properly in a variety of environments. This laser module features high ...

Specifications

Center Wavelength: 1.562 um
Output Power: 5 mW
Optical Isolation (optional): 35 dB
Spectral Width (-20 DB): 0.1 to 1 nm
Wavelength Temperature Coefficient: 0.08 to 0.12 nm/degC
...
Data Sheet
This high quality Narrow Linewidth DFB Laser Diode with butterfly package is a high-performance laser diode that offers exceptional power output for use in optical transmitter systems. It is designed with a butterfly package that includes a built-in thermo-electric cooler (TEC) for stable and reliable performance in various ...

Specifications

Center Wavelength: 1.310 um
Output Power: 50 mW
Operating Case Temperature: -20 - +70 degC
Storage Temperature: -40 - +85 degC
Reverse Voltage: 2 V
...
Data Sheet
