NPI’s Blade series ultrafast fiber laser is industrial grade ultrafast laser with high stability and reliability. Its single pulse energy is up to >50 μJ and pulse width is <15 ps. It is the most popular laser light source in ultrafast precision micro fabrication. Blade series ultrafast fiber lasers are mainly used in ...
  • Wavelength: 1064 nm
  • Repetition Rate: 1 MHz
  • Output Power: 10 W
  • Pulse Duration: 15000 fs
  • Output Fiber Type: Armored cable
  • ...
Data Sheet
Rainbow 1064 series is high a repetition rate 1 micron ultrafast fiber laser. The laser parameters can be selected flexibly in certain range. Typical output wavelength of this ultrafast fiber laser is from 1030 to 1064 nm, the pulse width is less than 10 ps, the repetition rate is 5-50 MHz. Lower rate is also available, that can be ...
  • Wavelength: 1030 nm
  • Repetition Rate: 10 MHz
  • Output Power: 1 W
  • Pulse Duration: 15000 fs
  • Peak Power: >60 kW
  • ...
Data Sheet
Rainbow 1550 series is an ultrafast mode locked fiber laser with turn key system and maintenance free. This ultrafast fiber laser designed as MOPA structure integrated optical and circuit structure, which is easy to integrate in researchers’ device or industrial laser system. Because of its high stability, reliability, customization ...
  • Wavelength: 1560 nm
  • Repetition Rate: 30 MHz
  • Output Power: 0.1 W
  • Pulse Duration: 100  fs
  • Power Requirement: AC 100-240 V (50 Hz/ 60 Hz)
  • ...
Data Sheet
Menlo Systems’ femtosecond Yb fiber-baser laser sources now offer more than 10 W in average power with a pulse duration of <200 fs. Based on our unique figure 9® design, the lasers offer reproducible and long-term stable operation. Both oscillator and amplifier use polarization maintaining (PM) fiber ...
  • Wavelength: 520 nm
  • Repetition Rate: 100 MHz
  • Output Power: 0.4 W
  • Pulse Duration: 150 fs
Data Sheet
Menlo Systems’ fiber-based femtosecond laser sources integrate the latest achievements in fiber technology into easy-to-use products. Menlo Systems’ unique figure 9® mode locking technology results in reproducible and long-term stable operation. The YLMO with its PM-fiber design guarantees excellent ...
  • Wavelength: 1030 nm
  • Repetition Rate: 50 MHz
  • Output Power: 0.2 W
  • Pulse Duration: 150 fs
Data Sheet
Menlo Systems’ femtosecond Yb fiber-baser laser sources now offer more than 10 W in average power with a pulse duration of <200 fs. Based on our unique figure 9® design, the lasers offer reproducible and long-term stable operation. Both oscillator and amplifier use polarization maintaining (PM) fiber ...
  • Wavelength: 1040 nm
  • Repetition Rate: 100 MHz
  • Output Power: 10 W
  • Pulse Duration: 200 fs
Data Sheet
Menlo Systems’ femtosecond Yb fiber-baser laser sources now offer more than 10 W in average power with a pulse duration of <200 fs. Based on our unique figure 9® design, the lasers offer reproducible and long-term stable operation. Both oscillator and amplifier use polarization maintaining (PM) fiber ...
  • Wavelength: 1040 nm
  • Repetition Rate: 100 MHz
  • Output Power: 1 W
  • Pulse Duration: 150 fs
Data Sheet
Menlo Systems’ fiber-based femtosecond laser sources integrate the latest achievments in fiber technology into easy-to-use products. Menlo Systems’ unique figure 9® design results in reproducible and long-term stable operation. It is based on the well-established nonlinear optical loop mirror (NOLM) mode locking ...
  • Wavelength: 780 nm
  • Repetition Rate: 100 MHz
  • Output Power: 0.250 W
  • Pulse Duration: 100 fs
Data Sheet
Menlo Systems’ fiber-based femtosecond laser sources integrate the latest achievments in fiber technology into easy-to-use products. Menlo Systems’ unique figure 9® design results in reproducible and long-term stable operation. It is based on the well-established nonlinear optical loop mirror (NOLM) ...
  • Wavelength: 1560 nm
  • Repetition Rate: 100 MHz
  • Output Power: 0.5 W
  • Pulse Duration: 90 fs
Data Sheet
Menlo Systems’ fiber-based femtosecond laser sources integrate the latest achievements in fiber technology into easy-to-use products. Menlo Systems’ unique figure 9® mode locking technology results in reproducible and long-term stable operation. The YLMO with its PM-fiber design guarantees excellent ...
  • Wavelength: 1030 nm
  • Repetition Rate: 50 MHz
  • Output Power: 0.005 W
  • Pulse Duration: 150 fs
Data Sheet
Menlo Systems’ fiber-based femtosecond laser sources integrate the latest achievements in fiber technology into easy-to-use products. Menlo Systems’ unique figure 9® mode locking technology results in reproducible and long-term stable operation. The YLMO-2W with its PM-fiber design guarantees excellent ...
