Description

The LDX-XXXX-885 is a high-power multimode laser diode designed to provide reliable and efficient laser performance at a wavelength of 885nm. This laser diode offers a wide range of output power options, with up to 6000mW in free space and up to 4800mW when used with fiber optics.

It boasts high output power and dynamic range, making it suitable for various applications. Custom packaging, wavelengths, and laser designs are available to meet specific requirements.

LDX-3210-885: 885nm 2500mW Multimode Laser Diode

Visit the RPMC Lasers, Inc. Store

Specifications

Center Wavelength: 0.885 um
Output Power: 2500 mW
Operating Temperature: 25 °C
Threshold Current: 200 mA
Operating Current: 2500 mA
Operating Voltage: 2.0 V
Beam Divergence (FWHM): 7 θ// (°)
Spectral Width (FWHM): 2.4 nm

Got questions about specs? Use the inquiry form to ask.

Document icon Download Data Sheet Download icon

Features

  • Wavelength: 885nm
  • Output Power: Up to 6000mW in free space, Up to 4800mW from fiber
  • High output power and dynamic range
  • High efficiency
  • Custom packaging available
  • Custom wavelengths and laser designs available

Applications

The LDX-XXXX-885 laser diode is ideal for a wide range of applications, including but not limited to:

  • Industrial laser systems
  • Medical equipment
  • Research and development
  • Laser-based manufacturing processes
  • Fiber optic communication systems
  • Scientific experiments and studies

Frequently Asked Questions

What is the output power of the LDX-3210-885 laser diode?
The LDX-3210-885 laser diode produces 2500mW from a 60um emitter in the free space packages or 2000mW from the fiber in the fiber coupled packages.
What is the wavelength of the LDX-3210-885 laser diode?
The LDX-3210-885 laser diode has a wavelength of 885nm.
What are the applications of the LDX-3210-885 laser diode?
The LDX-3210-885 laser diode is suitable for diode laser solutions, scientific and industrial applications, and OEM applications.
Is custom packaging available for the LDX-3210-885 laser diode?
Yes, custom packaging is available for the LDX-3210-885 laser diode.
Are custom wavelengths and laser designs available for the LDX-3210-885 laser diode?
Yes, custom wavelengths and laser designs are available for the LDX-3210-885 laser diode.
