Cyclone - FYLA fiber laser
Description
Broad Bandwidth Fiber Laser with Extremely Short Femtosecond Pulses
The Cyclone is a broad bandwidth femtosecond fibre laser. It provides the shortest pulses on the market generated by a fibre laser, less than 20 fs pulses.
Cyclone provides outstanding peak power (>200 kW) over a wide spectrum of 900-1200nm.
These parameters allow for increased brightness and reduced photodamage, making the Cyclone laser perfect for multiphoton microscopy, SHG microscopy and a variety of other non-linear processing and spectroscopy applications.
It is a cost-effective, maintenance-free femtosecond fibre laser with best-in-class performance.
Cyclone - FYLA fiber laser
Specifications |
|
|---|---|
| Wavelength: | 900-1200 nm |
| Repetition Rate: | 80 MHz |
| Output Power: | > 0.25 W |
| Pulse Duration: | 15 fs |
| Peak Power: | > 200 kW |
Features
Spectral range: 950-1150 nm
Pulse duration: 15-20 fs
Optical peak power: > 120 kW
Applications
- Two-Photon microscopy
- Non-linear optics
- Spectroscopy
- Multiphoton microscopy
- SHG
- TPEF
For pricing, technical or any other questions please contact the supplier
- No registration required
- No markups, no fees
- Direct contact with supplier
Contact Supplier
How to order?
-
Ships from:
Spain
-
Sold by:
-
On FindLight:
since 2020
Frequently Asked Questions
The pulse duration of the Cyclone fiber laser is 15-20 fs.
The spectral range of the Cyclone fiber laser is 950-1150 nm.
The optical peak power of the Cyclone fiber laser is > 120 kW.
The Cyclone fiber laser is suitable for two-photon microscopy, non-linear optics, spectroscopy, multiphoton microscopy, SHG microscopy, and TPEF.
Yes, the Cyclone fiber laser is maintenance-free.