  • Wavelength: 1030 nm
  • Repetition Rate: 50 MHz
  • Output Power: 2 W
  • Pulse Duration: 150 fs
Data Sheet
Menlo Systems’ femtosecond Yb fiber-baser laser sources now offer more than 10 W in average power with a pulse duration of <200 fs. Based on our unique figure 9® design, the lasers offer reproducible and long-term stable operation. Both oscillator and amplifier use polarization maintaining (PM) fiber ...
  • Wavelength: 1040 nm
  • Repetition Rate: 100 MHz
  • Output Power: 0.1 W
  • Pulse Duration: 150 fs
Data Sheet
Menlo Systems’ fiber-based femtosecond laser sources integrate the latest achievments in fiber technology into easy-to-use products. Menlo Systems’ unique figure 9® design results in reproducible and long-term stable operation. It is based on the well-established nonlinear optical loop mirror (NOLM) mode locking ...
  • Wavelength: 780 nm
  • Repetition Rate: 100 MHz
  • Output Power: 0.1 W
  • Pulse Duration: 100 fs
Data Sheet
Menlo Systems’ fiber-based femtosecond laser sources integrate the latest achievments in fiber technology into easy-to-use products. Menlo Systems’ unique figure 9® design results in reproducible and long-term stable operation. It is based on the well-established nonlinear optical loop mirror (NOLM) ...
  • Wavelength: 1560 nm
  • Repetition Rate: 100 MHz
  • Output Power: 100 W
  • Pulse Duration: 90 fs
Data Sheet
The BlueCut is an industrial-grade micro-Joule femtosecond fiber laser system. Based on all-fiber integrated technology, this is an inherently robust and stable system, which comes in a sealed package designed for OEM integration. The system is maintenance free and easily field serviceable, ensuring maximum up-time ...
  • Wavelength: 515 nm
  • Repetition Rate: 10 MHz
  • Output Power: 3.5 W
  • Pulse Duration: 400 fs
Data Sheet
The BlueCut is an industrial-grade micro-Joule femtosecond fiber laser system. Based on all-fiber integrated technology, this is an inherently robust and stable system, which comes in a sealed package designed for OEM integration. The system is maintenance free and easily field serviceable, ensuring maximum up-time ...
  • Wavelength: 1030 nm
  • Repetition Rate: 10 MHz
  • Output Power: 10 W
  • Pulse Duration: 400 fs
Data Sheet
YSL Photonics’PicoYL-70 has a tunable pulse duration from 50 ps to 800ps, repetition rates from 25 kHz up to 5 MHz and over 70W average power. The short pulse duration, high repetition rates combined with over 1MW peak power open up a variety of micromachining applications such as PERC solar cell dicing, glass drilling, ...
  • Wavelength: 1030 nm
  • Repetition Rate: 0.025-5 MHz
  • Output Power: >70 W
  • Pulse Duration: 300000 fs
Data Sheet
YSL Photonics’PicoYL-50 has a tunable pulse duration from 50 ps to 800ps, repetition rates from 25 kHz up to 5 MHz and over 70W average power. The short pulse duration, high repetition rates combined with over 500kW peak power open up a variety of micromachining applications such as PERC solar cell dicing, glass drilling, ...
  • Wavelength: 1030 nm
  • Repetition Rate: 0.025-5 MHz
  • Output Power: 50 W
  • Pulse Duration: 300000 fs
Data Sheet
YSL Photonics’PicoYL-20 has a continuously tunable pulse duration from 200ps to 2ns and repetition rates from 30 kHz up to 1 MHz. The short pulse duration, high repetition rates combined with over 150kW peak power give high speed, permanent black/color marking on a variety of metals, thin film coating and thermal sensitive ...
  • Wavelength: 1064 nm
  • Repetition Rate: 0.03-1 MHz
  • Output Power: 20 W
  • Pulse Duration: 200000 fs
Data Sheet
YSL Photonics’PicoYL-15 has a continuously tunable pulse duration from 100 ps to 4 ns and repetition rates from 100 kHz up to 5MHz. The short pulse duration, high repetition rates combined with over 50kW peak power give high speed, permanent black/color marking on a variety of metals, thin film coating and thermal sensitive ...
  • Wavelength: 1030 nm
  • Repetition Rate: 0.1-5 MHz
  • Output Power: 20 W
  • Pulse Duration: 100000 fs
Data Sheet

Did You know?

Ultrafast fiber lasers are mode-locked lasers that generate ultrashort pulses operating in the picosecond and femtosecond range. The high-energy and precision offered by ultrafast fiber lasers make them ideal for applications that require very precise cutting, such as material processing, bio-medicals, sensors, and optical communications. In the future, these lasers show promising potential in the medical field as they may have the ability to treat diseases like HIV and Ebola virus by damaging their viral capsids. They also show promise in the applications of disinfecting medication and producing inactivated vaccines.
